Engine which provides mapping from cells to patch faces. More...

Inheritance diagram for mappedInternalPatchBase:

Collaboration diagram for mappedInternalPatchBase:

[legend]

Public Types
enum	offsetMode { NORMAL , DIRECTION }
	How to project face centres. More...

Public Member Functions
	TypeName ("mappedInternalPatchBase")
	Runtime type information. More...

	mappedInternalPatchBase (const polyPatch &)
	Construct from patch. More...

	mappedInternalPatchBase (const polyPatch &pp, const word &nbrRegion)
	Construct with no offset. More...

	mappedInternalPatchBase (const polyPatch &, const dictionary &)
	Construct from dictionary. More...

	mappedInternalPatchBase (const polyPatch &, const mappedInternalPatchBase &)
	Construct as copy, resetting patch. More...

virtual	~mappedInternalPatchBase ()
	Destructor. More...

const word &	nbrRegionName () const
	Name of the region to map from. More...

bool	sameRegion () const
	Is the neighbour region the same as for this patch? More...

const distributionMap &	map () const
	Return reference to the parallel distribution map. More...

const labelList &	cellIndices () const
	Return the indices of the cells who's values have to be. More...

const polyMesh &	nbrMesh () const
	Get the region mesh. More...

tmp< pointField >	samplePoints () const
	Get the sample points. More...

void	clearOut ()
	Clear out data on mesh change. More...

template<class Type >
tmp< Field< Type > >	distribute (const Field< Type > &fld) const
	Wrapper around map/interpolate data distribution. More...

template<class Type >
tmp< Field< Type > >	distribute (const tmp< Field< Type >> &fld) const
	Wrapper around map/interpolate data distribution. More...

virtual void	write (Ostream &) const
	Write as a dictionary. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	distribute (const Field< Type > &fld) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	distribute (const tmp< Field< Type >> &fld) const

Static Public Member Functions
static bool	specified (const dictionary &dict)
	Return whether or not the given dictionary contains a. More...

Static Public Attributes
static const NamedEnum< offsetMode, 2 >	offsetModeNames_

Protected Member Functions
offsetMode	readOffsetMode (const dictionary &dict) const
	Read the offset mode from a dictionary. More...

void	calcMapping () const
	Calculate mapping. More...

Protected Attributes
const polyPatch &	patch_
	Patch to map to. More...

word	nbrRegionName_
	Name of the region to map from. More...

offsetMode	offsetMode_
	How to offset the patch face centres to the sampling locations. More...

scalar	distance_
	Offset distance. More...

vector	offset_
	Offset vector. More...

autoPtr< distributionMap >	mapPtr_
	Distributor. More...

labelList	cellIndices_
	Indices of the cells who's values have to be supplied to the. More...

Detailed Description

Engine which provides mapping from cells to patch faces.

Example:

    // The name of the region to map from. Optional. Defaults to the same
    // region as the patch.
    neighbourRegion region0;

    // How to offset the patch face centres to the sampling locations.
    // Optional. This will be inferred if there is a single entry of either
    // "distance" or "offset".
    // - normal              : distance along the patch face normals
    // - direction           : specified offset vector
    offsetMode direction;

    // If offsetMode is normal : The normal distance to offset
    distance 1;

    // If offsetMode is direction : The offset vector
    offset (1 0 0);

Note that patch normals point outward, so if offsetMode is normal then a negative distance will be required in order to map values from inside the region.

Source files

Definition at line 73 of file mappedInternalPatchBase.H.

Member Enumeration Documentation

◆ offsetMode

enum offsetMode

How to project face centres.

Enumerator
NORMAL
DIRECTION

Definition at line 80 of file mappedInternalPatchBase.H.

Constructor & Destructor Documentation

◆ mappedInternalPatchBase() [1/4]

mappedInternalPatchBase ( const polyPatch & pp )

Construct from patch.

Definition at line 281 of file mappedInternalPatchBase.C.

◆ mappedInternalPatchBase() [2/4]

mappedInternalPatchBase	(	const polyPatch &	pp,
		const word &	nbrRegion
	)

Construct with no offset.

Definition at line 296 of file mappedInternalPatchBase.C.

◆ mappedInternalPatchBase() [3/4]

mappedInternalPatchBase	(	const polyPatch &	pp,
		const dictionary &	dict
	)

Construct from dictionary.

