ensightParts Class Reference

A collection of several ensightPart elements. More...

Public Member Functions

 ensightParts (const polyMesh &)
 Construct from polyMesh. More...

 ensightParts (const IOobject &)
 Construct from IOobject. More...

 ensightParts (const ensightParts &)=delete
 Disallow default bitwise copy construction. More...

 ~ensightParts ()
 Destructor. More...

void recalculate (const polyMesh &)
 Clear old information and construct anew from polyMesh. More...

void renumber (const labelUList &origCellId, const labelUList &origFaceId)
 Renumber elements. More...

label size () const
 Number of parts. More...

void writeGeometry (ensightGeoFile &) const
 Write the geometry. More...

bool writeSummary (Ostream &) const
 Write summary information about the objects. More...

void writeData (Ostream &) const
 Write the lists. More...

void writeScalarField (ensightFile &, const List< scalar > &field, const bool useFaceData=false, const bool perNode=false) const
 Write (volume) scalar field. More...

void writeVectorField (ensightFile &, const List< scalar > &field0, const List< scalar > &field1, const List< scalar > &field2, const bool useFaceData=false, const bool perNode=false) const
 Write (volume) vector field components. More...

template<class Type >
void writeField (ensightFile &, const VolField< Type > &) const
 Write generalised volume field components. More...

void operator= (const ensightParts &)=delete
 Disallow default bitwise assignment. More...


Friends

ensightGeoFile & operator<< (ensightGeoFile &, const ensightParts &)
 Write geometry. More...


Detailed Description

A collection of several ensightPart elements.

Source files

Definition at line 59 of file ensightParts.H.

Constructor & Destructor Documentation

◆ ensightParts() [1/3]

ensightParts ( const polyMesh &  mesh)

Construct from polyMesh.

Definition at line 31 of file ensightParts.C.

References mesh, and ensightParts::recalculate().

Here is the call graph for this function:

◆ ensightParts() [2/3]

ensightParts ( const IOobject &  ioObj)

Construct from IOobject.

Definition at line 39 of file ensightParts.C.

◆ ensightParts() [3/3]

ensightParts ( const ensightParts &  )
delete

Disallow default bitwise copy construction.

◆ ~ensightParts()

~ensightParts ( )

Destructor.

Definition at line 50 of file ensightParts.C.

Member Function Documentation

◆ recalculate()

void recalculate ( const polyMesh &  mesh)

Clear old information and construct anew from polyMesh.

Definition at line 56 of file ensightParts.C.

References polyMesh::boundaryMesh(), polyMesh::cellZones(), forAll, mesh, primitiveMesh::nCells(), patchi, PtrList< T >::set(), List< T >::setSize(), UList< T >::size(), UPtrList< T >::size(), and List< T >::size().

Referenced by ensightParts::ensightParts().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ renumber()

void renumber ( const labelUList &  origCellId,
const labelUList &  origFaceId
)

Renumber elements.

Definition at line 164 of file ensightParts.C.

References forAll.

◆ size()

label size ( ) const
inline

Number of parts.

Definition at line 98 of file ensightParts.H.

References UPtrList< T >::size().

Here is the call graph for this function:

◆ writeGeometry()

void writeGeometry ( ensightGeoFile &  os) const

Write the geometry.

Definition at line 184 of file ensightParts.C.

References Foam::flush(), forAll, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ writeSummary()

bool writeSummary ( Ostream &  os) const

Write summary information about the objects.

Definition at line 197 of file ensightParts.C.

References forAll.

◆ writeData()

void writeData ( Ostream &  os) const

Write the lists.

Definition at line 208 of file ensightParts.C.

References token::BEGIN_LIST, IOstream::check(), token::END_LIST, forAll, and Foam::nl.

Here is the call graph for this function:

◆ writeScalarField()

void writeScalarField ( ensightFile &  os,
const List< scalar > &  field,
const bool  useFaceData = false,
const bool  perNode = false
) const

Write (volume) scalar field.

optionally write data for face parts optionally write data per node

Definition at line 228 of file ensightParts.C.

References forAll.

◆ writeVectorField()

void writeVectorField ( ensightFile &  os,
const List< scalar > &  field0,
const List< scalar > &  field1,
const List< scalar > &  field2,
const bool  useFaceData = false,
const bool  perNode = false
) const

Write (volume) vector field components.

optionally write data for face parts optionally write data per node

Definition at line 251 of file ensightParts.C.

References forAll.

◆ writeField()

void writeField ( ensightFile &  os,
const VolField< Type > &  field
) const

Write generalised volume field components.

Definition at line 34 of file ensightPartsTemplates.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), forAll, patchi, and UPtrList< T >::size().

Here is the call graph for this function:

◆ operator=()

void operator= ( const ensightParts &  )
delete

Disallow default bitwise assignment.

Friends And Related Function Documentation

◆ operator<<

ensightGeoFile& operator<< ( ensightGeoFile &  ,
const ensightParts &
)
friend

Write geometry.

The documentation for this class was generated from the following files:
