Inheritance diagram for twoPhaseMixtureThermo:

Collaboration diagram for twoPhaseMixtureThermo:

Public Member Functions
	TypeName ("twoPhaseMixtureThermo")
	Runtime type information. More...

	twoPhaseMixtureThermo (const volVectorField &U, const surfaceScalarField &phi)
	Construct from components. More...

virtual	~twoPhaseMixtureThermo ()
	Destructor. More...

const rhoThermo &	thermo1 () const

const rhoThermo &	thermo2 () const

rhoThermo &	thermo1 ()

rhoThermo &	thermo2 ()

virtual void	correctThermo ()
	Correct the thermodynamics of each phase. More...

virtual void	correct ()
	Update mixture properties. More...

virtual bool	incompressible () const
	Return true if the equation of state is incompressible. More...

virtual bool	isochoric () const
	Return true if the equation of state is isochoric. More...

virtual volScalarField &	he ()
	Enthalpy/Internal energy [J/kg]. More...

virtual const volScalarField &	he () const
	Enthalpy/Internal energy [J/kg]. More...

virtual tmp< volScalarField >	he (const volScalarField &p, const volScalarField &T) const
	Enthalpy/Internal energy. More...

virtual tmp< scalarField >	he (const scalarField &p, const scalarField &T, const labelList &cells) const
	Enthalpy/Internal energy for cell-set [J/kg]. More...

virtual tmp< scalarField >	he (const scalarField &p, const scalarField &T, const label patchi) const
	Enthalpy/Internal energy for patch [J/kg]. More...

virtual tmp< volScalarField >	hc () const
	Chemical enthalpy [J/kg]. More...

virtual tmp< scalarField >	THE (const scalarField &h, const scalarField &p, const scalarField &T0, const labelList &cells) const
	Temperature from enthalpy/internal energy for cell-set. More...

virtual tmp< scalarField >	THE (const scalarField &h, const scalarField &p, const scalarField &T0, const label patchi) const
	Temperature from enthalpy/internal energy for patch. More...

virtual tmp< volScalarField >	Cp () const
	Heat capacity at constant pressure [J/kg/K]. More...

virtual tmp< scalarField >	Cp (const scalarField &p, const scalarField &T, const label patchi) const
	Heat capacity at constant pressure for patch [J/kg/K]. More...

virtual tmp< volScalarField >	Cv () const
	Heat capacity at constant volume [J/kg/K]. More...

virtual tmp< scalarField >	Cv (const scalarField &p, const scalarField &T, const label patchi) const
	Heat capacity at constant volume for patch [J/kg/K]. More...

virtual tmp< volScalarField >	gamma () const
	Gamma = Cp/Cv []. More...

virtual tmp< scalarField >	gamma (const scalarField &p, const scalarField &T, const label patchi) const
	Gamma = Cp/Cv for patch []. More...

virtual tmp< volScalarField >	Cpv () const
	Heat capacity at constant pressure/volume [J/kg/K]. More...

virtual tmp< scalarField >	Cpv (const scalarField &p, const scalarField &T, const label patchi) const
	Heat capacity at constant pressure/volume for patch [J/kg/K]. More...

virtual tmp< volScalarField >	CpByCpv () const
	Heat capacity ratio []. More...

virtual tmp< scalarField >	CpByCpv (const scalarField &p, const scalarField &T, const label patchi) const
	Heat capacity ratio for patch []. More...

virtual tmp< volScalarField >	nu () const
	Kinematic viscosity of mixture [m^2/s]. More...

virtual tmp< scalarField >	nu (const label patchi) const
	Kinematic viscosity of mixture for patch [m^2/s]. More...

virtual tmp< volScalarField >	kappa () const
	Thermal diffusivity for temperature of mixture [J/m/s/K]. More...

virtual tmp< scalarField >	kappa (const label patchi) const
	Thermal diffusivity of mixture for patch [J/m/s/K]. More...

virtual tmp< volScalarField >	kappaEff (const volScalarField &alphat) const
	Effective thermal diffusivity of mixture [J/m/s/K]. More...

virtual tmp< scalarField >	kappaEff (const scalarField &alphat, const label patchi) const
	Effective thermal diffusivity of mixture for patch [J/m/s/K]. More...

virtual tmp< volScalarField >	alphaEff (const volScalarField &alphat) const
	Effective thermal diffusivity of mixture [J/m/s/K]. More...

virtual tmp< scalarField >	alphaEff (const scalarField &alphat, const label patchi) const
	Effective thermal diffusivity of mixture for patch [J/m/s/K]. More...

virtual bool	read ()
	Read base transportProperties dictionary. More...

