Set of locations to sample. More...

Inheritance diagram for probes:

Collaboration diagram for probes:

[legend]

Classes
class	fieldGroup
	Class used for grouping field types. More...

Public Member Functions
	TypeName ("probes")
	Runtime type information. More...

	probes (const word &name, const Time &time, const dictionary &dict, const bool initialise=true)
	Construct from Time and dictionary. More...

	probes (const probes &)=delete
	Disallow default bitwise copy construction. More...

virtual	~probes ()
	Destructor. More...

virtual wordList	fields () const
	Return the list of fields required. More...

bool	read (const dictionary &, const bool initialise)
	Read the probes. More...

virtual bool	read (const dictionary &)
	Read the probes. More...

virtual bool	execute ()
	Execute, currently does nothing. More...

virtual bool	write ()
	Sample and write. More...

virtual void	movePoints (const polyMesh &)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Update using the given distribution map. More...

void	operator= (const probes &)=delete
	Disallow default bitwise assignment. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	sample (const VolField< Type > &vField) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	sample (const SurfaceField< Type > &sField) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	sample (const word &fieldName) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleSurfaceFields (const word &fieldName) const

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
void	clearFieldGroups ()
	Clear old field groups. More...

label	appendFieldGroup (const word &fieldName, const word &fieldType)
	Append fieldName to the appropriate group. More...

label	classifyFields ()
	Classify field types, returns the number of fields. More...

virtual void	findElements (const fvMesh &)
	Find cells and faces containing probes. More...

label	prepare ()
	Classify field type and Open/close file streams,. More...

Protected Attributes
const fvMesh &	mesh_
	Const reference to fvMesh. More...

pointField	locations_
	Probe locations. More...

wordList	fields_
	Names of fields to probe. More...

bool	fixedLocations_
	Fixed locations, default = yes. More...

word	interpolationScheme_
	Interpolation scheme name. More...

fieldGroup< scalar >	scalarFields_
	Categorised scalar/vector/tensor vol fields. More...

fieldGroup< vector >	vectorFields_

fieldGroup< sphericalTensor >	sphericalTensorFields_

fieldGroup< symmTensor >	symmTensorFields_

fieldGroup< tensor >	tensorFields_

fieldGroup< scalar >	surfaceScalarFields_
	Categorised scalar/vector/tensor surf fields. More...

fieldGroup< vector >	surfaceVectorFields_

fieldGroup< sphericalTensor >	surfaceSphericalTensorFields_

fieldGroup< symmTensor >	surfaceSymmTensorFields_

fieldGroup< tensor >	surfaceTensorFields_

labelList	cellList_

labelList	faceList_

HashPtrTable< OFstream >	probeFilePtrs_
	Current open files. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Detailed Description

Set of locations to sample.

Call write() to sample and write files.

Source files

Definition at line 63 of file probes.H.

Constructor & Destructor Documentation

◆ probes() [1/2]

probes	(	const word &	name,
		const Time &	time,
		const dictionary &	dict,
		const bool	initialise = `true`
	)

Construct from Time and dictionary.

Definition at line 261 of file probes.C.

References dict, and probes::read().

Here is the call graph for this function:

◆ probes() [2/2]

probes ( const probes & )

delete

Disallow default bitwise copy construction.

◆ ~probes()

~probes ( )

virtual

Destructor.

Definition at line 290 of file probes.C.

Member Function Documentation

◆ clearFieldGroups()

void clearFieldGroups ( )

protected

Clear old field groups.

Definition at line 34 of file probesGrouping.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::clear(), probes::scalarFields_, probes::sphericalTensorFields_, probes::surfaceScalarFields_, probes::surfaceSphericalTensorFields_, probes::surfaceSymmTensorFields_, probes::surfaceTensorFields_, probes::surfaceVectorFields_, probes::symmTensorFields_, probes::tensorFields_, and probes::vectorFields_.

Here is the call graph for this function:

◆ appendFieldGroup()

Foam::label appendFieldGroup	(	const word &	fieldName,
		const word &	fieldType
	)

protected

Append fieldName to the appropriate group.

Definition at line 50 of file probesGrouping.C.

References Foam::typeName().

Here is the call graph for this function:

◆ classifyFields()

Foam::label classifyFields ( )

protected

Classify field types, returns the number of fields.

