The enriched patch contains a double set of faces from the two sides of the sliding interface before the cutting. More...

Public Member Functions
	ClassName ("enrichedPatch")

	enrichedPatch (const primitiveFacePatch &masterPatch, const primitiveFacePatch &slavePatch, const labelList &slavePointPointHits, const labelList &slavePointEdgeHits, const List< objectHit > &slavePointFaceHits)
	Construct from components. More...

	enrichedPatch (const enrichedPatch &)=delete
	Disallow default bitwise copy construction. More...

	~enrichedPatch ()
	Destructor. More...

Map< point > &	pointMap ()
	Return non-const access to point map to add points. More...

const Map< point > &	pointMap () const
	Return map of points. More...

Map< label > &	pointMergeMap ()
	Return map of point merges. More...

const Map< label > &	pointMergeMap () const
	Return map of point merges. More...

void	calcEnrichedFaces (const labelListList &pointsIntoMasterEdges, const labelListList &pointsIntoSlaveEdges, const pointField &projectedSlavePoints)
	Calculate enriched faces. More...

const faceList &	enrichedFaces () const
	Return enriched faces. More...

const labelList &	meshPoints () const
	Return mesh points. More...

const faceList &	localFaces () const
	Return local faces. More...

const pointField &	localPoints () const
	Return local points. More...

const labelListList &	pointPoints () const
	Return point-point addressing. More...

const Map< labelList > &	masterPointFaces () const
	Master point face addressing. More...

const faceList &	cutFaces () const
	Return list of cut faces. More...

const labelList &	cutFaceMaster () const
	Return cut face master list. More...

const labelList &	cutFaceSlave () const
	Return cut face slave list. More...

bool	checkSupport () const
	Check if the patch is fully supported. More...

void	writeOBJ (const fileName &) const
	Debugging: dump graphical representation to obj format file. More...

void	operator= (const enrichedPatch &)=delete
	Disallow default bitwise assignment. More...

Detailed Description

The enriched patch contains a double set of faces from the two sides of the sliding interface before the cutting.

The patch basically consists of two over-lapping sets of faces sitting on a common point support, where every edge may be shared by more than 2 faces. The patch points are collected in a map. Additional information needed for cutting is the point insertion into every edge of master and slave.

Note: If new points are created during master-slave edge cutting, they should be registered with the pointMap.

Source files

Definition at line 67 of file enrichedPatch.H.

Constructor & Destructor Documentation

◆ enrichedPatch() [1/2]

enrichedPatch	(	const primitiveFacePatch &	masterPatch,
		const primitiveFacePatch &	slavePatch,
		const labelList &	slavePointPointHits,
		const labelList &	slavePointEdgeHits,
		const List< objectHit > &	slavePointFaceHits
	)

Construct from components.

Definition at line 136 of file enrichedPatch.C.

◆ enrichedPatch() [2/2]

enrichedPatch ( const enrichedPatch & )

delete

Disallow default bitwise copy construction.

◆ ~enrichedPatch()

~enrichedPatch ( )

Destructor.

Definition at line 170 of file enrichedPatch.C.

Member Function Documentation

◆ ClassName()

ClassName ( "enrichedPatch" )

◆ pointMap() [1/2]

Foam::Map< Foam::point > & pointMap ( )

Return non-const access to point map to add points.

Definition at line 83 of file enrichedPatchPointMap.C.

◆ pointMap() [2/2]

const Foam::Map< Foam::point > & pointMap ( ) const

Return map of points.

Definition at line 94 of file enrichedPatchPointMap.C.

◆ pointMergeMap() [1/2]

Map<label>& pointMergeMap ( )

inline

Return map of point merges.

Definition at line 219 of file enrichedPatch.H.

◆ pointMergeMap() [2/2]

const Map<label>& pointMergeMap ( ) const

inline

Return map of point merges.

Definition at line 225 of file enrichedPatch.H.

References enrichedPatch::calcEnrichedFaces(), enrichedPatch::checkSupport(), enrichedPatch::cutFaceMaster(), enrichedPatch::cutFaces(), enrichedPatch::cutFaceSlave(), enrichedPatch::enrichedFaces(), enrichedPatch::localFaces(), enrichedPatch::localPoints(), enrichedPatch::masterPointFaces(), enrichedPatch::meshPoints(), enrichedPatch::operator=(), enrichedPatch::pointPoints(), and enrichedPatch::writeOBJ().

Here is the call graph for this function:

◆ calcEnrichedFaces()

void calcEnrichedFaces	(	const labelListList &	pointsIntoMasterEdges,
		const labelListList &	pointsIntoSlaveEdges,
		const pointField &	projectedSlavePoints
	)