Public Member Functions inherited from psiThermo
	TypeName ("psiThermo")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, psiThermo, fvMesh,(const fvMesh &mesh, const word &phaseName),(mesh, phaseName))
	Declare run-time constructor selection table. More...

	psiThermo (const fvMesh &, const word &phaseName)
	Construct from mesh and phase name. More...

virtual	~psiThermo ()
	Destructor. More...

virtual void	correctRho (const volScalarField &deltaRho)
	Add the given density correction to the density field. More...

virtual tmp< volScalarField >	rho () const
	Density [kg/m^3] - uses current value of pressure. More...

virtual tmp< scalarField >	rho (const label patchi) const
	Density for patch [kg/m^3]. More...

virtual const volScalarField &	psi () const
	Compressibility [s^2/m^2]. More...

virtual tmp< volScalarField >	mu () const
	Dynamic viscosity of mixture [kg/m/s]. More...

virtual tmp< scalarField >	mu (const label patchi) const
	Dynamic viscosity of mixture for patch [kg/m/s]. More...

Public Member Functions inherited from fluidThermo
	TypeName ("fluidThermo")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fluidThermo, fvMesh,(const fvMesh &mesh, const word &phaseName),(mesh, phaseName))
	Declare run-time constructor selection table. More...

	fluidThermo (const fvMesh &, const word &phaseName)
	Construct from mesh and phase name. More...

	fluidThermo (const fvMesh &, const dictionary &, const word &phaseName)
	Construct from mesh and phase name. More...

virtual	~fluidThermo ()
	Destructor. More...

Public Member Functions inherited from basicThermo
	TypeName ("basicThermo")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, basicThermo, fvMesh,(const fvMesh &mesh, const word &phaseName),(mesh, phaseName))
	Declare run-time constructor selection table. More...

	basicThermo (const fvMesh &, const word &phaseName)
	Construct from mesh and phase name. More...

	basicThermo (const fvMesh &, const dictionary &, const word &phaseName)
	Construct from mesh, dictionary and phase name. More...

virtual	~basicThermo ()
	Destructor. More...

word	phasePropertyName (const word &name) const

void	validate (const string &app, const word &) const
	Check that the thermodynamics package is consistent. More...

void	validate (const string &app, const word &, const word &) const
	Check that the thermodynamics package is consistent. More...

void	validate (const string &app, const word &, const word &, const word &) const
	Check that the thermodynamics package is consistent. More...

void	validate (const string &app, const word &, const word &, const word &, const word &) const
	Check that the thermodynamics package is consistent. More...

Switch	dpdt () const
	Should the dpdt term be included in the enthalpy equation. More...

virtual volScalarField &	p ()
	Pressure [Pa]. More...

virtual const volScalarField &	p () const
	Pressure [Pa]. More...

virtual const volScalarField &	T () const
	Temperature [K]. More...

virtual volScalarField &	T ()
	Temperature [K]. More...

virtual const volScalarField &	alpha () const
	Thermal diffusivity for enthalpy of mixture [kg/m/s]. More...

virtual const scalarField &	alpha (const label patchi) const
	Thermal diffusivity for enthalpy of mixture for patch [kg/m/s]. More...

template<class Thermo >
Foam::autoPtr< Thermo >	New (const fvMesh &mesh, const word &phaseName)

template<class Thermo >
Foam::autoPtr< Thermo >	New (const fvMesh &mesh, const dictionary &dict, const word &phaseName)

Public Member Functions inherited from IOdictionary
	IOdictionary (const IOobject &)
	Construct given an IOobject. More...

	IOdictionary (const IOobject &, const dictionary &)
	Construct given an IOobject and dictionary. More...

	IOdictionary (const IOobject &, Istream &)
	Construct given an IOobject and Istream. More...

virtual	~IOdictionary ()
	Destructor. More...

virtual bool	global () const
	Is object global. More...

virtual fileName	filePath () const
	Return complete path + object name if the file exists. More...

Public Member Functions inherited from baseIOdictionary
	TypeName ("dictionary")

	baseIOdictionary (const IOobject &)
	Construct given an IOobject. More...

	baseIOdictionary (const IOobject &, const dictionary &)
	Construct given an IOobject and dictionary. More...

	baseIOdictionary (const IOobject &, Istream &)
	Construct given an IOobject and Istream. More...

virtual	~baseIOdictionary ()
	Destructor. More...

const word &	name () const
	Name function is needed to disambiguate those inherited. More...

virtual bool	readData (Istream &)
	ReadData function required for regIOobject read operation. More...

virtual bool	writeData (Ostream &) const
	WriteData function required for regIOobject write operation. More...

void	operator= (const baseIOdictionary &)
	Assignment of other baseIOdictionary's entries to this. More...

Public Member Functions inherited from regIOobject
	TypeName ("regIOobject")
	Runtime type information. More...

	regIOobject (const IOobject &, const bool isTime=false)
	Construct from IOobject. Optional flag for if IOobject is the. More...

	regIOobject (const regIOobject &)
	Construct as copy. More...

	regIOobject (const regIOobject &, bool registerCopy)
	Construct as copy, transferring registry registration to copy. More...

	regIOobject (const word &newName, const regIOobject &, bool registerCopy)
	Construct as copy with new name, transfering registry registration. More...

	regIOobject (const IOobject &, const regIOobject &)
	Construct as copy with new IO parameters. More...

virtual	~regIOobject ()
	Destructor. More...

bool	checkIn ()
	Add object to registry. More...

bool	checkOut ()
	Remove object from registry. More...

virtual void	addWatch ()
	Add file watch on object (if registered and READ_IF_MODIFIED) More...

bool	ownedByRegistry () const
	Is this object owned by the registry? More...

void	store ()
	Transfer ownership of this object to its registry. More...

void	release ()
	Release ownership of this object from its registry. More...

label	eventNo () const
	Event number at last update. More...

label &	eventNo ()
	Event number at last update. More...

bool	upToDate (const regIOobject &) const
	Return true if up-to-date with respect to given object. More...

bool	upToDate (const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

void	setUpToDate ()
	Set up to date (obviously) More...

virtual void	rename (const word &newName)
	Rename. More...

bool	headerOk ()
	Read and check header info. More...

Istream &	readStream (const word &, const bool valid=true)
	Return Istream and check object type against that given. More...

void	close ()
	Close Istream. More...

virtual label	addWatch (const fileName &)
	Add file watch for fileName on object if not yet watched. Return. More...

const labelList &	watchIndices () const
	Return file-monitoring handles. More...

labelList &	watchIndices ()
	Return file-monitoring handles. More...

virtual bool	modified () const
	Return true if the object's file (or files for objectRegistry) More...

virtual bool	readIfModified ()
	Read object if modified (as set by call to modified) More...

virtual bool	writeObject (IOstream::streamFormat, IOstream::versionNumber, IOstream::compressionType, const bool valid) const
	Write using given format, version and compression. More...

virtual bool	write (const bool valid=true) const
	Write using setting from DB. More...

void	operator= (const IOobject &)

Public Member Functions inherited from IOobject
	TypeName ("IOobject")
	Runtime type information. More...

	IOobject (const word &name, const fileName &instance, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from name, instance, registry, io options. More...

	IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)
	Construct from name, instance, local, registry, io options. More...

	IOobject (const fileName &path, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true, bool globalObject=false)
	Construct from path, registry, io options. More...

	IOobject (const IOobject &io, const objectRegistry &registry)
	Construct from copy resetting registry. More...

	IOobject (const IOobject &io, const word &name)
	Construct from copy resetting name. More...

autoPtr< IOobject >	clone () const
	Clone. More...

autoPtr< IOobject >	clone (const objectRegistry &registry) const
	Clone resetting registry. More...

virtual	~IOobject ()
	Destructor. More...

const Time &	time () const
	Return time. More...

const objectRegistry &	db () const
	Return the local objectRegistry. More...

const word &	name () const
	Return name. More...

const word &	headerClassName () const
	Return name of the class name read from header. More...

word &	headerClassName ()
	Return name of the class name read from header. More...

string &	note ()
	Return non-constant access to the optional note. More...

const string &	note () const
	Return the optional note. More...

bool &	registerObject ()
	Register object created from this IOobject with registry if true. More...

bool	registerObject () const
	Register object created from this IOobject with registry if true. More...

bool &	globalObject ()
	Is object same for all processors. More...

bool	globalObject () const
	Is object same for all processors. More...

readOption	readOpt () const

readOption &	readOpt ()

writeOption	writeOpt () const

writeOption &	writeOpt ()

word	group () const
	Return group (extension part of name) More...

word	member () const
	Return member (name without the extension) More...

const fileName &	rootPath () const

const fileName &	caseName () const

const fileName &	instance () const

fileName &	instance ()

const fileName &	local () const

fileName	path () const
	Return complete path. More...

fileName	path (const word &instance, const fileName &local="") const
	Return complete path with alternative instance and local. More...

fileName	objectPath () const
	Return complete path + object name. More...

fileName	localFilePath (const word &typeName) const
	Helper for filePath that searches locally. More...

fileName	globalFilePath (const word &typeName) const
	Helper for filePath that searches up if in parallel. More...

bool	readHeader (Istream &)
	Read header. More...

template<class Type >
bool	typeHeaderOk (const bool checkType=true)
	Read header (uses typeFilePath to find file) and check header. More...

template<class Type >
void	warnNoRereading () const
	Helper: warn that type does not support re-reading. More...

bool	writeHeader (Ostream &) const
	Write header. More...

bool	writeHeader (Ostream &, const word &objectType) const
	Write header. Allow override of type. More...

bool	good () const

bool	bad () const

InfoProxy< IOobject >	info () const
	Return info proxy. More...

void	operator= (const IOobject &)

template<class Name >
Foam::word	groupName (Name name, const word &group)

Public Member Functions inherited from dictionary
	ClassName ("dictionary")

	dictionary ()
	Construct top-level dictionary null. More...

	dictionary (const fileName &name)
	Construct top-level empty dictionary with given name. More...

	dictionary (const fileName &name, const dictionary &parentDict, Istream &)
	Construct given the entry name, parent dictionary and Istream,. More...

	dictionary (Istream &)
	Construct top-level dictionary from Istream,. More...

	dictionary (Istream &, const bool keepHeader)
	Construct top-level dictionary from Istream,. More...

	dictionary (const dictionary &parentDict, const dictionary &)
	Construct as copy given the parent dictionary. More...

	dictionary (const dictionary &)
	Construct top-level dictionary as copy. More...

	dictionary (const dictionary *)
	Construct top-level dictionary as copy from pointer to dictionary. More...

	dictionary (const dictionary &parentDict, const Xfer< dictionary > &)
	Construct by transferring parameter contents given parent dictionary. More...

	dictionary (const Xfer< dictionary > &)
	Construct top-level dictionary by transferring parameter contents. More...

autoPtr< dictionary >	clone () const
	Construct and return clone. More...

virtual	~dictionary ()
	Destructor. More...

const dictionary &	parent () const
	Return the parent dictionary. More...

const dictionary &	topDict () const
	Return the top of the tree. More...

label	startLineNumber () const
	Return line number of first token in dictionary. More...

label	endLineNumber () const
	Return line number of last token in dictionary. More...

