Class to represent a certain side of an interface between phases, where one phase is considered segregated within the other. More...
Public Member Functions | |
TypeName ("segregatedSidedPhaseInterface") | |
Runtime type information. More... | |
segregatedSidedPhaseInterface (const phaseModel &phase, const phaseModel &otherPhase) | |
Construct from phases. More... | |
segregatedSidedPhaseInterface (const phaseSystem &fluid, const word &name) | |
Construct from fluid and name. More... | |
virtual | ~segregatedSidedPhaseInterface () |
Destructor. More... | |
virtual word | name () const |
Name. More... | |
Public Member Functions inherited from segregatedPhaseInterface | |
TypeName ("segregatedPhaseInterface") | |
Runtime type information. More... | |
segregatedPhaseInterface (const phaseModel &phase1, const phaseModel &phase2) | |
Construct from phases. More... | |
segregatedPhaseInterface (const phaseSystem &fluid, const word &name) | |
Construct from fluid and name. More... | |
virtual | ~segregatedPhaseInterface () |
Destructor. More... | |
Public Member Functions inherited from phaseInterface | |
TypeName ("phaseInterface") | |
Runtime type information. More... | |
declareRunTimeSelectionTable (autoPtr, phaseInterface, word,(const phaseSystem &fluid, const word &name),(fluid, name)) | |
phaseInterface (const phaseModel &phase1, const phaseModel &phase2) | |
Construct from phases. More... | |
phaseInterface (const Tuple2< const phaseModel &, const phaseModel & > &phases) | |
Construct from phases. More... | |
phaseInterface (const phaseSystem &fluid, const word &name) | |
Construct from fluid and name. More... | |
phaseInterface (const phaseSystem &fluid, const phaseInterfaceKey &name) | |
Construct from fluid and key. More... | |
virtual autoPtr< phaseInterface > | clone () const |
Clone function. More... | |
virtual | ~phaseInterface () |
Destructor. More... | |
template<class ModelType , class Derived > | |
const Derived & | modelCast () const |
Cast to derived type for use in a model. More... | |
virtual const volScalarField & | alpha1 () const |
Return the volume fraction of phase 1. More... | |
virtual const volScalarField & | alpha2 () const |
Return the volume fraction of phase 2. More... | |
virtual const rhoFluidThermo & | thermo1 () const |
Return the thermo for phase 1. More... | |
virtual const rhoFluidThermo & | thermo2 () const |
Return the thermo for phase 2. More... | |
virtual const volScalarField & | rho1 () const |
Return the density of phase 1. More... | |
virtual const volScalarField & | rho2 () const |
Return the density of phase 2. More... | |
const phaseModel & | phase1 () const |
Return phase 1. More... | |
const phaseModel & | phase2 () const |
Return phase 2. More... | |
bool | contains (const phaseModel &phase) const |
Return true if this phaseInterface contains the given phase. More... | |
const phaseModel & | otherPhase (const phaseModel &phase) const |
Return the other phase relative to the given phase. More... | |
label | index (const phaseModel &phase) const |
Return the index of the given phase. Generates a FatalError if. More... | |
const phaseSystem & | fluid () const |
Return the phase system. More... | |
const fvMesh & | mesh () const |
Return the mesh. More... | |
const uniformDimensionedVectorField & | g () const |
Return gravitational acceleration. More... | |
tmp< volScalarField > | rho () const |
Average density. More... | |
tmp< volScalarField > | magUr () const |
Relative velocity magnitude. More... | |
tmp< volScalarField > | sigma () const |
Surface tension coefficient. More... | |
const_iterator | cbegin () const |
const_iterator set to the beginning of the pair More... | |
const_iterator | cend () const |
const_iterator set to beyond the end of the pair More... | |
const_iterator | begin () const |
const_iterator set to the beginning of the pair More... | |
const_iterator | end () const |
const_iterator set to beyond the end of the pair More... | |
Public Member Functions inherited from compressibleTwoPhases | |
TypeName ("compressibleTwoPhases") | |
Runtime type information. More... | |
compressibleTwoPhases () | |
Default construct. More... | |
virtual | ~compressibleTwoPhases () |
Destructor. More... | |
const rhoFluidThermo & | thermo (const bool index) const |
Return the density of a given phase. More... | |
const volScalarField & | rho (const bool index) const |
Return the density of a given phase. More... | |
Public Member Functions inherited from twoPhases | |
TypeName ("twoPhases") | |
Runtime type information. More... | |
