Model of Laakkonen et al. (2007). The total breakup rate is calculated by. More...

Inheritance diagram for Laakkonen:

Collaboration diagram for Laakkonen:

Public Member Functions
	TypeName ("Laakkonen")
	Runtime type information. More...

	Laakkonen (const populationBalanceModel &popBal, const dictionary &dict)

virtual	~Laakkonen ()
	Destructor. More...

virtual void	setBreakupRate (volScalarField::Internal &breakupRate, const label i)
	Set total breakupRate. More...

Public Member Functions inherited from breakupModel
	TypeName ("breakupModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, breakupModel, dictionary,(const populationBalanceModel &popBal, const dictionary &dict),(popBal, dict))

	breakupModel (const populationBalanceModel &popBal, const dictionary &dict)

autoPtr< breakupModel >	clone () const

virtual	~breakupModel ()
	Destructor. More...

const populationBalanceModel &	popBal () const
	Return reference to the populationBalanceModel. More...

const autoPtr< daughterSizeDistributionModel > &	dsdPtr () const
	Return const-reference to daughter size distribution pointer. More...

autoPtr< daughterSizeDistributionModel > &	dsdPtr ()
	Return reference to daughter size distribution pointer. More...

virtual void	precompute ()
	Precompute diameter independent expressions. More...

Additional Inherited Members
Static Public Member Functions inherited from breakupModel
static autoPtr< breakupModel >	New (const word &type, const populationBalanceModel &popBal, const dictionary &dict)

Protected Attributes inherited from breakupModel
const populationBalanceModel &	popBal_
	Reference to the populationBalanceModel. More...

autoPtr< daughterSizeDistributionModel >	dsd_
	Daughter size distribution model. More...

Detailed Description

Model of Laakkonen et al. (2007). The total breakup rate is calculated by.

$C_1 \epsilon_c^{1/3} \mathrm{erfc} \left( \sqrt { C_2 \frac{\sigma}{\rho_c \epsilon_c^{2/3} (6v_i/\pi)^{5/9}} + C_3 \frac{\mu_c}{\sqrt{\rho_c \rho_d} \epsilon_c^{1/3} (6v_i/\pi)^{4/9}} } \right)$

where

$\sigma$	=	Surface tension [N/m]
	=	Volume of mother bubble i [m3]
$\epsilon_c$	=	Turbulent dissipation rate of continuous phase [m^2/s^3]
$\mu_c$	=	Molecular dynamic viscosity of liquid phase [Pa s]
$\rho_c$	=	Density of continuous phase [kg/m^3]
$\rho_d$	=	Density of disperse phase [kg/m^3]

References:

        Laakkonen, M., Moilanen, P., Alopaeus, V., & Aittamaa, J. (2007).
        Modelling local bubble size distributions in agitated vessels.
        Chemical Engineering Science, 62, 721–740.

Usage

Property	Description	Required	Default value
`C1`	coefficient C1	no	2.25
`C2`	coefficient C2	no	0.04
`C3`	coefficient C3	no	0.01
`daughterSizeDistributionModel`	inh. from breakupModel	inherited

Source files

Definition at line 141 of file Laakkonen.H.

Constructor & Destructor Documentation

◆ Laakkonen()

Laakkonen	(	const populationBalanceModel &	popBal,
		const dictionary &	dict
	)

Definition at line 52 of file Laakkonen.C.

◆ ~Laakkonen()

virtual ~Laakkonen ( )

inlinevirtual

Destructor.

Definition at line 172 of file Laakkonen.H.

Member Function Documentation

◆ TypeName()

TypeName ( "Laakkonen" )

Runtime type information.

◆ setBreakupRate()

void setBreakupRate	(	volScalarField::Internal &	breakupRate,
		const label	i
	)

virtual

Set total breakupRate.

Implements breakupModel.

Definition at line 68 of file Laakkonen.C.

References Foam::cbrt(), sizeGroup::dSph(), Foam::erfc(), sizeGroup::phase(), Foam::pow(), phaseModel::rho(), Foam::constant::physicoChemical::sigma, and Foam::sqrt().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/populationBalance/breakupModels/Laakkonen/Laakkonen.H
applications/modules/multiphaseEuler/populationBalance/breakupModels/Laakkonen/Laakkonen.C
