XiReactionRate Class Reference

Writes the turbulent flame-speed and reaction-rate volScalarFields for the Xi-based combustion models. More...

Inheritance diagram for XiReactionRate:
Collaboration diagram for XiReactionRate:

Public Member Functions

 TypeName ("XiReactionRate")
 Runtime type information. More...

 XiReactionRate (const word &name, const Time &runTime, const dictionary &dict)
 Construct from Time and dictionary. More...

 XiReactionRate (const XiReactionRate &)=delete
 Disallow default bitwise copy construction. More...

virtual ~XiReactionRate ()
 Destructor. More...

virtual bool execute ()
 Do nothing. More...

virtual bool write ()
 Write the cell-centre fields. More...

void operator= (const XiReactionRate &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from fvMeshFunctionObject
 TypeName ("fvMeshFunctionObject")
 Runtime type information. More...

 fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
 Construct from Time and dictionary. More...

 fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
 Construct from the region objectRegistry and dictionary. More...

 fvMeshFunctionObject (const fvMeshFunctionObject &)=delete
 Disallow default bitwise copy construction. More...

virtual ~fvMeshFunctionObject ()
 Destructor. More...

void operator= (const fvMeshFunctionObject &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from regionFunctionObject
 TypeName ("regionFunctionObject")
 Runtime type information. More...

 regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
 Construct from Time and dictionary. More...

 regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
 Construct from the region objectRegistry and dictionary. More...

 regionFunctionObject (const regionFunctionObject &)=delete
 Disallow default bitwise copy construction. More...

virtual ~regionFunctionObject ()
 Destructor. More...

virtual bool read (const dictionary &)
 Read optional controls. More...

void operator= (const regionFunctionObject &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from functionObject
virtual const wordtype () const =0
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

 functionObject (const word &name)
 Construct from components. More...

autoPtr< functionObjectclone () const
 Return clone. More...

 functionObject (const functionObject &)=delete
 Disallow default bitwise copy construction. More...

virtual ~functionObject ()
 Destructor. More...

const wordname () const
 Return the name of this functionObject. More...

virtual bool end ()
 Called when Time::run() determines that the time-loop exits. More...

virtual bool setTimeStep ()
 Called by Time::setDeltaT(). Allows the function object to override. More...

virtual scalar timeToNextWrite ()
 Called by Time::adjustTimeStep(). Allows the function object to. More...

virtual void updateMesh (const mapPolyMesh &mpm)
 Update for changes of mesh. More...

virtual void movePoints (const polyMesh &mesh)
 Update for changes of mesh. More...

void operator= (const functionObject &)=delete
 Disallow default bitwise assignment. More...


Additional Inherited Members

- Static Public Member Functions inherited from functionObject
static autoPtr< functionObjectNew (const word &name, const Time &, const dictionary &)
 Select from dictionary, based on its "type" entry. More...

- Public Attributes inherited from functionObject
Switch log
 Switch write log to Info. More...

- Static Public Attributes inherited from functionObject
static int debug

static bool postProcess
 Global post-processing mode switch. More...

- Protected Member Functions inherited from regionFunctionObject
template<class ObjectType >
bool foundObject (const word &fieldName) const
 Find field in the objectRegistry. More...

template<class ObjectType >
const ObjectType & lookupObject (const word &fieldName) const
 Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType & lookupObjectRef (const word &fieldName)
 Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
bool store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
 Store the given field in the objectRegistry under the given name. More...

bool writeObject (const word &fieldName)
 Write field if present in objectRegistry. More...

bool clearObject (const word &fieldName)
 Clear field from the objectRegistry if present. More...

- Protected Attributes inherited from fvMeshFunctionObject
const fvMeshmesh_
 Reference to the fvMesh. More...

- Protected Attributes inherited from regionFunctionObject
const Timetime_
 Reference to the Time. More...

const objectRegistryobr_
 Reference to the region objectRegistry. More...


Detailed Description

Writes the turbulent flame-speed and reaction-rate volScalarFields for the Xi-based combustion models.

Example of function object specification:

XiReactionRate
{
    type        XiReactionRate;
    libs        ("libfieldFunctionObjects.so");
    ...
}
Usage
Property Description Required Default value
type type name: XiReactionRate yes
See also
Foam::functionObjects::fvMeshFunctionObject
Source files

Definition at line 80 of file XiReactionRate.H.

Constructor & Destructor Documentation

◆ XiReactionRate() [1/2]

XiReactionRate ( const word name,
const Time runTime,
const dictionary dict
)

Construct from Time and dictionary.

Definition at line 46 of file XiReactionRate.C.

References Foam::read().

Here is the call graph for this function:

◆ XiReactionRate() [2/2]

XiReactionRate ( const XiReactionRate )
delete

Disallow default bitwise copy construction.

◆ ~XiReactionRate()

~XiReactionRate ( )
virtual

Destructor.

Definition at line 60 of file XiReactionRate.C.

Member Function Documentation

◆ TypeName()

TypeName ( "XiReactionRate"  )

Runtime type information.

◆ execute()

bool execute ( )
virtual

Do nothing.

Implements functionObject.

Definition at line 66 of file XiReactionRate.C.

◆ write()

bool write ( )
virtual

Write the cell-centre fields.

Implements functionObject.

Definition at line 72 of file XiReactionRate.C.

References Foam::constant::physicoChemical::b, Foam::endl(), Foam::fvc::grad(), Log, Foam::mag(), IOobject::name(), Su, Ostream::write(), and regIOobject::write().

Here is the call graph for this function:

◆ operator=()

void operator= ( const XiReactionRate )
delete

Disallow default bitwise assignment.


The documentation for this class was generated from the following files:
