Class for modelling the shape of particle aggregates using the concept of fractal geometry. Returns a collisional diameter. More...

Inheritance diagram for fractal:

[legend]

Collaboration diagram for fractal:

[legend]

Public Member Functions
	TypeName ("fractal")
	Runtime type information. More...

	fractal (const dictionary &dict, const populationBalanceModel &popBal)
	Construct from a dictionary. More...

	fractal (const fractal &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fractal ()
	Destructor. More...

dimensionedScalar	Df (const label i) const
	Return the fractal dimension for a group. More...

dimensionedScalar	alphaC (const label i) const
	Return the scaling prefactor for a group. More...

virtual const volScalarField &	fld (const label i) const
	Return a reference to a secondary property field. More...

virtual volScalarField::Internal &	src (const label i)
	Access a secondary property source. More...

virtual tmp< volScalarField >	a (const label i) const
	Return the representative surface area of a group. More...

virtual tmp< volScalarField >	d (const label i) const
	Return the representative diameter of a group. More...

virtual void	solve ()
	Solve equations. More...

virtual void	correct ()
	Correct the shape. More...

void	operator= (const fractal &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from SecondaryPropertyModel< shapeModel >
virtual const word &	type () const=0
	Runtime type information. More...

	SecondaryPropertyModel (const populationBalanceModel &popBal)
	Construct from a population balance model. More...

	SecondaryPropertyModel (const SecondaryPropertyModel< shapeModel > &)=delete
	Disallow default bitwise copy construction. More...

virtual	~SecondaryPropertyModel ()
	Destructor. More...

virtual void	addCoalescence (const volScalarField::Internal &Su, const label i, const label j, const label k)
	Add coalescence contribution to secondary property source. More...

virtual void	addBreakup (const volScalarField::Internal &Su, const label i, const label j)
	Add breakup contribution to secondary property source. More...

virtual void	reset ()
	Reset secondary property source. More...

void	operator= (const SecondaryPropertyModel< shapeModel > &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from shapeModel
	TypeName ("shapeModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, shapeModel, dictionary,(const dictionary &dict, const populationBalanceModel &popBal),(dict, popBal))

	shapeModel (const populationBalanceModel &popBal)
	Construct from a population balance model. More...

	shapeModel (const shapeModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~shapeModel ()
	Destructor. More...

const populationBalanceModel &	popBal () const
	Return reference to the population balance model. More...

void	operator= (const shapeModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from shapeModel
static autoPtr< shapeModel >	New (const dictionary &dict, const populationBalanceModel &popBal)

Protected Attributes inherited from shapeModel
const populationBalanceModel &	popBal_
	Reference to the population balance model. More...

Detailed Description

Class for modelling the shape of particle aggregates using the concept of fractal geometry. Returns a collisional diameter.

$d_{c_i} = \frac{6}{\kappa_i} \left( \frac{v_i \kappa_i^3}{36 \pi \alpha_c} \right)^{1/D_{f_i}}\,,$

computed from a constant fractal dimension $D_{f_i}$ and a field-dependent surface area to volume ratio $\kappa_i$ , assuming that the primary particles in an aggregate have the same size.

Usage

Property	Description	Required	Default value
`Df`	Fractal dimension	yes
`alphaC`	Scaling prefactor	yes

See also: Foam::populationBalance::shapeModel

Source files

Definition at line 91 of file fractal.H.

Constructor & Destructor Documentation

◆ fractal() [1/2]

fractal	(	const dictionary &	dict,
		const populationBalanceModel &	popBal
	)

Construct from a dictionary.

Definition at line 77 of file fractal.C.

References Foam::dimLength, and Foam::dimless.

◆ fractal() [2/2]

fractal ( const fractal & )

delete

Disallow default bitwise copy construction.

◆ ~fractal()

~fractal ( )

virtual

Destructor.

Definition at line 150 of file fractal.C.

Member Function Documentation

◆ TypeName()

TypeName ( "fractal" )

Runtime type information.

◆ Df()

Foam::dimensionedScalar Df ( const label i ) const

Return the fractal dimension for a group.

Definition at line 157 of file fractal.C.

References Foam::dimless, and Foam::name().

Referenced by ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ alphaC()

Foam::dimensionedScalar alphaC ( const label i ) const

Return the scaling prefactor for a group.

Definition at line 170 of file fractal.C.

References Foam::dimless, and Foam::name().

Referenced by ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fld()

const Foam::volScalarField & fld ( const label i ) const

virtual

Return a reference to a secondary property field.

Implements SecondaryPropertyModel< shapeModel >.

Definition at line 183 of file fractal.C.

Referenced by KochFriedlanderSintering::KochFriedlanderSintering(), hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource::value(), and ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the caller graph for this function:

◆ src()

Foam::volScalarField::Internal & src ( const label i )

virtual

Access a secondary property source.

Implements SecondaryPropertyModel< shapeModel >.

Definition at line 190 of file fractal.C.

◆ a()

Foam::tmp< Foam::volScalarField > a ( const label i ) const

virtual

Return the representative surface area of a group.

Implements shapeModel.

Definition at line 275 of file fractal.C.

◆ d()

Foam::tmp< Foam::volScalarField > d ( const label i ) const

virtual

Return the representative diameter of a group.

Implements shapeModel.

Definition at line 282 of file fractal.C.

Referenced by ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the caller graph for this function:

◆ solve()

void solve ( )

virtual

Solve equations.

Reimplemented from shapeModel.

Definition at line 196 of file fractal.C.

References alpha(), phaseModel::alphaPhi(), word::capitalise(), Foam::correction(), Foam::fvm::ddt(), Foam::fvm::div(), forAll, IOobject::groupName(), Foam::fvc::interpolate(), Foam::max(), IOobject::member(), mesh, Foam::min(), fvMatrix< Type >::relax(), phaseModel::residualAlpha(), rho, fvMatrix< Type >::solve(), Foam::fvm::Sp(), and Foam::dimensions::time.

Here is the call graph for this function:

◆ correct()

void correct ( )

virtual

Correct the shape.

Reimplemented from shapeModel.

Definition at line 264 of file fractal.C.

References forAll.

◆ operator=()

void operator= ( const fractal & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/populationBalance/shapeModels/fractal/fractal.H
applications/modules/multiphaseEuler/populationBalance/shapeModels/fractal/fractal.C
