Templated break-up model class. More...

Inheritance diagram for BreakupModel< CloudType >:

[legend]

Collaboration diagram for BreakupModel< CloudType >:

Public Member Functions
	TypeName ("breakupModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, BreakupModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))
	Declare runtime constructor selection table. More...

	BreakupModel (CloudType &owner)
	Construct null from owner. More...

	BreakupModel (const dictionary &dict, CloudType &owner, const word &type, bool solveOscillationEq=false)
	Construct from dictionary. More...

	BreakupModel (const BreakupModel< CloudType > &bum)
	Construct copy. More...

virtual autoPtr< BreakupModel< CloudType > >	clone () const =0
	Construct and return a clone. More...

virtual	~BreakupModel ()
	Destructor. More...

const Switch &	solveOscillationEq () const

const scalar &	y0 () const

const scalar &	yDot0 () const

const scalar &	TABComega () const

const scalar &	TABCmu () const

const scalar &	TABtwoWeCrit () const

virtual bool	update (const scalar dt, const vector &g, scalar &d, scalar &tc, scalar &ms, scalar &nParticle, scalar &KHindex, scalar &y, scalar &yDot, const scalar d0, const scalar rho, const scalar mu, const scalar sigma, const vector &U, const scalar rhoc, const scalar muc, const vector &Urel, const scalar Urmag, const scalar tMom, const label injectori, scalar &dChild, scalar &massChild)=0
	Update the parcel properties and return true if a child parcel. More...

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)
	Construct null from owner cloud. More...

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from owner cloud without name. More...

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from owner cloud with name. More...

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)
	Copy constructor. More...

virtual	~CloudSubModelBase ()
	Destructor. More...

const CloudType &	owner () const
	Return const access to the owner cloud. More...

virtual bool	writeTime () const
	Flag to indicate when to write a property. More...

CloudType &	owner ()
	Return non-const access to the owner cloud for manipulation. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)
	Construct null. More...

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from components without name. More...

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from components with name. More...

	subModelBase (const subModelBase &smb)
	Copy constructor. More...

virtual	~subModelBase ()
	Destructor. More...

const word &	modelName () const
	Return const access to the name of the sub-model. More...

const dictionary &	dict () const
	Return const access to the cloud dictionary. More...

const word &	baseName () const
	Return const access to the base name of the sub-model. More...

const word &	modelType () const
	Return const access to the sub-model type. More...

const dictionary &	coeffDict () const
	Return const access to the coefficients dictionary. More...

const dictionary &	properties () const
	Return const access to the properties dictionary. More...

virtual bool	defaultCoeffs (const bool printMsg) const
	Returns true if defaultCoeffs is true and outputs on printMsg. More...

virtual void	cacheFields (const bool store)
	Cache dependent sub-model fields. More...

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the base model. More...

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const
	Retrieve generic property from the base model. More...

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)
	Add generic property to the base model. More...

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const
	Retrieve generic property from the sub-model. More...

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the sub-model. More...

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)
	Add generic property to the sub-model. More...

void	operator= (const subModelBase &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< BreakupModel< CloudType > >	New (const dictionary &dict, CloudType &owner)
	Selector. More...

Protected Attributes
Switch	solveOscillationEq_

scalar	y0_

scalar	yDot0_

scalar	TABComega_

scalar	TABCmu_

scalar	TABtwoWeCrit_

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_
	Reference to the cloud. More...

Protected Attributes inherited from subModelBase
const word	modelName_
	Name of the sub-model. More...

dictionary &	properties_
	Reference to properties dictionary e.g. for restart. More...

const dictionary	dict_
	Copy of dictionary used during construction. More...

const word	baseName_
	Name of the sub-model base class. More...

const word	modelType_
	Type of the sub-model. More...

const dictionary	coeffDict_
	Coefficients dictionary. More...

Additional Inherited Members
Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType
	Type of cloud this model was instantiated for. More...

Protected Member Functions inherited from subModelBase
bool	inLine () const
	Flag to indicate whether data is/was read in-line. More...

Detailed Description

template<class CloudType>
class Foam::BreakupModel< CloudType >

Templated break-up model class.

Source files

Definition at line 52 of file BreakupModel.H.

Constructor & Destructor Documentation

◆ BreakupModel() [1/3]

BreakupModel ( CloudType & owner )

Construct null from owner.

Definition at line 31 of file BreakupModel.C.

◆ BreakupModel() [2/3]

BreakupModel	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	type,
		bool	solveOscillationEq = `false`
	)

Construct from dictionary.

Definition at line 63 of file BreakupModel.C.

References subModelBase::dict(), dictionary::found(), dictionary::lookup(), BreakupModel< CloudType >::solveOscillationEq_, dictionary::subDict(), BreakupModel< CloudType >::TABCmu_, BreakupModel< CloudType >::TABComega_, and BreakupModel< CloudType >::TABtwoWeCrit_.