SHA1Digest	digest () const
	Return the SHA1 digest of the dictionary contents. More...

tokenList	tokens () const
	Return the dictionary as a list of tokens. More...

bool	found (const word &, bool recursive=false, bool patternMatch=true) const
	Search dictionary for given keyword. More...

const entry *	lookupEntryPtr (const word &, bool recursive, bool patternMatch) const
	Find and return an entry data stream pointer if present. More...

entry *	lookupEntryPtr (const word &, bool recursive, bool patternMatch)
	Find and return an entry data stream pointer for manipulation. More...

const entry &	lookupEntry (const word &, bool recursive, bool patternMatch) const
	Find and return an entry data stream if present otherwise error. More...

ITstream &	lookup (const word &, bool recursive=false, bool patternMatch=true) const
	Find and return an entry data stream. More...

template<class T >
T	lookupType (const word &, bool recursive=false, bool patternMatch=true) const
	Find and return a T,. More...

template<class T >
T	lookupOrDefault (const word &, const T &, bool recursive=false, bool patternMatch=true) const
	Find and return a T,. More...

template<class T >
T	lookupOrAddDefault (const word &, const T &, bool recursive=false, bool patternMatch=true)
	Find and return a T, if not found return the given. More...

template<class T >
bool	readIfPresent (const word &, T &, bool recursive=false, bool patternMatch=true) const
	Find an entry if present, and assign to T. More...

const entry *	lookupScopedEntryPtr (const word &, bool recursive, bool patternMatch) const
	Find and return an entry data stream pointer if present. More...

bool	isDict (const word &) const
	Check if entry is a sub-dictionary. More...

const dictionary *	subDictPtr (const word &) const
	Find and return a sub-dictionary pointer if present. More...

dictionary *	subDictPtr (const word &)
	Find and return a sub-dictionary pointer if present. More...

const dictionary &	subDict (const word &) const
	Find and return a sub-dictionary. More...

dictionary &	subDict (const word &)
	Find and return a sub-dictionary for manipulation. More...

dictionary	subOrEmptyDict (const word &, const bool mustRead=false) const
	Find and return a sub-dictionary as a copy, or. More...

const dictionary &	optionalSubDict (const word &) const
	Find and return a sub-dictionary if found. More...

wordList	toc () const
	Return the table of contents. More...

wordList	sortedToc () const
	Return the sorted table of contents. More...

List< keyType >	keys (bool patterns=false) const
	Return the list of available keys or patterns. More...

bool	substituteKeyword (const word &keyword)
	Substitute the given keyword prepended by '$' with the. More...

bool	substituteScopedKeyword (const word &keyword)
	Substitute the given scoped keyword prepended by '$' with the. More...

bool	add (entry *, bool mergeEntry=false)
	Add a new entry. More...

void	add (const entry &, bool mergeEntry=false)
	Add an entry. More...

void	add (const keyType &, const word &, bool overwrite=false)
	Add a word entry. More...

void	add (const keyType &, const string &, bool overwrite=false)
	Add a string entry. More...

void	add (const keyType &, const label, bool overwrite=false)
	Add a label entry. More...

void	add (const keyType &, const scalar, bool overwrite=false)
	Add a scalar entry. More...

void	add (const keyType &, const dictionary &, bool mergeEntry=false)
	Add a dictionary entry. More...

template<class T >
void	add (const keyType &, const T &, bool overwrite=false)
	Add a T entry. More...

void	set (entry *)
	Assign a new entry, overwrite any existing entry. More...

void	set (const entry &)
	Assign a new entry, overwrite any existing entry. More...

void	set (const keyType &, const dictionary &)
	Assign a dictionary entry, overwrite any existing entry. More...

template<class T >
void	set (const keyType &, const T &)
	Assign a T entry, overwrite any existing entry. More...

bool	remove (const word &)
	Remove an entry specified by keyword. More...

bool	changeKeyword (const keyType &oldKeyword, const keyType &newKeyword, bool forceOverwrite=false)
	Change the keyword for an entry,. More...

bool	merge (const dictionary &)
	Merge entries from the given dictionary. More...

void	clear ()
	Clear the dictionary. More...

void	transfer (dictionary &)
	Transfer the contents of the argument and annul the argument. More...

Xfer< dictionary >	xfer ()
	Transfer contents to the Xfer container. More...

bool	read (Istream &)
	Read dictionary from Istream. More...

bool	read (Istream &, const bool keepHeader)
	Read dictionary from Istream, optionally keeping the header. More...

void	write (Ostream &, const bool subDict=true) const
	Write dictionary, normally with sub-dictionary formatting. More...