Definition at line 312 of file mappedInternalPatchBase.C.

◆ mappedInternalPatchBase() [4/4]

mappedInternalPatchBase	(	const polyPatch &	pp,
		const mappedInternalPatchBase &	mpb
	)

Construct as copy, resetting patch.

Definition at line 345 of file mappedInternalPatchBase.C.

◆ ~mappedInternalPatchBase()

~mappedInternalPatchBase ( )

virtual

Destructor.

Definition at line 363 of file mappedInternalPatchBase.C.

Member Function Documentation

◆ readOffsetMode()

Foam::mappedInternalPatchBase::offsetMode readOffsetMode ( const dictionary & dict ) const

protected

Read the offset mode from a dictionary.

Definition at line 55 of file mappedInternalPatchBase.C.

References dict, mappedInternalPatchBase::DIRECTION, mappedInternalPatchBase::NORMAL, mappedInternalPatchBase::offsetModeNames_, and NamedEnum< Enum, nEnum >::read().

Here is the call graph for this function:

◆ calcMapping()

void calcMapping ( ) const

protected

Calculate mapping.

Definition at line 86 of file mappedInternalPatchBase.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), primitiveMesh::cellCentres(), polyMesh::cellTree(), UList< T >::data(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, indexedOctree< Type >::findInside(), forAll, Pstream::gatherList(), PointIndexHit< Point >::hitPoint(), PointIndexHit< Point >::index(), Pstream::listCombineGather(), Pstream::listCombineScatter(), Foam::magSqr(), UPstream::myProcNo(), IOstream::name(), Foam::name(), UPstream::nProcs(), p, Foam::returnReduce(), Pstream::scatterList(), globalIndex::size(), Foam::sqr(), globalIndex::toGlobal(), List< T >::transfer(), WarningInFunction, and OBJstream::write().

Referenced by mappedInternalPatchBase::distribute().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "mappedInternalPatchBase" )

Runtime type information.

◆ nbrRegionName()

const Foam::word & nbrRegionName ( ) const

inline

Name of the region to map from.

Definition at line 30 of file mappedInternalPatchBaseI.H.

References mappedInternalPatchBase::nbrRegionName_.

◆ sameRegion()

bool sameRegion ( ) const

inline

Is the neighbour region the same as for this patch?

Definition at line 36 of file mappedInternalPatchBaseI.H.

◆ map()

const Foam::distributionMap & map ( ) const

inline

Return reference to the parallel distribution map.

Definition at line 42 of file mappedInternalPatchBaseI.H.

◆ cellIndices()

const Foam::labelList & cellIndices ( ) const

inline

Return the indices of the cells who's values have to be.

supplied to the distribution map

Definition at line 53 of file mappedInternalPatchBaseI.H.

◆ nbrMesh()

const Foam::polyMesh & nbrMesh ( ) const

Get the region mesh.

Definition at line 369 of file mappedInternalPatchBase.C.

References polyMesh::boundaryMesh(), objectRegistry::lookupObject(), polyBoundaryMesh::mesh(), and objectRegistry::time().

Here is the call graph for this function:

◆ samplePoints()

Foam::tmp< Foam::pointField > samplePoints ( ) const

Get the sample points.

Definition at line 378 of file mappedInternalPatchBase.C.

References polyMesh::boundaryMesh(), primitiveMesh::cellCentres(), PointHit< Point >::distance(), f(), UList< T >::fcIndex(), forAll, intersection::halfRay, PointHit< Point >::hit(), PointHit< Point >::hitPoint(), triangle< Point, PointRef >::intersection(), polyBoundaryMesh::mesh(), mesh, polyMesh::points(), tmp< T >::ref(), List< T >::size(), and polyMesh::tetBasePtIs().

Here is the call graph for this function:

◆ clearOut()

void clearOut ( )

Clear out data on mesh change.

Definition at line 452 of file mappedInternalPatchBase.C.

Referenced by mappedInternalPolyPatch::calcGeometry(), mappedInternalPolyPatch::movePoints(), and mappedInternalPolyPatch::topoChange().

Here is the caller graph for this function:

◆ distribute() [1/4]

tmp<Field<Type> > distribute ( const Field< Type > & fld ) const

Wrapper around map/interpolate data distribution.

◆ distribute() [2/4]

tmp<Field<Type> > distribute ( const tmp< Field< Type >> & fld ) const

Wrapper around map/interpolate data distribution.