Definition at line 111 of file probesGrouping.C.

References forAll.

◆ findElements()

void findElements ( const fvMesh & mesh )

protectedvirtual

Find cells and faces containing probes.

Definition at line 53 of file probes.C.

References primitiveMesh::cellCentres(), probes::cellList_, primitiveMesh::cells(), List< T >::clear(), Foam::endl(), primitiveMesh::faceCentres(), probes::faceList_, meshSearch::findCell(), forAll, Foam::Info, probes::locations_, Foam::mag(), UPstream::master(), mesh, probes::mesh_, UPstream::myProcNo(), meshSearch::New(), Foam::Pout, Foam::reduce(), List< T >::setSize(), List< T >::size(), and WarningInFunction.

Here is the call graph for this function:

◆ prepare()

Foam::label prepare ( )

protected

Classify field type and Open/close file streams,.

returns number of fields to sample

Definition at line 170 of file probes.C.

References IOstream::defaultPrecision(), polyMesh::defaultRegion, Foam::endl(), HashTable< T, Key, Hash >::erase(), forAll, forAllConstIter, forAllIter, Foam::Info, HashSet< Key, Hash >::insert(), UPstream::master(), Foam::mkDir(), OFstream::name(), Foam::name(), Foam::nl, writeFile::outputPrefix, Foam::setf(), and Foam::setw().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "probes" )

Runtime type information.

◆ fields()

Foam::wordList fields ( ) const

virtual

Return the list of fields required.

Implements functionObject.

Definition at line 332 of file probes.C.

◆ read() [1/2]

bool read	(	const dictionary &	dict,
		const bool	initialise
	)

Read the probes.

Definition at line 296 of file probes.C.

References dict, dictionary::lookup(), dictionary::readIfPresent(), and WarningInFunction.

Referenced by probes::probes(), and patchProbes::read().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ read() [2/2]

bool read ( const dictionary & dict )

virtual

Read the probes.

Reimplemented from functionObject.

Reimplemented in patchProbes.

Definition at line 326 of file probes.C.

References dict, and Foam::read().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Execute, currently does nothing.

Implements functionObject.

Definition at line 338 of file probes.C.

◆ write()

bool write ( )

virtual

Sample and write.

Implements functionObject.

Reimplemented in patchProbes.

Definition at line 344 of file probes.C.

◆ movePoints()

void movePoints ( const polyMesh & mesh )

virtual

Update topology using the given map.

Reimplemented from functionObject.

Definition at line 365 of file probes.C.

References DebugInfo, Foam::endl(), and mesh.

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update topology using the given map.

Reimplemented from functionObject.

Definition at line 378 of file probes.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), DebugInfo, UList< T >::empty(), Foam::endl(), forAll, Foam::Info, polyTopoChangeMap::mesh(), polyTopoChangeMap::reverseCellMap(), and polyTopoChangeMap::reverseFaceMap().

Here is the call graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Reimplemented from functionObject.

Definition at line 458 of file probes.C.

References DebugInfo, Foam::endl(), and polyMeshMap::mesh().

Here is the call graph for this function:

◆ distribute()

void distribute ( const polyDistributionMap & map )

virtual

Update using the given distribution map.

Reimplemented from functionObject.

Definition at line 468 of file probes.C.

References polyDistributionMap::cellMap(), DebugInfo, Foam::endl(), polyDistributionMap::faceMap(), forAll, polyDistributionMap::mesh(), polyDistributionMap::nOldCells(), and polyDistributionMap::nOldFaces().

Here is the call graph for this function:

◆ operator=()

void operator= ( const probes & )

delete

Disallow default bitwise assignment.

◆ sample() [1/3]

Foam::tmp<Foam::Field<Type> > sample ( const VolField< Type > & vField ) const

Definition at line 164 of file probesTemplates.C.

References forAll, Pstream::listCombineGather(), Pstream::listCombineScatter(), Foam::tracking::position(), and tmp< T >::ref().

Here is the call graph for this function:

◆ sample() [2/3]

Foam::tmp<Foam::Field<Type> > sample ( const SurfaceField< Type > & sField ) const

Definition at line 217 of file probesTemplates.C.

References forAll, Pstream::listCombineGather(), Pstream::listCombineScatter(), and tmp< T >::ref().

Here is the call graph for this function:

◆ sample() [3/3]

Foam::tmp<Foam::Field<Type> > sample ( const word & fieldName ) const

Definition at line 245 of file probesTemplates.C.

◆ sampleSurfaceFields()

Foam::tmp<Foam::Field<Type> > sampleSurfaceFields ( const word & fieldName ) const

Definition at line 259 of file probesTemplates.C.

Member Data Documentation

◆ mesh_

const fvMesh& mesh_

protected

Const reference to fvMesh.

Definition at line 90 of file probes.H.

Referenced by probes::findElements().

◆ locations_

pointField locations_

protected

Probe locations.

Definition at line 96 of file probes.H.

Referenced by probes::findElements().

◆ fields_

wordList fields_

protected

Names of fields to probe.

Definition at line 99 of file probes.H.

◆ fixedLocations_

bool fixedLocations_

protected

Fixed locations, default = yes.

Note: set to false for moving mesh calculations where locations should move with the mesh

Definition at line 104 of file probes.H.

◆ interpolationScheme_

word interpolationScheme_

protected

Interpolation scheme name.

Note: only possible when fixedLocations_ is true

Definition at line 108 of file probes.H.

◆ scalarFields_

fieldGroup<scalar> scalarFields_

protected

Categorised scalar/vector/tensor vol fields.

Definition at line 114 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ vectorFields_

fieldGroup<vector> vectorFields_

protected

Definition at line 115 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ sphericalTensorFields_

fieldGroup<sphericalTensor> sphericalTensorFields_

protected

Definition at line 116 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ symmTensorFields_

fieldGroup<symmTensor> symmTensorFields_

protected

Definition at line 117 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ tensorFields_

fieldGroup<tensor> tensorFields_

protected

Definition at line 118 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ surfaceScalarFields_

fieldGroup<scalar> surfaceScalarFields_

protected

Categorised scalar/vector/tensor surf fields.

Definition at line 121 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ surfaceVectorFields_

fieldGroup<vector> surfaceVectorFields_

protected

Definition at line 122 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ surfaceSphericalTensorFields_

fieldGroup<sphericalTensor> surfaceSphericalTensorFields_

protected

Definition at line 123 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ surfaceSymmTensorFields_

fieldGroup<symmTensor> surfaceSymmTensorFields_

protected

Definition at line 124 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ surfaceTensorFields_

fieldGroup<tensor> surfaceTensorFields_

protected

Definition at line 125 of file probes.H.

Referenced by probes::clearFieldGroups().

◆ cellList_

labelList cellList_

protected

Definition at line 128 of file probes.H.

Referenced by probes::findElements().

◆ faceList_

labelList faceList_

protected

Definition at line 131 of file probes.H.

Referenced by probes::findElements().

◆ probeFilePtrs_

HashPtrTable<OFstream> probeFilePtrs_

protected

Current open files.

Definition at line 134 of file probes.H.

The documentation for this class was generated from the following files:

src/sampling/probes/probes.H
src/sampling/probes/probes.C
src/sampling/probes/probesGrouping.C
src/sampling/probes/probesTemplates.C

Classes

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ probes() [1/2]

◆ probes() [2/2]

◆ ~probes()

Member Function Documentation

◆ clearFieldGroups()

◆ appendFieldGroup()

◆ classifyFields()

◆ findElements()

◆ prepare()

◆ TypeName()

◆ fields()

◆ read() [1/2]

◆ read() [2/2]

◆ execute()

◆ write()

◆ movePoints()

◆ topoChange()

◆ mapMesh()

◆ distribute()

◆ operator=()

◆ sample() [1/3]

◆ sample() [2/3]

◆ sample() [3/3]

◆ sampleSurfaceFields()

Member Data Documentation

◆ mesh_

◆ locations_

◆ fields_

◆ fixedLocations_

◆ interpolationScheme_

◆ scalarFields_

◆ vectorFields_

◆ sphericalTensorFields_

◆ symmTensorFields_

◆ tensorFields_

◆ surfaceScalarFields_

◆ surfaceVectorFields_

◆ surfaceSphericalTensorFields_

◆ surfaceSymmTensorFields_

◆ surfaceTensorFields_

◆ cellList_

◆ faceList_

◆ probeFilePtrs_
