Gaussian profile time dependent rate ignition model for the Weller b-Xi combustion model. More...

Inheritance diagram for GaussianbXiIgnition:

Collaboration diagram for GaussianbXiIgnition:

[legend]

Public Member Functions
	TypeName ("GaussianbXiIgnition")
	Runtime type information. More...

	GaussianbXiIgnition (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from explicit source name and mesh. More...

	GaussianbXiIgnition (const GaussianbXiIgnition &)=delete
	Disallow default bitwise copy construction. More...

virtual void	addSup (const volScalarField &rho, const volScalarField &b, fvMatrix< scalar > &eqn) const
	Add ignition contribution to b equation. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	movePoints ()
	Update for mesh motion. More...

virtual bool	read (const dictionary &dict)
	Read source dictionary. More...

void	operator= (const GaussianbXiIgnition &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from bXiTimedIgnition
	TypeName ("bXiTimedIgnition")
	Runtime type information. More...

	bXiTimedIgnition (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from explicit source name and mesh. More...

	bXiTimedIgnition (const bXiTimedIgnition &)=delete
	Disallow default bitwise copy construction. More...

virtual wordList	addSupFields () const
	Return the list of fields for which the option adds source term. More...

virtual bool	igniting (const dimensionedScalar duration) const
	Return true during the specified ignition duration. More...

virtual bool	igniting () const
	Return true during the ignition duration. More...

virtual bool	ignited () const
	Return true during the combustion duration. More...

void	operator= (const bXiTimedIgnition &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from bXiIgnition
	TypeName ("bXiIgnition")
	Runtime type information. More...

	bXiIgnition (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from explicit source name and mesh. More...

	bXiIgnition (const bXiIgnition &)=delete
	Disallow default bitwise copy construction. More...

void	operator= (const bXiIgnition &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvModel
	TypeName ("fvModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvModel, dictionary,(const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict),(name, modelType, mesh, dict))

	fvModel (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

autoPtr< fvModel >	clone () const
	Return clone. More...

virtual	~fvModel ()
	Destructor. More...

const word &	name () const
	Return const access to the source name. More...

const word &	keyword () const
	Return name as the keyword. More...

const fvMesh &	mesh () const
	Return const access to the mesh database. More...

const dictionary &	coeffs (const dictionary &) const
	Return the coefficients sub-dictionary. More...

virtual bool	addsSupToField (const word &fieldName) const
	Return true if the fvModel adds a source term to the given. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	addSup (fvMatrix< scalar > &eqn) const
	Add a source term to a field-less proxy equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const VolField< Type > &eqnField) const
	Add a source term to an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const VolField< Type > &field) const
	Return source for an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const VolField< Type > &field, const VolField< Type > &eqnField) const
	Return source for an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &rho, const VolField< Type > &field) const
	Return source for a compressible equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const
	Return source for a compressible equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &alpha, const geometricOneField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const geometricOneField &alpha, const volScalarField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const geometricOneField &alpha, const geometricOneField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	d2dt2 (const VolField< Type > &field) const
	Return source for an equation with a second time derivative. More...

virtual void	preUpdateMesh ()
	Prepare for mesh update. More...

virtual void	correct ()
	Correct the fvModel. More...

virtual bool	write (const bool write=true) const
	Write fvModel data. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::dimensionSet	sourceDims (const dimensionSet &ds, const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
const Foam::word &	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
const Foam::word &	fieldName (const AlphaRhoFieldType &alphaRhoField)

template<class Type , class ... AlphaRhoFieldTypes>
Foam::tmp< Foam::fvMatrix< Type > >	sourceTerm (const VolField< Type > &eqnField, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhoFields) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const VolField< Type > &field, const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const geometricOneField &alpha, const geometricOneField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &alpha, const geometricOneField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const geometricOneField &alpha, const volScalarField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	d2dt2 (const VolField< Type > &field) const

Protected Attributes
fvCellZone	zone_
	The ignition cellZone. More...

autoPtr< kernelShape >	kernelShape_

dimensionedVector	position_

dimensionedScalar	diameter_

autoPtr< Function1< scalar > >	rate_
	Ignition burning rate [1/t]. More...

scalarList	Vk_
	Kernel volume correction factor. More...

Protected Attributes inherited from bXiTimedIgnition
dimensionedScalar	start_
	Ignition start time. More...

dimensionedScalar	duration_
	Ignition duration. More...

dimensionedScalar	period_
	Ignition repeat period. More...

dimensionedScalar	combustionDuration_
	Combustion duration. More...

bool	reset_
	Set true when the composition is reset. More...

Protected Attributes inherited from bXiIgnition
const solvers::XiFluid &	XiFluid_
	The XiFluid solver. More...

Additional Inherited Members
Static Public Member Functions inherited from fvModel
static const dictionary &	coeffs (const word &modelType, const dictionary &)
	Return the coefficients sub-dictionary for a given model type. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static dimensionSet	sourceDims (const dimensionSet &ds, const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the dimensions of the matrix of a source term. More...

static const dimensionSet &	sourceDims (const dimensionSet &ds)
	Return the dimensions of the matrix of a source term (base. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static const word &	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the field associated with a source term. More...

template<class AlphaRhoFieldType >
static const word &	fieldName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the field associated with a source term (base. More...

static const word &	fieldName ()
	Return the name of the field associated with a source term. Special. More...

static autoPtr< fvModel >	New (const word &name, const fvMesh &mesh, const dictionary &dict)
	Return a reference to the selected fvModel. More...

Static Public Attributes inherited from fvModel
static const wordHashSet	keywords
	The keywords read by this class. More...

Protected Member Functions inherited from bXiTimedIgnition
scalar	ignRelTime (const scalar t) const
	Return the time relative to the ignition time. More...

Protected Member Functions inherited from fvModel
template<class Type >
void	addSupType (const VolField< Type > &field, fvMatrix< Type > &eqn) const
	Add a source term to an equation. More...

template<class Type >
void	addSupType (const volScalarField &rho, const VolField< Type > &field, fvMatrix< Type > &eqn) const
	Add a source term to a compressible equation. More...

template<class Type >
void	addSupType (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field, fvMatrix< Type > &eqn) const
	Add a source term to a phase equation. More...

template<class Type , class ... AlphaRhoFieldTypes>
tmp< fvMatrix< Type > >	sourceTerm (const VolField< Type > &eqnField, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhoFields) const
	Return a source for an equation. More...

Detailed Description

Gaussian profile time dependent rate ignition model for the Weller b-Xi combustion model.

Usage

Example usage:

GaussianbXiIgnition1
{
    type            GaussianbXiIgnition;

    cellZone        ignition;

    position        (0 0 0);
    diameter        1e-3;

    kernelShape
    {
        type            spherical;
    }

    start           0;
    duration        0.003;
    rate            1e3;
}

Where:

Property	Description	Required
`cellZone`	Correction cellZone	yes
`position`	Ignition centre	yes
`diameter`	Diameter of the ignition kernel	yes
`kernelShape`	Kernel shape	yes
`start`	Ignition start time	yes
`duration`	Ignition duration	yes
`rate`	Burning rate coefficient Function1 of time [1/s]	yes

See also: Foam::fv::constantbXiIgnition Foam::fv::bXiKernelCorr Foam::kernelShape Foam::kernelShapes::planar Foam::kernelShapes::cylindrical Foam::kernelShapes::spherical

Source files

Definition at line 136 of file GaussianbXiIgnition.H.

Constructor & Destructor Documentation

◆ GaussianbXiIgnition() [1/2]

GaussianbXiIgnition	(	const word &	name,
		const word &	modelType,
		const fvMesh &	mesh,
		const dictionary &	dict
	)

Construct from explicit source name and mesh.

Definition at line 102 of file GaussianbXiIgnition.C.

References fvModel::coeffs(), and dict.

Here is the call graph for this function:

◆ GaussianbXiIgnition() [2/2]

GaussianbXiIgnition ( const GaussianbXiIgnition & )

delete

Disallow default bitwise copy construction.

Member Function Documentation

◆ TypeName()

TypeName ( "GaussianbXiIgnition" )

Runtime type information.

◆ addSup()

void addSup	(	const volScalarField &	rho,
		const volScalarField &	b,
		fvMatrix< scalar > &	eqn
	)		const

virtual

Add ignition contribution to b equation.

Definition at line 122 of file GaussianbXiIgnition.C.

References cells, lduMatrix::diag(), Foam::endl(), forAll, Foam::Info, mesh, fvMatrix< Type >::psi(), Foam::dimensions::rate, rho, Foam::fvc::Sp(), Foam::dimensions::time, and Foam::type().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update topology using the given map.

Implements fvModel.

Definition at line 148 of file GaussianbXiIgnition.C.

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Implements fvModel.

Definition at line 158 of file GaussianbXiIgnition.C.

◆ distribute()

void distribute ( const polyDistributionMap & map )

virtual

Redistribute or update using the given distribution map.

Implements fvModel.

Definition at line 165 of file GaussianbXiIgnition.C.

◆ movePoints()

bool movePoints ( )

virtual

Update for mesh motion.

Implements fvModel.

Definition at line 175 of file GaussianbXiIgnition.C.

◆ read()

bool read ( const dictionary & dict )

virtual

Read source dictionary.

Reimplemented from bXiTimedIgnition.

Definition at line 183 of file GaussianbXiIgnition.C.

References dict, and fvModel::read().

Here is the call graph for this function:

◆ operator=()

void operator= ( const GaussianbXiIgnition & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ zone_

fvCellZone zone_

protected

The ignition cellZone.

Definition at line 146 of file GaussianbXiIgnition.H.

◆ kernelShape_

autoPtr<kernelShape> kernelShape_

protected

Definition at line 148 of file GaussianbXiIgnition.H.

◆ position_

dimensionedVector position_

protected

Definition at line 150 of file GaussianbXiIgnition.H.

◆ diameter_

dimensionedScalar diameter_

protected

Definition at line 152 of file GaussianbXiIgnition.H.

◆ rate_

autoPtr<Function1<scalar> > rate_

protected

Ignition burning rate [1/t].

Definition at line 155 of file GaussianbXiIgnition.H.

◆ Vk_

scalarList Vk_

protected

Kernel volume correction factor.

Definition at line 158 of file GaussianbXiIgnition.H.

The documentation for this class was generated from the following files:

applications/modules/XiFluid/fvModels/ignition/GaussianbXiIgnition/GaussianbXiIgnition.H
applications/modules/XiFluid/fvModels/ignition/GaussianbXiIgnition/GaussianbXiIgnition.C

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ GaussianbXiIgnition() [1/2]

◆ GaussianbXiIgnition() [2/2]

Member Function Documentation

◆ TypeName()

◆ addSup()

◆ topoChange()

◆ mapMesh()

◆ distribute()

◆ movePoints()

◆ read()

◆ operator=()

Member Data Documentation

◆ zone_

◆ kernelShape_

◆ position_

◆ diameter_

◆ rate_

◆ Vk_