ITstream &	operator[] (const word &) const
	Find and return entry. More...

void	operator= (const dictionary &)

void	operator+= (const dictionary &)
	Include entries from the given dictionary. More...

void	operator\|= (const dictionary &)
	Conditionally include entries from the given dictionary. More...

void	operator<<= (const dictionary &)
	Unconditionally include entries from the given dictionary. More...

Public Member Functions inherited from dictionaryName
	dictionaryName ()
	Construct dictionaryName null. More...

	dictionaryName (const fileName &name)
	Construct dictionaryName as copy of the given fileName. More...

const fileName &	name () const
	Return the dictionary name. More...

fileName &	name ()
	Return the dictionary name. More...

const word	dictName () const
	Return the local dictionary name (final part of scoped name) More...

Public Member Functions inherited from ILList< LListBase, T >
	ILList ()
	Null construct. More...

	ILList (T *a)
	Construct given initial T. More...

	ILList (Istream &)
	Construct from Istream. More...

	ILList (const ILList< LListBase, T > &)
	Construct as copy. More...

template<class CloneArg >
	ILList (const ILList< LListBase, T > &lst, const CloneArg &cloneArg)
	Copy constructor with additional argument for clone. More...

template<class INew >
	ILList (Istream &, const INew &)
	Construct from Istream using given Istream constructor class. More...

	~ILList ()
	Destructor. More...

bool	eraseHead ()
	Remove the head element specified from the list and delete it. More...

bool	erase (T *p)
	Remove the specified element from the list and delete it. More...

void	clear ()
	Clear the contents of the list. More...

void	transfer (ILList< LListBase, T > &)
	Transfer the contents of the argument into this List. More...

void	operator= (const ILList< LListBase, T > &)
	Assignment operator. More...

Public Member Functions inherited from UILList< LListBase, T >
	UILList ()
	Null construct. More...

	UILList (T *a)
	Construct given initial T. More...

	UILList (const UILList< LListBase, T > &)
	Construct as copy. More...

T *	first ()
	Return the first entry. More...

const T *	first () const
	Return the first entry. More...

T *	last ()
	Return the last entry. More...

const T *	last () const
	Return the last entry. More...

T *	removeHead ()
	Remove and return head. More...

T *	remove (T *p)
	Remove and return element. More...

T *	remove (iterator &it)
	Remove and return specified by iterator. More...

void	operator= (const UILList< LListBase, T > &)

iterator	begin ()

const iterator &	end ()

const_iterator	cbegin () const

const const_iterator &	cend () const

const_iterator	begin () const

const const_iterator &	end () const

const_reverse_iterator	crbegin () const

const const_reverse_iterator &	crend () const

const_reverse_iterator	rbegin () const

const const_reverse_iterator &	rend () const

bool	operator== (const UILList< LListBase, T > &) const
	Equality operation on ULists of the same type. More...

bool	operator!= (const UILList< LListBase, T > &) const
	The opposite of the equality operation. Takes linear time. More...

Public Member Functions inherited from compressibleTransportModel
	TypeName ("compressibleTransportModel")
	Runtime type information. More...

	compressibleTransportModel ()
	Construct from components. More...

virtual	~compressibleTransportModel ()
	Destructor. More...

Public Member Functions inherited from twoPhaseMixture
	twoPhaseMixture (const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

	~twoPhaseMixture ()
	Destructor. More...

const word &	phase1Name () const

const word &	phase2Name () const

const volScalarField &	alpha1 () const
	Return the phase-fraction of phase 1. More...

volScalarField &	alpha1 ()
	Return the phase-fraction of phase 1. More...

const volScalarField &	alpha2 () const
	Return the phase-fraction of phase 2. More...

volScalarField &	alpha2 ()
	Return the phase-fraction of phase 2. More...

Public Member Functions inherited from interfaceProperties
	interfaceProperties (const volScalarField &alpha1, const volVectorField &U, const IOdictionary &)
	Construct from volume fraction field gamma and IOdictionary. More...

scalar	cAlpha () const

const dimensionedScalar &	deltaN () const

const surfaceScalarField &	nHatf () const

tmp< volScalarField >	sigmaK () const

tmp< surfaceScalarField >	surfaceTensionForce () const

tmp< volScalarField >	nearInterface () const
	Indicator of the proximity of the interface. More...

void	correct ()

bool	read ()
	Read transportProperties dictionary. More...

Additional Inherited Members
Public Types inherited from IOobject
enum	objectState { GOOD, BAD }
	Enumeration defining the valid states of an IOobject. More...

enum	readOption { MUST_READ, MUST_READ_IF_MODIFIED, READ_IF_PRESENT, NO_READ }
	Enumeration defining the read options. More...

enum	writeOption { AUTO_WRITE = 0, NO_WRITE = 1 }
	Enumeration defining the write options. More...

enum	fileCheckTypes { timeStamp, timeStampMaster, inotify, inotifyMaster }
	Enumeration defining the file checking options. More...

Public Types inherited from UILList< LListBase, T >
typedef T	value_type
	Type of values the DLList contains. More...

typedef T &	reference
	Type that can be used for storing into DLList::value_type. More...

typedef const T &	const_reference
	Type that can be used for storing into constant. More...

typedef label	size_type
	The type that can represent the size of a DLList. More...

typedef LListBase::iterator	LListBase_iterator

typedef LListBase::const_iterator	LListBase_const_iterator

Static Public Member Functions inherited from psiThermo
static autoPtr< psiThermo >	New (const fvMesh &mesh, const word &phaseName=word::null)
	Selector. More...

Static Public Member Functions inherited from fluidThermo
static autoPtr< fluidThermo >	New (const fvMesh &, const word &phaseName=word::null)
	Selector. More...

Static Public Member Functions inherited from basicThermo
template<class Thermo , class Table >
static Table::iterator	lookupThermo (const dictionary &thermoTypeDict, Table tablePtr, const int nCmpt, const char cmptNames[], const word &thermoTypeName)
	Generic lookup for thermodynamics package thermoTypeName. More...

template<class Thermo , class Table >
static Table::iterator	lookupThermo (const dictionary &thermoDict, Table *tablePtr)
	Generic lookup for each of the related thermodynamics packages. More...

template<class Thermo >
static autoPtr< Thermo >	New (const fvMesh &, const word &phaseName=word::null)
	Generic New for each of the related thermodynamics packages. More...

template<class Thermo >
static autoPtr< Thermo >	New (const fvMesh &, const dictionary &, const word &phaseName=word::null)
	Generic New for each of the related thermodynamics packages. More...

static autoPtr< basicThermo >	New (const fvMesh &, const word &phaseName=word::null)
	Specialisation of the Generic New for basicThermo. More...

static word	phasePropertyName (const word &name, const word &phaseName)

static const basicThermo &	lookupThermo (const fvPatchScalarField &pf)

static wordList	splitThermoName (const word &thermoName, const int nCmpt)
	Split name of thermo package into a list of the components names. More...

Static Public Member Functions inherited from regIOobject
template<class Type >
static Type &	store (Type *)
	Transfer ownership of the given object pointer to its registry. More...

template<class Type >
static Type &	store (autoPtr< Type > &)
	Transfer ownership of the given object pointer to its registry. More...

Static Public Member Functions inherited from IOobject
static bool	fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name)
	Split path into instance, local, name components. More...

template<class Name >
static word	groupName (Name name, const word &group)

template<class Stream >
static Stream &	writeBanner (Stream &os, bool noHint=false)
	Write the standard OpenFOAM file/dictionary banner. More...

template<class Stream >
static Stream &	writeDivider (Stream &os)
	Write the standard file section divider. More...

template<class Stream >
static Stream &	writeEndDivider (Stream &os)
	Write the standard end file divider. More...

Static Public Member Functions inherited from dictionary
static autoPtr< dictionary >	New (Istream &)
	Construct top-level dictionary on freestore from Istream. More...

Static Public Attributes inherited from basicThermo
static const word	dictName

Static Public Attributes inherited from regIOobject
static float	fileModificationSkew

Static Public Attributes inherited from IOobject
static const NamedEnum< fileCheckTypes, 4 >	fileCheckTypesNames

static fileCheckTypes	fileModificationChecking
	Type of file modification checking. More...

Static Public Attributes inherited from dictionary
static const dictionary	null
	Null dictionary. More...

Static Public Attributes inherited from interfaceProperties
static const scalar	convertToRad
	Conversion factor for degrees into radians. More...

Protected Member Functions inherited from psiThermo
	psiThermo (const psiThermo &)
	Construct as copy (not implemented) More...

Protected Member Functions inherited from basicThermo
	basicThermo (const basicThermo &)
	Construct as copy (not implemented) More...

volScalarField &	lookupOrConstruct (const fvMesh &mesh, const char *name) const

wordList	heBoundaryTypes ()
	Return the enthalpy/internal energy field boundary types. More...

wordList	heBoundaryBaseTypes ()
	Return the enthalpy/internal energy field boundary base types. More...

Protected Member Functions inherited from regIOobject
bool	readHeaderOk (const IOstream::streamFormat PstreamFormat, const word &typeName)
	Helper: check readOpt flags and read if necessary. More...

Protected Member Functions inherited from IOobject
void	setBad (const string &)
	Set the object state to bad. More...

Protected Attributes inherited from psiThermo
volScalarField	psi_
	Compressibility [s^2/m^2]. More...

volScalarField	mu_
	Dynamic viscosity [kg/m/s]. More...

Protected Attributes inherited from basicThermo
const word &	phaseName_
	Phase-name. More...

volScalarField &	p_
	Pressure [Pa]. More...

volScalarField	T_
	Temperature [K]. More...

volScalarField	alpha_
	Laminar thermal diffusuvity [kg/m/s]. More...

Switch	dpdt_
	Should the dpdt term be included in the enthalpy equation. More...

Protected Attributes inherited from twoPhaseMixture
word	phase1Name_

word	phase2Name_

volScalarField	alpha1_

volScalarField	alpha2_

Static Protected Attributes inherited from regIOobject
static bool	masterOnlyReading = false
	To flag master-only reading of objects. More...

