A 'mixed' boundary condition that implements a Marshak condition for the incident radiation field (usually written as G) More...

Inheritance diagram for MarshakRadiationFvPatchScalarField:

[legend]

Collaboration diagram for MarshakRadiationFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("MarshakRadiation")
	Runtime type information. More...

	MarshakRadiationFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	MarshakRadiationFvPatchScalarField (const MarshakRadiationFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping given MarshakRadiationFvPatchField onto a new. More...

	MarshakRadiationFvPatchScalarField (const MarshakRadiationFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	MarshakRadiationFvPatchScalarField (const MarshakRadiationFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

const word &	TName () const
	Return the temperature field name. More...

word &	TName ()
	Return reference to the temperature field name to allow. More...

virtual void	map (const fvPatchScalarField &, const fvPatchFieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...

virtual void	reset (const fvPatchScalarField &)
	Reset the fvPatchField to the given fvPatchField. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

Public Member Functions inherited from radiationCoupledBase
	TypeName ("radiationCoupledBase")
	Runtime type information. More...

	radiationCoupledBase (const fvPatch &patch, const word &calculationMethod, const scalarField &emissivity)
	Construct from patch, emissivity mode and emissivity. More...

	radiationCoupledBase (const fvPatch &patch, const word &calculationMethod, const scalarField &emissivity, const fvPatchFieldMapper &mapper)
	Construct from patch, emissivity mode and emissivity and mapper. More...

	radiationCoupledBase (const fvPatch &patch, const dictionary &dict)
	Construct from patch and dictionary. More...

virtual	~radiationCoupledBase ()
	Destructor. More...

word	emissivityMethod () const
	Method to obtain emissivity. More...

tmp< scalarField >	emissivity () const
	Calculate corresponding emissivity field. More...

void	write (Ostream &) const
	Write. More...

Additional Inherited Members
Public Types inherited from radiationCoupledBase
enum	emissivityMethodType { SOLIDRADIATION , LOOKUP }
	Type of supplied emissivity. More...

Protected Attributes inherited from radiationCoupledBase
const emissivityMethodType	method_
	How to get emissivity. More...

scalarField	emissivity_
	Emissivity. More...

Detailed Description

A 'mixed' boundary condition that implements a Marshak condition for the incident radiation field (usually written as G)

The radiation temperature is retrieved from the mesh database, using a user specified temperature field name.

Usage

Property	Description	Required	Default value
`T`	temperature field name	no	T

Example of the boundary condition specification:

    <patchName>
    {
        type            MarshakRadiation;
        T               T;
        value           uniform 0;
    }

See also: Foam::radiationCoupledBase Foam::mixedFvPatchField

Source files

Definition at line 83 of file MarshakRadiationFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ MarshakRadiationFvPatchScalarField() [1/4]

MarshakRadiationFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 35 of file MarshakRadiationFvPatchScalarField.C.

References dict, fvPatchField< Type >::operator=(), and p.

Referenced by MarshakRadiationFvPatchScalarField::clone().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ MarshakRadiationFvPatchScalarField() [2/4]

MarshakRadiationFvPatchScalarField	(	const MarshakRadiationFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Construct by mapping given MarshakRadiationFvPatchField onto a new.

patch

Definition at line 64 of file MarshakRadiationFvPatchScalarField.C.

◆ MarshakRadiationFvPatchScalarField() [3/4]

MarshakRadiationFvPatchScalarField ( const MarshakRadiationFvPatchScalarField & )

delete

Disallow copy without setting internal field reference.

◆ MarshakRadiationFvPatchScalarField() [4/4]

MarshakRadiationFvPatchScalarField	(	const MarshakRadiationFvPatchScalarField &	ptf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 84 of file MarshakRadiationFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "MarshakRadiation" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 135 of file MarshakRadiationFvPatchScalarField.H.

References MarshakRadiationFvPatchScalarField::MarshakRadiationFvPatchScalarField().

Here is the call graph for this function:

◆ TName() [1/2]

const word& TName ( ) const

inline

Return the temperature field name.

Definition at line 152 of file MarshakRadiationFvPatchScalarField.H.

◆ TName() [2/2]

word& TName ( )

inline

Return reference to the temperature field name to allow.

adjustment

Definition at line 159 of file MarshakRadiationFvPatchScalarField.H.

◆ map()

void map	(	const fvPatchScalarField &	ptf,
		const fvPatchFieldMapper &	mapper
	)

virtual

Map the given fvPatchField onto this fvPatchField.

Reimplemented from radiationCoupledBase.

Definition at line 103 of file MarshakRadiationFvPatchScalarField.C.

References radiationCoupledBase::map().

Here is the call graph for this function:

◆ reset()

void reset ( const fvPatchScalarField & ptf )

virtual

Reset the fvPatchField to the given fvPatchField.

Used for mesh to mesh mapping

Reimplemented from radiationCoupledBase.

Definition at line 114 of file MarshakRadiationFvPatchScalarField.C.

References radiationCoupledBase::reset().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 124 of file MarshakRadiationFvPatchScalarField.C.

References UPstream::msgType(), Foam::pow4(), Foam::constant::physicoChemical::sigma, and dimensioned< Type >::value().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Definition at line 161 of file MarshakRadiationFvPatchScalarField.C.

References radiationCoupledBase::write(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/radiationModels/derivedFvPatchFields/MarshakRadiation/MarshakRadiationFvPatchScalarField.H
src/radiationModels/derivedFvPatchFields/MarshakRadiation/MarshakRadiationFvPatchScalarField.C
