Public Member Functions | Static Public Member Functions | List of all members
polyMeshFilter Class Reference

Remove the edges and faces of a polyMesh whilst satisfying the given mesh quality criteria. More...

Inheritance diagram for polyMeshFilter:
Inheritance graph
[legend]
Collaboration diagram for polyMeshFilter:
Collaboration graph
[legend]

Public Member Functions

 ClassName ("polyMeshFilter")
 Runtime type information. More...

 polyMeshFilter (const fvMesh &mesh)
 Construct from fvMesh. More...

 polyMeshFilter (const fvMesh &mesh, const labelList &pointPriority)
 Construct from fvMesh and a label list of point priorities. More...

 polyMeshFilter (const fvMesh &mesh, const labelList &pointPriority, const dictionary &dict)
 Construct from fvMesh and a label list of point priorities. More...

 polyMeshFilter (const polyMeshFilter &)=delete
 Disallow default bitwise copy construction. More...

 ~polyMeshFilter ()
 Destructor. More...

const autoPtr< fvMesh > & filteredMesh () const
 Return reference to the filtered mesh. Does not check if the. More...

const autoPtr< labelList > & pointPriority () const
 Return the new pointPriority list. More...

label filter (const label nOriginalBadFaces)
 Filter edges and faces. More...

label filter (const faceSet &fSet)
 Filter all faces that are in the face set. More...

label filterEdges (const label nOriginalBadFaces)
 Filter edges only. More...

void operator= (const polyMeshFilter &)=delete
 Disallow default bitwise assignment. More...


Static Public Member Functions

static autoPtr< fvMesh > copyMesh (const fvMesh &mesh)
 Return a copy of an fvMesh. More...

static void copySets (const polyMesh &oldMesh, const polyMesh &newMesh)
 Copy loaded topoSets from the old mesh to the new mesh. More...

static void updateSets (const polyTopoChangeMap &map)
 Update the loaded topoSets. More...


Detailed Description

Remove the edges and faces of a polyMesh whilst satisfying the given mesh quality criteria.

Works on a copy of the mesh.

Source files

Definition at line 62 of file polyMeshFilter.H.

Constructor & Destructor Documentation

◆ polyMeshFilter() [1/4]

polyMeshFilter ( const fvMesh &  mesh)
explicit

Construct from fvMesh.

Definition at line 871 of file polyMeshFilter.C.

References Foam::Info, and polyMeshFilterSettings::writeSettings().

Here is the call graph for this function:

◆ polyMeshFilter() [2/4]

polyMeshFilter ( const fvMesh &  mesh,
const labelList &  pointPriority
)

Construct from fvMesh and a label list of point priorities.

Definition at line 898 of file polyMeshFilter.C.

References Foam::Info, and polyMeshFilterSettings::writeSettings().

Here is the call graph for this function:

◆ polyMeshFilter() [3/4]

polyMeshFilter ( const fvMesh &  mesh,
const labelList &  pointPriority,
const dictionary &  dict
)

Construct from fvMesh and a label list of point priorities.

Definition at line 928 of file polyMeshFilter.C.

References Foam::Info, and polyMeshFilterSettings::writeSettings().

Here is the call graph for this function:

◆ polyMeshFilter() [4/4]

polyMeshFilter ( const polyMeshFilter &  )
delete

Disallow default bitwise copy construction.

◆ ~polyMeshFilter()

~polyMeshFilter ( )

Destructor.

Definition at line 949 of file polyMeshFilter.C.

Member Function Documentation

◆ ClassName()

ClassName ( "polyMeshFilter"  )

Runtime type information.

◆ filteredMesh()

const Foam::autoPtr< Foam::fvMesh > & filteredMesh ( ) const

Return reference to the filtered mesh. Does not check if the.

mesh has actually been filtered.

Definition at line 1104 of file polyMeshFilter.C.

◆ pointPriority()

const Foam::autoPtr< Foam::labelList > & pointPriority ( ) const

Return the new pointPriority list.

Definition at line 1111 of file polyMeshFilter.C.

◆ copyMesh()

Foam::autoPtr< Foam::fvMesh > copyMesh ( const fvMesh &  mesh)
static

Return a copy of an fvMesh.

Definition at line 66 of file polyMeshFilter.C.

References polyTopoChange::makeMesh(), mesh, fvMesh::name(), IOobject::NO_READ, IOobject::NO_WRITE, and fvMesh::time().

Here is the call graph for this function:

◆ copySets()

void copySets ( const polyMesh &  oldMesh,
const polyMesh &  newMesh
)
static

Copy loaded topoSets from the old mesh to the new mesh.

Definition at line 54 of file polyMeshFilter.C.

◆ updateSets()

void updateSets ( const polyTopoChangeMap &  map)
static

Update the loaded topoSets.

Definition at line 46 of file polyMeshFilter.C.

◆ filter() [1/2]

Foam::label filter ( const label  nOriginalBadFaces)

Filter edges and faces.

Definition at line 955 of file polyMeshFilter.C.

◆ filter() [2/2]

Foam::label filter ( const faceSet &  fSet)

Filter all faces that are in the face set.

Definition at line 964 of file polyMeshFilter.C.

References forAll, and HashTable< T, Key, Hash >::found().

Here is the call graph for this function:

◆ filterEdges()

Foam::label filterEdges ( const label  nOriginalBadFaces)

Filter edges only.

Definition at line 981 of file polyMeshFilter.C.

References edgeCollapser::checkMeshQuality(), PackedList< nBits >::count(), Foam::decrIndent(), Foam::endl(), Foam::identityMap(), Foam::incrIndent(), Foam::indent(), Foam::Info, Foam::labelMax, Foam::nl, primitiveMesh::nPoints(), Field< Type >::reset(), and Foam::returnReduce().

Here is the call graph for this function:

◆ operator=()

void operator= ( const polyMeshFilter &  )
delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:
