Public Member Functions | Static Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
cavitationModel Class Referenceabstract
Inheritance diagram for cavitationModel:
Inheritance graph
[legend]
Collaboration diagram for cavitationModel:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("cavitation")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, cavitationModel, dictionary,(const dictionary &dict, const compressibleTwoPhases &phases, const label liquidIndex),(dict, phases, liquidIndex))

 cavitationModel (const dictionary &dict, const compressibleTwoPhases &phases, const label liquidIndex)
 Construct for phases. More...

virtual ~cavitationModel ()
 Destructor. More...

tmp< volScalarField::Internal > pSat1 () const
 Return the saturation vapour pressure for phase 1. More...

tmp< volScalarField::Internal > pSat2 () const
 Return the saturation vapour pressure for phase 2. More...

virtual Pair< tmp< volScalarField::Internal > > mDotcvAlphal () const =0
 Return the mass condensation and vaporisation rates as a. More...

virtual Pair< tmp< volScalarField::Internal > > mDotcvP () const =0
 Return the mass condensation and vaporisation rates as coefficients. More...

Pair< tmp< volScalarField::Internal > > mDot12Alpha () const
 Return the mass transfer rates of the two phases as coefficients to. More...

Pair< tmp< volScalarField::Internal > > mDot12P () const
 Return the mass transfer rates of the two phases as coefficients to. More...

virtual void correct ()=0
 Correct the cavitation model. More...

virtual bool read (const dictionary &dict)=0
 Read the dictionary and update. More...


Static Public Member Functions

static autoPtr< cavitationModel > New (const dictionary &dict, const compressibleTwoPhases &phases, const label liquidIndex=-1)


Protected Member Functions

const volScalarField::Internal & alphal () const
 Return the liquid density. More...

const volScalarField::Internal & alphav () const
 Return the vapour density. More...

const volScalarField::Internal & rhol () const
 Return the liquid density. More...

const volScalarField::Internal & rhov () const
 Return the vapour density. More...

const rhoFluidThermo & thermol () const
 Return the liquid thermo. More...

const rhoFluidThermo & thermov () const
 Return the vapour thermo. More...

tmp< volScalarField::Internal > pSatl () const
 Return the saturation vapour pressure for the liquid. More...

tmp< volScalarField::Internal > pSatv () const
 Return the saturation vapour pressure for the vapour. More...


Protected Attributes

const compressibleTwoPhases & phases_
 Phases. More...

const bool liquidIndex_
 Index of the liquid. More...

autoPtr< saturationPressureModel > saturationModel_
 The saturation pressure model. More...


Detailed Description

Definition at line 53 of file cavitationModel.H.

Constructor & Destructor Documentation

◆ cavitationModel()

cavitationModel ( const dictionary &  dict,
const compressibleTwoPhases &  phases,
const label  liquidIndex
)

Construct for phases.

Definition at line 44 of file cavitationModel.C.

◆ ~cavitationModel()

virtual ~cavitationModel ( )
inlinevirtual

Destructor.

Definition at line 163 of file cavitationModel.H.

Member Function Documentation

◆ alphal()

const volScalarField::Internal& alphal ( ) const
inlineprotected

Return the liquid density.

Definition at line 72 of file cavitationModel.H.

References twoPhases::alpha(), cavitationModel::liquidIndex_, and cavitationModel::phases_.

Here is the call graph for this function:

◆ alphav()

const volScalarField::Internal& alphav ( ) const
inlineprotected

Return the vapour density.

Definition at line 78 of file cavitationModel.H.

References twoPhases::alpha(), cavitationModel::liquidIndex_, and cavitationModel::phases_.

Here is the call graph for this function:

◆ rhol()

const volScalarField::Internal& rhol ( ) const
inlineprotected

Return the liquid density.

Definition at line 84 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::phases_, and compressibleTwoPhases::rho().

Here is the call graph for this function:

◆ rhov()

const volScalarField::Internal& rhov ( ) const
inlineprotected

Return the vapour density.

Definition at line 90 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::phases_, and compressibleTwoPhases::rho().

Here is the call graph for this function:

◆ thermol()

const rhoFluidThermo& thermol ( ) const
inlineprotected

Return the liquid thermo.

Definition at line 96 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::phases_, and compressibleTwoPhases::thermo().

Referenced by cavitationModel::pSatl().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ thermov()

const rhoFluidThermo& thermov ( ) const
inlineprotected

Return the vapour thermo.

Definition at line 102 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::phases_, and compressibleTwoPhases::thermo().

Referenced by cavitationModel::pSatv().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ pSatl()

tmp<volScalarField::Internal> pSatl ( ) const
inlineprotected

Return the saturation vapour pressure for the liquid.

Definition at line 108 of file cavitationModel.H.

References cavitationModel::saturationModel_, Foam::T(), and cavitationModel::thermol().

Referenced by cavitationModel::pSat1(), and cavitationModel::pSat2().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ pSatv()

tmp<volScalarField::Internal> pSatv ( ) const
inlineprotected

Return the saturation vapour pressure for the vapour.

Definition at line 114 of file cavitationModel.H.

References cavitationModel::saturationModel_, Foam::T(), and cavitationModel::thermov().

Referenced by cavitationModel::pSat1(), and cavitationModel::pSat2().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ TypeName()

TypeName ( "cavitation"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
cavitationModel  ,
dictionary  ,
(const dictionary &dict, const compressibleTwoPhases &phases, const label liquidIndex)  ,
(dict, phases, liquidIndex)
)

◆ New()

Foam::autoPtr< Foam::compressible::cavitationModel > New ( const dictionary &  dict,
const compressibleTwoPhases &  phases,
const label  liquidIndex = -1
)
static

Definition at line 31 of file cavitationModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ pSat1()

tmp<volScalarField::Internal> pSat1 ( ) const
inline

Return the saturation vapour pressure for phase 1.

Definition at line 170 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::pSatl(), and cavitationModel::pSatv().

Here is the call graph for this function:

◆ pSat2()

tmp<volScalarField::Internal> pSat2 ( ) const
inline

Return the saturation vapour pressure for phase 2.

Definition at line 176 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::pSatl(), and cavitationModel::pSatv().

Here is the call graph for this function:

◆ mDotcvAlphal()

virtual Pair<tmp<volScalarField::Internal> > mDotcvAlphal ( ) const
pure virtual

Return the mass condensation and vaporisation rates as a.

coefficient to multiply alphav for the condensation rate and a coefficient to multiply alphal for the vaporisation rate

Implemented in SchnerrSauer, Saito, Merkle, and Kunz.

◆ mDotcvP()

virtual Pair<tmp<volScalarField::Internal> > mDotcvP ( ) const
pure virtual

Return the mass condensation and vaporisation rates as coefficients.

to multiply (p - pSat)

Implemented in SchnerrSauer, Saito, Merkle, and Kunz.

◆ mDot12Alpha()

Pair<tmp<volScalarField::Internal> > mDot12Alpha ( ) const
inline

Return the mass transfer rates of the two phases as coefficients to.

multiply the volume fraction of the other phase

Definition at line 192 of file cavitationModel.H.

◆ mDot12P()

Pair<tmp<volScalarField::Internal> > mDot12P ( ) const
inline

Return the mass transfer rates of the two phases as coefficients to.

multiply (p - pSat)

Definition at line 199 of file cavitationModel.H.

◆ correct()

virtual void correct ( )
pure virtual

Correct the cavitation model.

Implemented in SchnerrSauer, Saito, Merkle, and Kunz.

◆ read()

bool read ( const dictionary &  dict)
pure virtual

Read the dictionary and update.

Implemented in SchnerrSauer, Saito, Merkle, and Kunz.

Definition at line 62 of file cavitationModel.C.

References dict, and saturationPressureModel::New().

Referenced by Kunz::read(), Merkle::read(), Saito::read(), and SchnerrSauer::read().

Here is the call graph for this function:
Here is the caller graph for this function:

Member Data Documentation

◆ phases_

const compressibleTwoPhases& phases_
protected

Phases.

Definition at line 60 of file cavitationModel.H.

Referenced by cavitationModel::alphal(), cavitationModel::alphav(), cavitationModel::rhol(), cavitationModel::rhov(), cavitationModel::thermol(), and cavitationModel::thermov().

◆ liquidIndex_

const bool liquidIndex_
protected

Index of the liquid.

Definition at line 63 of file cavitationModel.H.

Referenced by cavitationModel::alphal(), cavitationModel::alphav(), cavitationModel::pSat1(), cavitationModel::pSat2(), cavitationModel::rhol(), cavitationModel::rhov(), cavitationModel::thermol(), and cavitationModel::thermov().

◆ saturationModel_

autoPtr<saturationPressureModel> saturationModel_
protected

The saturation pressure model.

Definition at line 66 of file cavitationModel.H.

Referenced by cavitationModel::pSatl(), and cavitationModel::pSatv().

The documentation for this class was generated from the following files:
