compressibleTwoPhases Class Reference

Inheritance diagram for compressibleTwoPhases:

Collaboration diagram for compressibleTwoPhases:

Public Member Functions
	TypeName ("compressibleTwoPhases")
	Runtime type information. More...
	compressibleTwoPhases ()
	Default construct. More...
virtual	~compressibleTwoPhases ()
	Destructor. More...
virtual const rhoFluidThermo &	thermo1 () const =0
	Return the thermo for phase 1. More...
virtual const rhoFluidThermo &	thermo2 () const =0
	Return the thermo for phase 2. More...
const rhoFluidThermo &	thermo (const bool index) const
	Return the density of a given phase. More...
virtual const volScalarField &	rho1 () const =0
	Return the density of phase 1. More...
virtual const volScalarField &	rho2 () const =0
	Return the density of phase 2. More...
const volScalarField &	rho (const bool index) const
	Return the density of a given phase. More...
Public Member Functions inherited from twoPhases
	TypeName ("twoPhases")
	Runtime type information. More...
	twoPhases ()
	Default construct. More...
virtual	~twoPhases ()
	Destructor. More...
const fvMesh &	mesh () const
	Access the mesh. More...
bool	index (const word &name) const
	Return the index associated with a given phase name. More...
virtual const volScalarField &	alpha1 () const =0
	Return the volume-fraction of phase 1. More...
virtual const volScalarField &	alpha2 () const =0
	Return the volume-fraction of phase 2. More...
const volScalarField &	alpha (const bool index) const
	Return the volume-fraction of a given phase. More...

Detailed Description

Definition at line 49 of file compressibleTwoPhases.H.

Constructor & Destructor Documentation

compressibleTwoPhases()

compressibleTwoPhases ( )

inline

Default construct.

Definition at line 62 of file compressibleTwoPhases.H.

~compressibleTwoPhases()

virtual ~compressibleTwoPhases ( )

inlinevirtual

Destructor.

Definition at line 67 of file compressibleTwoPhases.H.

Member Function Documentation

TypeName()

TypeName

(

"compressibleTwoPhases"

)

Runtime type information.

thermo1()

virtual const rhoFluidThermo& thermo1 ( ) const

pure virtual

Return the thermo for phase 1.

Implemented in phaseInterface, and compressibleTwoPhaseVoFMixture.

Referenced by compressibleTwoPhases::thermo().

Here is the caller graph for this function:

thermo2()

virtual const rhoFluidThermo& thermo2 ( ) const

pure virtual

Return the thermo for phase 2.

Implemented in phaseInterface, and compressibleTwoPhaseVoFMixture.

Referenced by compressibleTwoPhases::thermo().

Here is the caller graph for this function:

thermo()

const rhoFluidThermo& thermo ( const bool  index ) const

inline

Return the density of a given phase.

Definition at line 80 of file compressibleTwoPhases.H.

References twoPhases::index(), compressibleTwoPhases::thermo1(), and compressibleTwoPhases::thermo2().

Referenced by cavitationModel::thermol(), and cavitationModel::thermov().

Here is the call graph for this function:

Here is the caller graph for this function:

rho1()

virtual const volScalarField& rho1 ( ) const

pure virtual

Return the density of phase 1.

Implemented in phaseInterface, and compressibleTwoPhaseVoFMixture.

Referenced by compressibleTwoPhases::rho().

Here is the caller graph for this function:

rho2()

virtual const volScalarField& rho2 ( ) const

pure virtual

Return the density of phase 2.

Implemented in phaseInterface, and compressibleTwoPhaseVoFMixture.

Referenced by compressibleTwoPhases::rho().

Here is the caller graph for this function:

rho()

const volScalarField& rho ( const bool  index ) const

inline

Return the density of a given phase.

Definition at line 92 of file compressibleTwoPhases.H.

References twoPhases::index(), compressibleTwoPhases::rho1(), and compressibleTwoPhases::rho2().

Referenced by cavitationModel::rhol(), and cavitationModel::rhov().

Here is the call graph for this function:

Here is the caller graph for this function:

---

The documentation for this class was generated from the following file:

• src/twoPhaseModels/compressibleTwoPhases/compressibleTwoPhases.H