Here is the call graph for this function:

◆ BreakupModel() [3/3]

BreakupModel ( const BreakupModel< CloudType > & bum )

Construct copy.

Definition at line 47 of file BreakupModel.C.

◆ ~BreakupModel()

~BreakupModel

virtual

Destructor.

Definition at line 93 of file BreakupModel.C.

Member Function Documentation

◆ TypeName()

TypeName ( "breakupModel" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		BreakupModel< CloudType >	,
		dictionary	,
		(const dictionary &dict, CloudType &owner)	,
		(dict, owner)
	)

Declare runtime constructor selection table.

◆ clone()

virtual autoPtr<BreakupModel<CloudType> > clone ( ) const

pure virtual

Construct and return a clone.

Implemented in TAB< CloudType >, SHF< CloudType >, ReitzKHRT< CloudType >, ReitzDiwakar< CloudType >, PilchErdman< CloudType >, NoBreakup< CloudType >, and ETAB< CloudType >.

◆ New()

Foam::autoPtr< Foam::BreakupModel< CloudType > > New	(	const dictionary &	dict,
		CloudType &	owner
	)

static

Selector.

Definition at line 32 of file BreakupModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ solveOscillationEq()

const Switch& solveOscillationEq ( ) const

inline

Definition at line 125 of file BreakupModel.H.

References BreakupModel< CloudType >::solveOscillationEq_.

◆ y0()

const scalar& y0 ( ) const

inline

Definition at line 130 of file BreakupModel.H.

References BreakupModel< CloudType >::y0_.

◆ yDot0()

const scalar& yDot0 ( ) const

inline

Definition at line 135 of file BreakupModel.H.

References BreakupModel< CloudType >::yDot0_.

◆ TABComega()

const scalar& TABComega ( ) const

inline

Definition at line 140 of file BreakupModel.H.

References BreakupModel< CloudType >::TABComega_.

◆ TABCmu()

const scalar& TABCmu ( ) const

inline

Definition at line 145 of file BreakupModel.H.

References BreakupModel< CloudType >::TABCmu_.

◆ TABtwoWeCrit()

const scalar& TABtwoWeCrit ( ) const

inline

Definition at line 150 of file BreakupModel.H.

References BreakupModel< CloudType >::TABtwoWeCrit_.

◆ update()

virtual bool update	(	const scalar	dt,
		const vector &	g,
		scalar &	d,
		scalar &	tc,
		scalar &	ms,
		scalar &	nParticle,
		scalar &	KHindex,
		scalar &	y,
		scalar &	yDot,
		const scalar	d0,
		const scalar	rho,
		const scalar	mu,
		const scalar	sigma,
		const vector &	U,
		const scalar	rhoc,
		const scalar	muc,
		const vector &	Urel,
		const scalar	Urmag,
		const scalar	tMom,
		const label	injectori,
		scalar &	dChild,
		scalar &	massChild
	)

pure virtual

Update the parcel properties and return true if a child parcel.

should be added

Implemented in TAB< CloudType >, SHF< CloudType >, ReitzKHRT< CloudType >, ReitzDiwakar< CloudType >, PilchErdman< CloudType >, NoBreakup< CloudType >, and ETAB< CloudType >.

Member Data Documentation

◆ solveOscillationEq_

Switch solveOscillationEq_

protected

Definition at line 61 of file BreakupModel.H.

Referenced by BreakupModel< CloudType >::BreakupModel(), and BreakupModel< CloudType >::solveOscillationEq().

◆ y0_

scalar y0_

protected

Definition at line 63 of file BreakupModel.H.

Referenced by BreakupModel< CloudType >::y0().

◆ yDot0_

scalar yDot0_

protected

Definition at line 64 of file BreakupModel.H.

Referenced by BreakupModel< CloudType >::yDot0().

◆ TABComega_

scalar TABComega_

protected

Definition at line 66 of file BreakupModel.H.

Referenced by BreakupModel< CloudType >::BreakupModel(), and BreakupModel< CloudType >::TABComega().

◆ TABCmu_

scalar TABCmu_

protected

Definition at line 67 of file BreakupModel.H.

Referenced by BreakupModel< CloudType >::BreakupModel(), and BreakupModel< CloudType >::TABCmu().

◆ TABtwoWeCrit_

scalar TABtwoWeCrit_

protected

Definition at line 68 of file BreakupModel.H.

Referenced by BreakupModel< CloudType >::BreakupModel(), and BreakupModel< CloudType >::TABtwoWeCrit().

The documentation for this class was generated from the following files:

src/lagrangian/parcel/clouds/Templates/SprayCloud/SprayCloud.H
src/lagrangian/parcel/submodels/Spray/BreakupModel/BreakupModel/BreakupModel.H
src/lagrangian/parcel/submodels/Spray/BreakupModel/BreakupModel/BreakupModel.C
src/lagrangian/parcel/submodels/Spray/BreakupModel/BreakupModel/BreakupModelNew.C