◆ specified()

bool specified ( const dictionary & dict )

static

Return whether or not the given dictionary contains a.

mappedInternalPatchBase specification

Definition at line 459 of file mappedInternalPatchBase.C.

References dict, and dictionary::found().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write as a dictionary.

Reimplemented in mappedInternalPolyPatch.

Definition at line 469 of file mappedInternalPatchBase.C.

References IOstream::name(), Foam::writeEntry(), and Foam::writeEntryIfDifferent().

Referenced by mappedInternalPolyPatch::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ distribute() [3/4]

Foam::tmp<Foam::Field<Type> > distribute ( const Field< Type > & fld ) const

Definition at line 32 of file mappedInternalPatchBaseTemplates.C.

References mappedInternalPatchBase::calcMapping(), mappedInternalPatchBase::cellIndices_, fld(), mappedInternalPatchBase::mapPtr_, and tmp< T >::ref().

Here is the call graph for this function:

◆ distribute() [4/4]

Foam::tmp<Foam::Field<Type> > distribute ( const tmp< Field< Type >> & fld ) const

Definition at line 46 of file mappedInternalPatchBaseTemplates.C.

References fld().

Here is the call graph for this function:

Member Data Documentation

◆ offsetModeNames_

const Foam::NamedEnum< Foam::mappedInternalPatchBase::offsetMode, 2 > offsetModeNames_

static

Initial value:

{
    "normal",
    "direction"
}

Definition at line 86 of file mappedInternalPatchBase.H.

Referenced by mappedInternalPatchBase::readOffsetMode().

◆ patch_

const polyPatch& patch_

protected

Patch to map to.

Definition at line 94 of file mappedInternalPatchBase.H.

◆ nbrRegionName_

word nbrRegionName_

protected

Name of the region to map from.

Definition at line 97 of file mappedInternalPatchBase.H.

Referenced by mappedInternalPatchBase::nbrRegionName().

◆ offsetMode_

offsetMode offsetMode_

protected

How to offset the patch face centres to the sampling locations.

Definition at line 100 of file mappedInternalPatchBase.H.

◆ distance_

scalar distance_

protected

Offset distance.

Definition at line 103 of file mappedInternalPatchBase.H.

◆ offset_

vector offset_

protected

Offset vector.

Definition at line 106 of file mappedInternalPatchBase.H.

◆ mapPtr_

autoPtr<distributionMap> mapPtr_

mutableprotected

Distributor.

Definition at line 109 of file mappedInternalPatchBase.H.

Referenced by mappedInternalPatchBase::distribute().

◆ cellIndices_

labelList cellIndices_

mutableprotected

Indices of the cells who's values have to be supplied to the.

distribution map

Definition at line 113 of file mappedInternalPatchBase.H.

Referenced by mappedInternalPatchBase::distribute().

The documentation for this class was generated from the following files:

src/meshTools/mappedPatches/mappedInternalPatchBase/mappedInternalPatchBase.H
src/meshTools/mappedPatches/mappedInternalPatchBase/mappedInternalPatchBase.C
src/meshTools/mappedPatches/mappedInternalPatchBase/mappedInternalPatchBaseI.H
src/meshTools/mappedPatches/mappedInternalPatchBase/mappedInternalPatchBaseTemplates.C

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Member Functions

Protected Attributes

Detailed Description

Member Enumeration Documentation

◆ offsetMode

Constructor & Destructor Documentation

◆ mappedInternalPatchBase() [1/4]

◆ mappedInternalPatchBase() [2/4]

◆ mappedInternalPatchBase() [3/4]

◆ mappedInternalPatchBase() [4/4]

◆ ~mappedInternalPatchBase()

Member Function Documentation

◆ readOffsetMode()

◆ calcMapping()

◆ TypeName()

◆ nbrRegionName()

◆ sameRegion()

◆ map()

◆ cellIndices()

◆ nbrMesh()

◆ samplePoints()

◆ clearOut()

◆ distribute() [1/4]

◆ distribute() [2/4]

◆ specified()

◆ write()

◆ distribute() [3/4]

◆ distribute() [4/4]

Member Data Documentation

◆ offsetModeNames_

◆ patch_

◆ nbrRegionName_

◆ offsetMode_

◆ distance_

◆ offset_

◆ mapPtr_

◆ cellIndices_