Detailed Description

Source files

Definition at line 52 of file twoPhaseMixtureThermo.H.

Constructor & Destructor Documentation

◆ twoPhaseMixtureThermo()

twoPhaseMixtureThermo	(	const volVectorField &	U,
		const surfaceScalarField &	phi
	)

Construct from components.

◆ ~twoPhaseMixtureThermo()

virtual ~twoPhaseMixtureThermo ( )

virtual

Destructor.

Member Function Documentation

◆ TypeName()

TypeName ( "twoPhaseMixtureThermo" )

Runtime type information.

◆ thermo1() [1/2]

const rhoThermo& thermo1 ( ) const

inline

Definition at line 89 of file twoPhaseMixtureThermo.H.

◆ thermo2() [1/2]

const rhoThermo& thermo2 ( ) const

inline

Definition at line 94 of file twoPhaseMixtureThermo.H.

◆ thermo1() [2/2]

rhoThermo& thermo1 ( )

inline

Definition at line 99 of file twoPhaseMixtureThermo.H.

◆ thermo2() [2/2]

rhoThermo& thermo2 ( )

inline

Definition at line 104 of file twoPhaseMixtureThermo.H.

References twoPhaseMixtureThermo::correct(), twoPhaseMixtureThermo::correctThermo(), twoPhaseMixtureThermo::he(), twoPhaseMixtureThermo::incompressible(), twoPhaseMixtureThermo::isochoric(), and NotImplemented.

Here is the call graph for this function:

◆ correctThermo()

virtual void correctThermo ( )

virtual

Correct the thermodynamics of each phase.

Referenced by twoPhaseMixtureThermo::thermo2().

Here is the caller graph for this function:

◆ correct()

virtual void correct ( )

virtual

Update mixture properties.

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::thermo2().

Here is the caller graph for this function:

◆ incompressible()

virtual bool incompressible ( ) const

virtual

Return true if the equation of state is incompressible.

i.e. rho != f(p)

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::thermo2().

Here is the caller graph for this function:

◆ isochoric()

virtual bool isochoric ( ) const

virtual

Return true if the equation of state is isochoric.

i.e. rho = const

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::thermo2().

Here is the caller graph for this function:

◆ he() [1/5]

virtual volScalarField& he ( )

inlinevirtual

Enthalpy/Internal energy [J/kg].

Non-const access allowed for transport equations

Implements basicThermo.

Definition at line 128 of file twoPhaseMixtureThermo.H.

Referenced by twoPhaseMixtureThermo::he(), and twoPhaseMixtureThermo::thermo2().

Here is the caller graph for this function:

◆ he() [2/5]

virtual const volScalarField& he ( ) const

inlinevirtual

Enthalpy/Internal energy [J/kg].

Implements basicThermo.

Definition at line 135 of file twoPhaseMixtureThermo.H.

References twoPhaseMixtureThermo::alphaEff(), cells, twoPhaseMixtureThermo::Cp(), twoPhaseMixtureThermo::CpByCpv(), twoPhaseMixtureThermo::Cpv(), twoPhaseMixtureThermo::Cv(), twoPhaseMixtureThermo::gamma(), h, twoPhaseMixtureThermo::hc(), twoPhaseMixtureThermo::he(), twoPhaseMixtureThermo::kappa(), twoPhaseMixtureThermo::kappaEff(), NotImplemented, twoPhaseMixtureThermo::nu(), basicThermo::p(), patchi, twoPhaseMixtureThermo::read(), basicThermo::T(), and twoPhaseMixtureThermo::THE().

Here is the call graph for this function:

◆ he() [3/5]

virtual tmp<volScalarField> he	(	const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Enthalpy/Internal energy.

for given pressure and temperature [J/kg]

Implements basicThermo.

◆ he() [4/5]

virtual tmp<scalarField> he	(	const scalarField &	p,
		const scalarField &	T,
		const labelList &	cells
	)		const

virtual

Enthalpy/Internal energy for cell-set [J/kg].

Implements basicThermo.

◆ he() [5/5]

virtual tmp<scalarField> he	(	const scalarField &	p,
		const scalarField &	T,
		const label	patchi
	)		const

virtual

Enthalpy/Internal energy for patch [J/kg].

Implements basicThermo.

◆ hc()

virtual tmp<volScalarField> hc ( ) const

virtual

Chemical enthalpy [J/kg].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ THE() [1/2]

virtual tmp<scalarField> THE	(	const scalarField &	h,
		const scalarField &	p,
		const scalarField &	T0,
		const labelList &	cells
	)		const

virtual

Temperature from enthalpy/internal energy for cell-set.

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ THE() [2/2]

virtual tmp<scalarField> THE	(	const scalarField &	h,
		const scalarField &	p,
		const scalarField &	T0,
		const label	patchi
	)		const

virtual

Temperature from enthalpy/internal energy for patch.

Implements basicThermo.

◆ Cp() [1/2]

virtual tmp<volScalarField> Cp ( ) const

virtual

Heat capacity at constant pressure [J/kg/K].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ Cp() [2/2]

virtual tmp<scalarField> Cp	(	const scalarField &	p,
		const scalarField &	T,
		const label	patchi
	)		const

virtual

Heat capacity at constant pressure for patch [J/kg/K].

Implements basicThermo.

◆ Cv() [1/2]

virtual tmp<volScalarField> Cv ( ) const

virtual

Heat capacity at constant volume [J/kg/K].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ Cv() [2/2]

virtual tmp<scalarField> Cv	(	const scalarField &	p,
		const scalarField &	T,
		const label	patchi
	)		const

virtual

Heat capacity at constant volume for patch [J/kg/K].

Implements basicThermo.

◆ gamma() [1/2]

virtual tmp<volScalarField> gamma ( ) const

virtual

Gamma = Cp/Cv [].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ gamma() [2/2]

virtual tmp<scalarField> gamma	(	const scalarField &	p,
		const scalarField &	T,
		const label	patchi
	)		const

virtual

Gamma = Cp/Cv for patch [].

Implements basicThermo.

◆ Cpv() [1/2]

virtual tmp<volScalarField> Cpv ( ) const

virtual

Heat capacity at constant pressure/volume [J/kg/K].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ Cpv() [2/2]

virtual tmp<scalarField> Cpv	(	const scalarField &	p,
		const scalarField &	T,
		const label	patchi
	)		const

virtual

Heat capacity at constant pressure/volume for patch [J/kg/K].

Implements basicThermo.

◆ CpByCpv() [1/2]

virtual tmp<volScalarField> CpByCpv ( ) const

virtual

Heat capacity ratio [].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ CpByCpv() [2/2]

virtual tmp<scalarField> CpByCpv	(	const scalarField &	p,
		const scalarField &	T,
		const label	patchi
	)		const

virtual

Heat capacity ratio for patch [].

Implements basicThermo.

◆ nu() [1/2]

virtual tmp<volScalarField> nu ( ) const

virtual

Kinematic viscosity of mixture [m^2/s].

Reimplemented from fluidThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ nu() [2/2]

virtual tmp<scalarField> nu ( const label patchi ) const

virtual

Kinematic viscosity of mixture for patch [m^2/s].

Reimplemented from fluidThermo.

◆ kappa() [1/2]

virtual tmp<volScalarField> kappa ( ) const

virtual

Thermal diffusivity for temperature of mixture [J/m/s/K].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ kappa() [2/2]

virtual tmp<scalarField> kappa ( const label patchi ) const

virtual

Thermal diffusivity of mixture for patch [J/m/s/K].

Implements basicThermo.

◆ kappaEff() [1/2]

virtual tmp<volScalarField> kappaEff ( const volScalarField & alphat ) const

virtual

Effective thermal diffusivity of mixture [J/m/s/K].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ kappaEff() [2/2]

virtual tmp<scalarField> kappaEff	(	const scalarField &	alphat,
		const label	patchi
	)		const

virtual

Effective thermal diffusivity of mixture for patch [J/m/s/K].

Implements basicThermo.

◆ alphaEff() [1/2]

virtual tmp<volScalarField> alphaEff ( const volScalarField & alphat ) const

virtual

Effective thermal diffusivity of mixture [J/m/s/K].

Implements basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

◆ alphaEff() [2/2]

virtual tmp<scalarField> alphaEff	(	const scalarField &	alphat,
		const label	patchi
	)		const

virtual

Effective thermal diffusivity of mixture for patch [J/m/s/K].

Implements basicThermo.

◆ read()

virtual bool read ( )

virtual

Read base transportProperties dictionary.

Reimplemented from basicThermo.

Referenced by twoPhaseMixtureThermo::he().

Here is the caller graph for this function:

The documentation for this class was generated from the following file:

applications/solvers/multiphase/compressibleInterFoam/twoPhaseMixtureThermo/twoPhaseMixtureThermo.H

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ twoPhaseMixtureThermo()

◆ ~twoPhaseMixtureThermo()

Member Function Documentation

◆ TypeName()

◆ thermo1() [1/2]

◆ thermo2() [1/2]

◆ thermo1() [2/2]

◆ thermo2() [2/2]

◆ correctThermo()

◆ correct()

◆ incompressible()

◆ isochoric()

◆ he() [1/5]

◆ he() [2/5]

◆ he() [3/5]

◆ he() [4/5]

◆ he() [5/5]

◆ hc()

◆ THE() [1/2]

◆ THE() [2/2]

◆ Cp() [1/2]

◆ Cp() [2/2]

◆ Cv() [1/2]

◆ Cv() [2/2]

◆ gamma() [1/2]

◆ gamma() [2/2]

◆ Cpv() [1/2]

◆ Cpv() [2/2]

◆ CpByCpv() [1/2]

◆ CpByCpv() [2/2]

◆ nu() [1/2]

◆ nu() [2/2]

◆ kappa() [1/2]

◆ kappa() [2/2]

◆ kappaEff() [1/2]

◆ kappaEff() [2/2]

◆ alphaEff() [1/2]

◆ alphaEff() [2/2]

◆ read()