twoPhases () | |
Default construct. More... | |
virtual | ~twoPhases () |
Destructor. More... | |
const fvMesh & | mesh () const |
Access the mesh. More... | |
bool | index (const word &name) const |
Return the index associated with a given phase name. More... | |
const volScalarField & | alpha (const bool index) const |
Return the volume-fraction of a given phase. More... | |
Public Member Functions inherited from sidedPhaseInterface | |
TypeName ("sidedPhaseInterface") | |
Runtime type information. More... | |
sidedPhaseInterface (const phaseModel &phase, const phaseModel &otherPhase) | |
Construct from phases. More... | |
sidedPhaseInterface (const phaseSystem &fluid, const word &name) | |
Construct from fluid and name. More... | |
virtual | ~sidedPhaseInterface () |
Destructor. More... | |
const phaseModel & | phase () const |
Phase on the this side of the interface. More... | |
const phaseModel & | otherPhase () const |
Phase on the other side of the interface. More... | |
autoPtr< phaseInterface > | otherInterface () const |
Interface on the other side of the interface. More... | |
Additional Inherited Members | |
Static Public Member Functions inherited from segregatedPhaseInterface | |
static word | separator () |
Return the separator that delimits this interface's name. More... | |
Static Public Member Functions inherited from phaseInterface | |
static const phaseModel & | getPhase1 (const phaseModel &phase1, const phaseModel &phase2) |
Get a reference to phase1 after sorting the phases by index. More... | |
static const phaseModel & | getPhase2 (const phaseModel &phase1, const phaseModel &phase2) |
Get a reference to phase2 after sorting the phases by index. More... | |
static bool | addHeadSeparator (const word &separator) |
Add a head separator to the list. More... | |
static bool | addOldSeparatorToSeparator (const word &oldSeparator, const word &separator) |
Add a old separator to separator to the table. More... | |
static wordList | nameToNameParts (const phaseSystem &fluid, const word &name) |
Split an interface name and return all its parts. More... | |
static wordList | nameToSeparators (const phaseSystem &fluid, const word &name) |
Split an interface name and return its separators. More... | |
static word | separatorsToTypeName (const wordList &separators) |
Convert a list of separators into a type name. More... | |
static word | nameToTypeName (const phaseSystem &fluid, const word &name) |
Convert an interface name into a type name. Essentially just. More... | |
static word | namePartsToName (const phaseSystem &fluid, const wordList &nameParts) |
Convert interface name parts to an interface name. More... | |
static word | oldNamePartsToName (const phaseSystem &fluid, const wordList &oldNameParts) |
Convert old-format interface name parts to an interface name. Used. More... | |
static Tuple2< const phaseModel &, const phaseModel & > | identifyPhases (const phaseSystem &fluid, const word &name, const wordList &separators) |
Return references to the phases associated with a given name, and a. More... | |
static autoPtr< phaseInterface > | New (const phaseSystem &fluid, const word &name) |
Select given fluid and name. More... | |
static autoPtr< phaseInterface > | New (const phaseInterface &interface1, const phaseInterface &interface2) |
Select by combining two interfaces. More... | |
static word | separator () |
Return the separator that delimits this interface's name. More... | |
Static Public Member Functions inherited from sidedPhaseInterface | |
static word | separator () |
Return the separator that delimits this interface's name. More... | |
Class to represent a certain side of an interface between phases, where one phase is considered segregated within the other.
Definition at line 50 of file segregatedSidedPhaseInterface.H.
segregatedSidedPhaseInterface | ( | const phaseModel & | phase, |
const phaseModel & | otherPhase | ||
) |
Construct from phases.
Definition at line 54 of file segregatedSidedPhaseInterface.C.
segregatedSidedPhaseInterface | ( | const phaseSystem & | fluid, |
const word & | name | ||
) |
Construct from fluid and name.
Definition at line 66 of file segregatedSidedPhaseInterface.C.
|
virtual |
Destructor.
Definition at line 80 of file segregatedSidedPhaseInterface.C.
TypeName | ( | "segregatedSidedPhaseInterface" | ) |
Runtime type information.
|
virtual |
Name.
Reimplemented from segregatedPhaseInterface.
Definition at line 86 of file segregatedSidedPhaseInterface.C.
References segregatedPhaseInterface::name(), and sidedPhaseInterface::separator().
