An abstract base class for processor coupled interfaces. More...

Inheritance diagram for processorLduInterface:

Public Member Functions
	TypeName ("processorLduInterface")
	Runtime type information. More...

	processorLduInterface ()
	Construct null. More...

virtual	~processorLduInterface ()
	Destructor. More...

virtual label	comm () const =0
	Return communicator used for parallel communication. More...

virtual int	myProcNo () const =0
	Return processor number (rank in communicator) More...

virtual int	neighbProcNo () const =0
	Return neighbour processor number (rank in communicator) More...

virtual const transformer &	transform () const =0
	Return transformation between the coupled patches. More...

virtual int	tag () const =0
	Return message tag used for sending. More...

template<class Type >
void	send (const Pstream::commsTypes commsType, const UList< Type > &) const
	Raw send function. More...

template<class Type >
void	receive (const Pstream::commsTypes commsType, UList< Type > &) const
	Raw field receive function. More...

template<class Type >
tmp< Field< Type > >	receive (const Pstream::commsTypes commsType, const label size) const
	Raw field receive function returning field. More...

template<class Type >
void	compressedSend (const Pstream::commsTypes commsType, const UList< Type > &) const
	Raw field send function with data compression. More...

template<class Type >
void	compressedReceive (const Pstream::commsTypes commsType, UList< Type > &) const
	Raw field receive function with data compression. More...

template<class Type >
tmp< Field< Type > >	compressedReceive (const Pstream::commsTypes commsType, const label size) const
	Raw field receive function with data compression returning field. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	receive (const Pstream::commsTypes commsType, const label size) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	compressedReceive (const Pstream::commsTypes commsType, const label size) const

Detailed Description

An abstract base class for processor coupled interfaces.

Source files

Definition at line 51 of file processorLduInterface.H.

Constructor & Destructor Documentation

◆ processorLduInterface()

processorLduInterface ( )

Construct null.

Definition at line 53 of file processorLduInterface.C.

◆ ~processorLduInterface()

~processorLduInterface ( )

virtual

Destructor.

Definition at line 62 of file processorLduInterface.C.

Member Function Documentation

◆ TypeName()

TypeName ( "processorLduInterface" )

Runtime type information.

◆ comm()

virtual label comm ( ) const

pure virtual

Return communicator used for parallel communication.

Implemented in processorGAMGInterface, and processorFvPatch.

Referenced by procLduInterface::procLduInterface(), and processorLduInterface::send().

Here is the caller graph for this function:

◆ myProcNo()

virtual int myProcNo ( ) const

pure virtual

Return processor number (rank in communicator)

Implemented in processorGAMGInterface, and processorFvPatch.

Referenced by lduPrimitiveMesh::lduPrimitiveMesh(), and procLduInterface::procLduInterface().

Here is the caller graph for this function:

◆ neighbProcNo()

virtual int neighbProcNo ( ) const

pure virtual

Return neighbour processor number (rank in communicator)

Implemented in processorGAMGInterface, and processorFvPatch.

Referenced by lduPrimitiveMesh::lduPrimitiveMesh(), procLduInterface::procLduInterface(), and processorLduInterface::send().

Here is the caller graph for this function:

◆ transform()

virtual const transformer& transform ( ) const

pure virtual

Return transformation between the coupled patches.

Implemented in processorGAMGInterface, processorCyclicFvPatch, and processorFvPatch.

◆ tag()

virtual int tag ( ) const

pure virtual

Return message tag used for sending.

Implemented in processorGAMGInterface, processorCyclicFvPatch, and processorFvPatch.

Referenced by procLduInterface::procLduInterface(), and processorLduInterface::send().

Here is the caller graph for this function:

◆ send()

void send	(	const Pstream::commsTypes	commsType,
		const UList< Type > &	f
	)		const

Raw send function.

Definition at line 33 of file processorLduInterfaceTemplates.C.

References UList< T >::begin(), UPstream::blocking, processorLduInterface::comm(), Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, processorLduInterface::neighbProcNo(), UPstream::nonBlocking, UIPstream::read(), UPstream::scheduled, processorLduInterface::tag(), and UOPstream::write().

Here is the call graph for this function:

◆ receive() [1/3]

void receive	(	const Pstream::commsTypes	commsType,
		UList< Type > &	f
	)		const

Raw field receive function.

Definition at line 94 of file processorLduInterfaceTemplates.C.

References UList< T >::begin(), UPstream::blocking, UList< T >::byteSize(), Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, UPstream::nonBlocking, UIPstream::read(), and UPstream::scheduled.

Here is the call graph for this function:

◆ receive() [2/3]

tmp<Field<Type> > receive	(	const Pstream::commsTypes	commsType,
		const label	size
	)		const

Raw field receive function returning field.

◆ compressedSend()

void compressedSend	(	const Pstream::commsTypes	commsType,
		const UList< Type > &	f
	)		const

Raw field send function with data compression.

Definition at line 143 of file processorLduInterfaceTemplates.C.

References UList< T >::begin(), UPstream::blocking, Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, UPstream::floatTransfer, UList< T >::last(), UPstream::nonBlocking, UIPstream::read(), UPstream::scheduled, List< T >::size(), and UOPstream::write().

Here is the call graph for this function:

◆ compressedReceive() [1/3]

void compressedReceive	(	const Pstream::commsTypes	commsType,
		UList< Type > &	f
	)		const

Raw field receive function with data compression.

Definition at line 223 of file processorLduInterfaceTemplates.C.

References UList< T >::begin(), UPstream::blocking, Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, UPstream::floatTransfer, UList< T >::last(), UPstream::nonBlocking, UIPstream::read(), UPstream::scheduled, and List< T >::size().

Here is the call graph for this function:

◆ compressedReceive() [2/3]

tmp<Field<Type> > compressedReceive	(	const Pstream::commsTypes	commsType,
		const label	size
	)		const

Raw field receive function with data compression returning field.

◆ receive() [3/3]

Foam::tmp<Foam::Field<Type> > receive	(	const Pstream::commsTypes	commsType,
		const label	size
	)		const

Definition at line 130 of file processorLduInterfaceTemplates.C.

References tf.

◆ compressedReceive() [3/3]

Foam::tmp<Foam::Field<Type> > compressedReceive	(	const Pstream::commsTypes	commsType,
		const label	size
	)		const

Definition at line 280 of file processorLduInterfaceTemplates.C.

References tf.

The documentation for this class was generated from the following files:

src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterface/processorLduInterface.H
src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterface/processorLduInterface.C
src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterface/processorLduInterfaceTemplates.C
