fixedRhoFvPatchScalarField Class Reference

Foam::fixedRhoFvPatchScalarField. More...

Inheritance diagram for fixedRhoFvPatchScalarField:
Collaboration diagram for fixedRhoFvPatchScalarField:

Public Member Functions

 TypeName ("fixedRho")
 Runtime type information. More...

 fixedRhoFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
 Construct from patch and internal field. More...

 fixedRhoFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 fixedRhoFvPatchScalarField (const fixedRhoFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given fixedRhoFvPatchScalarField. More...

 fixedRhoFvPatchScalarField (const fixedRhoFvPatchScalarField &)
 Copy constructor. More...

virtual tmp< fvPatchScalarFieldclone () const
 Construct and return a clone. More...

 fixedRhoFvPatchScalarField (const fixedRhoFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarFieldclone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Detailed Description

Foam::fixedRhoFvPatchScalarField.

This boundary condition provides a fixed density inlet condition for compressible solvers, where the density of calculated using:

\[ \rho = \psi p \]

where

$ p $ = pressure [Pa]
$ \rho $ = density [kg/m^3]
Usage
Property Description Required Default value
p Pressure field name no p
psi Compressibility field name no thermo:psi

Example of the boundary condition specification:

    <patchName>
    {
        type            fixedRho;
    }
Source files

Definition at line 100 of file fixedRhoFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ fixedRhoFvPatchScalarField() [1/5]

fixedRhoFvPatchScalarField ( const fvPatch ,
const DimensionedField< scalar, volMesh > &
)

Construct from patch and internal field.

Referenced by fixedRhoFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ fixedRhoFvPatchScalarField() [2/5]

fixedRhoFvPatchScalarField ( const fvPatch ,
const DimensionedField< scalar, volMesh > &  ,
const dictionary
)

Construct from patch, internal field and dictionary.

◆ fixedRhoFvPatchScalarField() [3/5]

fixedRhoFvPatchScalarField ( const fixedRhoFvPatchScalarField ,
const fvPatch ,
const DimensionedField< scalar, volMesh > &  ,
const fvPatchFieldMapper
)

Construct by mapping given fixedRhoFvPatchScalarField.

onto a new patch

◆ fixedRhoFvPatchScalarField() [4/5]

Copy constructor.

◆ fixedRhoFvPatchScalarField() [5/5]

Copy constructor setting internal field reference.

Member Function Documentation

◆ TypeName()

TypeName ( "fixedRho"  )

Runtime type information.

◆ clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const
inlinevirtual

Construct and return a clone.

Definition at line 153 of file fixedRhoFvPatchScalarField.H.

References fixedRhoFvPatchScalarField::fixedRhoFvPatchScalarField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 170 of file fixedRhoFvPatchScalarField.H.

References fixedRhoFvPatchScalarField::fixedRhoFvPatchScalarField(), fixedRhoFvPatchScalarField::updateCoeffs(), and fixedRhoFvPatchScalarField::write().

Here is the call graph for this function:

◆ updateCoeffs()

virtual void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Referenced by fixedRhoFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ write()

virtual void write ( Ostream ) const
virtual

Write.

Referenced by fixedRhoFvPatchScalarField::clone().

Here is the caller graph for this function:

The documentation for this class was generated from the following file:
