Public Member Functions | List of all members
ISAT Class Reference

Implementation of the ISAT (In-situ adaptive tabulation), for chemistry calculation. More...

Inheritance diagram for ISAT:
Inheritance graph
[legend]
Collaboration diagram for ISAT:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("ISAT")
 Runtime type information. More...

 ISAT (const dictionary &chemistryProperties, const odeChemistryModel &chemistry)
 Construct from dictionary. More...

 ISAT (const ISAT &)=delete
 Disallow default bitwise copy construction. More...

virtual ~ISAT ()

virtual bool tabulates ()
 Return true as this tabulation method tabulates. More...

bool reduction () const
 Return true if reduction is applied to the state variables. More...

const odeChemistryModel & chemistry ()

binaryTree & chemisTree ()

const scalarField & scaleFactor () const

label timeSteps () const
 Return the number of chemistry evaluations. More...

virtual void writePerformance ()

virtual bool retrieve (const Foam::scalarField &phiq, scalarField &Rphiq)
 Find the closest stored leaf of phiQ and store the result in. More...

virtual label add (const scalarField &phiq, const scalarField &Rphiq, const label nActive, const label li, const scalar deltaT)
 Add information to the tabulation. More...

virtual void reset ()

virtual bool update ()

- Public Member Functions inherited from chemistryTabulationMethod
 TypeName ("chemistryTabulationMethod")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, chemistryTabulationMethod, dictionary,(const dictionary &dict, const odeChemistryModel &chemistry),(dict, chemistry))

 chemistryTabulationMethod (const dictionary &dict, const odeChemistryModel &chemistry)
 Construct from components. More...

virtual ~chemistryTabulationMethod ()
 Destructor. More...


Additional Inherited Members

- Static Public Member Functions inherited from chemistryTabulationMethod
static autoPtr< chemistryTabulationMethod > New (const IOdictionary &dict, const odeChemistryModel &chemistry)


Detailed Description

Implementation of the ISAT (In-situ adaptive tabulation), for chemistry calculation.

Reference:

    Pope, S. B. (1997).
    Computationally efficient implementation of combustion chemistry using
    in situ adaptive tabulation.
    Combustion Theory and Modelling, 1, 41-63.

Definition at line 60 of file ISAT.H.

Constructor & Destructor Documentation

◆ ISAT() [1/2]

ISAT ( const dictionary &  chemistryProperties,
const odeChemistryModel &  chemistry
)

Construct from dictionary.

Definition at line 150 of file ISAT.C.

◆ ISAT() [2/2]

ISAT ( const ISAT &  )
delete

Disallow default bitwise copy construction.

◆ ~ISAT()

~ISAT ( )
virtual

Definition at line 167 of file ISAT.C.

Member Function Documentation

◆ TypeName()

TypeName ( "ISAT"  )

Runtime type information.

◆ tabulates()

virtual bool tabulates ( )
inlinevirtual

Return true as this tabulation method tabulates.

Implements chemistryTabulationMethod.

Definition at line 244 of file ISAT.H.

◆ reduction()

bool reduction ( ) const
inline

Return true if reduction is applied to the state variables.

Definition at line 250 of file ISAT.H.

Referenced by binaryNode::calcV(), and chemPointISAT::chemPointISAT().

Here is the caller graph for this function:

◆ chemistry()

const odeChemistryModel& chemistry ( )
inline

Definition at line 255 of file ISAT.H.

Referenced by chemPointISAT::chemPointISAT().

Here is the caller graph for this function:

◆ chemisTree()

binaryTree& chemisTree ( )
inline

Definition at line 260 of file ISAT.H.

◆ scaleFactor()

const scalarField& scaleFactor ( ) const
inline

Definition at line 265 of file ISAT.H.

◆ timeSteps()

label timeSteps ( ) const
inline

Return the number of chemistry evaluations.

Definition at line 271 of file ISAT.H.

◆ writePerformance()

void writePerformance ( )
virtual

Definition at line 634 of file ISAT.C.

References Foam::endl().

Here is the call graph for this function:

◆ retrieve()

bool retrieve ( const Foam::scalarField &  phiq,
scalarField &  Rphiq
)
virtual

Find the closest stored leaf of phiQ and store the result in.

RphiQ or return false.

Implements chemistryTabulationMethod.

Definition at line 422 of file ISAT.C.

References Foam::constant::electromagnetic::phi0.

◆ add()

Foam::label add ( const scalarField &  phiq,
const scalarField &  Rphiq,
const label  nActive,
const label  li,
const scalar  deltaT
)
virtual

Add information to the tabulation.

This function can grow an existing point or add a new leaf to the binary tree Input : phiq the new composition to store Rphiq the mapping of the new composition point

Implements chemistryTabulationMethod.

Definition at line 506 of file ISAT.C.

References Foam::saturationModels::A, DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), Foam::deleteDemandDrivenData(), forAll, and Foam::Zero.

Here is the call graph for this function:

◆ reset()

void reset ( )
virtual

Implements chemistryTabulationMethod.

Definition at line 672 of file ISAT.C.

References forAll.

◆ update()

bool update ( )
virtual

Implements chemistryTabulationMethod.

Definition at line 684 of file ISAT.C.

The documentation for this class was generated from the following files:
