Mesh motion solver for an fvMesh. Based on solving the cell-centre solid-body rotation stress equations for the motion displacement. More...

Inheritance diagram for displacementSBRStressFvMotionSolver:

[legend]

Collaboration diagram for displacementSBRStressFvMotionSolver:

[legend]

Public Member Functions
	TypeName ("displacementSBRStress")
	Runtime type information. More...

	displacementSBRStressFvMotionSolver (const polyMesh &, const dictionary &)
	Construct from polyMesh and dictionary. More...

	displacementSBRStressFvMotionSolver (const displacementSBRStressFvMotionSolver &)
	Disallow default bitwise copy construction. More...

	~displacementSBRStressFvMotionSolver ()
	Destructor. More...

volVectorField &	cellDisplacement ()
	Return reference to the cell motion displacement field. More...

const volVectorField &	cellDisplacement () const
	Return const reference to the cell motion displacement field. More...

motionDiffusivity &	diffusivity ()
	Return diffusivity. More...

virtual tmp< pointField >	curPoints () const
	Return point location obtained from the current motion field. More...

virtual void	solve ()
	Solve for motion. More...

virtual void	updateMesh (const mapPolyMesh &)
	Update topology. More...

void	operator= (const displacementSBRStressFvMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from displacementMotionSolver
	TypeName ("displacementMotionSolver")
	Runtime type information. More...

	displacementMotionSolver (const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	displacementMotionSolver (const displacementMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~displacementMotionSolver ()
	Destructor. More...

pointVectorField &	pointDisplacement ()
	Return reference to the point motion displacement field. More...

const pointVectorField &	pointDisplacement () const
	Return const reference to the point motion displacement field. More...

void	operator= (const displacementMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from points0MotionSolver
	TypeName ("points0MotionSolver")
	Runtime type information. More...

	points0MotionSolver (const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	points0MotionSolver (const points0MotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~points0MotionSolver ()
	Destructor. More...

pointField &	points0 ()
	Return reference to the reference field. More...

const pointField &	points0 () const
	Return reference to the reference field. More...

virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...

void	operator= (const points0MotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from motionSolver
	TypeName ("motionSolver")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const polyMesh &mesh, const dictionary &dict),(mesh, dict))

	motionSolver (const polyMesh &mesh, const dictionary &, const word &type)
	Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver >	clone () const
	Clone function. More...

virtual	~motionSolver ()
	Destructor. More...

const polyMesh &	mesh () const
	Return reference to mesh. More...

const dictionary &	coeffDict () const
	Const access to the coefficients dictionary. More...

virtual tmp< pointField >	newPoints ()
	Provide new points for motion. Solves for motion. More...

virtual void	twoDCorrectPoints (pointField &) const

virtual bool	write () const
	Optionally write motion state information for restart. More...

Public Member Functions inherited from fvMotionSolver
	ClassName ("displacementMotionSolver")
	Runtime type information. More...

	fvMotionSolver (const polyMesh &)
	Construct from polyMesh. More...

const fvMesh &	mesh () const
	Return reference to the fvMesh to be moved. More...

template<class Type >
Foam::wordList	cellMotionBoundaryTypes (const typename GeometricField< Type, pointPatchField, pointMesh >::Boundary &pmUbf) const

Additional Inherited Members
Static Public Member Functions inherited from motionSolver
static autoPtr< motionSolver >	New (const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...

Protected Member Functions inherited from fvMotionSolver
template<class Type >
wordList	cellMotionBoundaryTypes (const typename GeometricField< Type, pointPatchField, pointMesh >::Boundary &pmUbf) const
	Create the corresponding patch types for cellMotion from those. More...

Protected Attributes inherited from displacementMotionSolver
pointVectorField	pointDisplacement_
	Point motion field. More...

Protected Attributes inherited from points0MotionSolver
pointIOField	points0_
	Starting points. More...

Protected Attributes inherited from fvMotionSolver
const fvMesh &	fvMesh_
	The fvMesh to be moved. More...

Detailed Description

Mesh motion solver for an fvMesh. Based on solving the cell-centre solid-body rotation stress equations for the motion displacement.

Source files

Definition at line 53 of file displacementSBRStressFvMotionSolver.H.

Constructor & Destructor Documentation

◆ displacementSBRStressFvMotionSolver() [1/2]

displacementSBRStressFvMotionSolver	(	const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from polyMesh and dictionary.

Definition at line 55 of file displacementSBRStressFvMotionSolver.C.

References displacementSBRStressFvMotionSolver::~displacementSBRStressFvMotionSolver().

Here is the call graph for this function:

◆ displacementSBRStressFvMotionSolver() [2/2]

displacementSBRStressFvMotionSolver ( const displacementSBRStressFvMotionSolver & )

Disallow default bitwise copy construction.

◆ ~displacementSBRStressFvMotionSolver()

~displacementSBRStressFvMotionSolver ( )

Destructor.

Definition at line 91 of file displacementSBRStressFvMotionSolver.C.

Referenced by displacementSBRStressFvMotionSolver::displacementSBRStressFvMotionSolver().

Here is the caller graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "displacementSBRStress" )

Runtime type information.

◆ cellDisplacement() [1/2]

volVectorField& cellDisplacement ( )

inline

Return reference to the cell motion displacement field.

Definition at line 96 of file displacementSBRStressFvMotionSolver.H.

◆ cellDisplacement() [2/2]

const volVectorField& cellDisplacement ( ) const

inline

Return const reference to the cell motion displacement field.

Definition at line 102 of file displacementSBRStressFvMotionSolver.H.

◆ diffusivity()

motionDiffusivity& diffusivity ( )

inline

Return diffusivity.

Definition at line 108 of file displacementSBRStressFvMotionSolver.H.

References displacementSBRStressFvMotionSolver::curPoints(), displacementSBRStressFvMotionSolver::operator=(), displacementSBRStressFvMotionSolver::solve(), and displacementSBRStressFvMotionSolver::updateMesh().

Here is the call graph for this function:

◆ curPoints()

Foam::tmp< Foam::pointField > curPoints ( ) const

virtual

Return point location obtained from the current motion field.

Implements motionSolver.

Definition at line 98 of file displacementSBRStressFvMotionSolver.C.

References volPointInterpolation::interpolate(), MeshObject< fvMesh, UpdateableMeshObject, volPointInterpolation >::New(), and tmp< T >::ref().

Referenced by displacementSBRStressFvMotionSolver::diffusivity().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ solve()

void solve ( )

virtual

Solve for motion.

Implements motionSolver.

Definition at line 117 of file displacementSBRStressFvMotionSolver.C.

References Foam::fvc::div(), Foam::fvc::dotInterpolate(), Foam::fvc::grad(), Foam::fvc::interpolate(), Foam::fvm::laplacian(), Foam::solve(), GeometricField< Type, PatchField, GeoMesh >::T(), Foam::tr(), and displacementSBRStressFvMotionSolver::updateMesh().

Referenced by displacementSBRStressFvMotionSolver::diffusivity().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ updateMesh()

void updateMesh ( const mapPolyMesh & mpm )

virtual

Update topology.

Reimplemented from points0MotionSolver.

Definition at line 182 of file displacementSBRStressFvMotionSolver.C.

References lookup(), motionDiffusivity::New(), and points0MotionSolver::updateMesh().

Referenced by displacementSBRStressFvMotionSolver::diffusivity(), and displacementSBRStressFvMotionSolver::solve().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const displacementSBRStressFvMotionSolver & )

delete

Disallow default bitwise assignment.

Referenced by displacementSBRStressFvMotionSolver::diffusivity().

Here is the caller graph for this function:

The documentation for this class was generated from the following files:

src/fvMotionSolver/fvMotionSolvers/displacement/SBRStress/displacementSBRStressFvMotionSolver.H
src/fvMotionSolver/fvMotionSolvers/displacement/SBRStress/displacementSBRStressFvMotionSolver.C
