Inheritance diagram for drippingInjection:

Collaboration diagram for drippingInjection:

[legend]

Public Member Functions
	TypeName ("drippingInjection")
	Runtime type information. More...

	drippingInjection (surfaceFilmModel &film, const dictionary &dict)
	Construct from surface film model. More...

virtual	~drippingInjection ()
	Destructor. More...

virtual void	correct (scalarField &availableMass, scalarField &massToInject, scalarField &diameterToInject)
	Correct. More...

Public Member Functions inherited from injectionModel
	TypeName ("injectionModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, injectionModel, dictionary,(surfaceFilmModel &film, const dictionary &dict),(film, dict))

	injectionModel (surfaceFilmModel &film)
	Construct null. More...

	injectionModel (const word &modelType, surfaceFilmModel &film, const dictionary &dict)
	Construct from type name, dictionary and surface film model. More...

virtual	~injectionModel ()
	Destructor. More...

virtual scalar	injectedMassTotal () const
	Return the total mass injected. More...

virtual void	patchInjectedMassTotals (scalarField &patchMasses) const
	Accumulate the total mass injected for the patches into the. More...

Public Member Functions inherited from filmSubModelBase
	filmSubModelBase (surfaceFilmModel &film)
	Construct null. More...

	filmSubModelBase (surfaceFilmModel &film, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from film film wihout name. More...

	filmSubModelBase (const word &modelName, surfaceFilmModel &film, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from film film with name. More...

virtual	~filmSubModelBase ()
	Destructor. More...

virtual bool	writeTime () const
	Flag to indicate when to write a property. More...

const surfaceFilmModel &	film () const
	Return const access to the film surface film model. More...

surfaceFilmModel &	film ()
	Return the reference to the film surface film model. More...

template<class FilmType >
const FilmType &	filmType () const

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)
	Construct null. More...

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from components without name. More...

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from components with name. More...

	subModelBase (const subModelBase &smb)
	Construct as copy. More...

virtual	~subModelBase ()
	Destructor. More...

const word &	modelName () const
	Return const access to the name of the sub-model. More...

const dictionary &	dict () const
	Return const access to the cloud dictionary. More...

const word &	baseName () const
	Return const access to the base name of the sub-model. More...

const word &	modelType () const
	Return const access to the sub-model type. More...

const dictionary &	coeffDict () const
	Return const access to the coefficients dictionary. More...

const dictionary &	properties () const
	Return const access to the properties dictionary. More...

virtual bool	defaultCoeffs (const bool printMsg) const
	Returns true if defaultCoeffs is true and outputs on printMsg. More...

virtual bool	active () const
	Return the model 'active' status - default active = true. More...

virtual void	cacheFields (const bool store)
	Cache dependant sub-model fields. More...

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the base model. More...

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const
	Retrieve generic property from the base model. More...

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)
	Add generic property to the base model. More...

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const
	Retrieve generic property from the sub-model. More...

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the sub-model. More...

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)
	Add generic property to the sub-model. More...

virtual void	write (Ostream &os) const
	Write. More...

Protected Attributes
scalar	deltaStable_
	Stable film thickness - drips only formed if thickness. More...

scalar	particlesPerParcel_
	Number of particles per parcel. More...

cachedRandom	rndGen_
	Random number generator. More...

const autoPtr< distributionModel >	parcelDistribution_
	Parcel size PDF model. More...

scalarList	diameter_
	Diameters of particles to inject into the dripping. More...

Protected Attributes inherited from filmSubModelBase
surfaceFilmModel &	filmModel_
	Reference to the film surface film model. More...

Protected Attributes inherited from subModelBase
const word	modelName_
	Name of the sub-model. More...

dictionary &	properties_
	Reference to properties dictionary e.g. for restart. More...

const dictionary	dict_
	Copy of dictionary used during construction. More...

const word	baseName_
	Name of the sub-model base class. More...

const word	modelType_
	Type of the sub-model. More...

const dictionary	coeffDict_
	Coefficients dictionary. More...

Additional Inherited Members
Static Public Member Functions inherited from injectionModel
static autoPtr< injectionModel >	New (surfaceFilmModel &film, const dictionary &dict, const word &mdoelType)
	Return a reference to the selected injection model. More...

Protected Member Functions inherited from injectionModel
void	addToInjectedMass (const scalar dMass)
	Add to injected mass. More...

void	correct ()
	Correct. More...

Protected Member Functions inherited from subModelBase
bool	inLine () const
	Flag to indicate whether data is/was read in-line. More...

Detailed Description

Definition at line 59 of file drippingInjection.H.

Constructor & Destructor Documentation

◆ drippingInjection()

drippingInjection	(	surfaceFilmModel &	film,
		const dictionary &	dict
	)

Construct from surface film model.

Definition at line 52 of file drippingInjection.C.

◆ ~drippingInjection()

~drippingInjection ( )

virtual

Destructor.

Definition at line 75 of file drippingInjection.C.

References injectionModel::correct().

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "drippingInjection" )

Runtime type information.

◆ correct()

void correct	(	scalarField &	availableMass,
		scalarField &	massToInject,
		scalarField &	diameterToInject
	)

virtual

Correct.

Implements injectionModel.

Definition at line 82 of file drippingInjection.C.

References injectionModel::addToInjectedMass(), injectionModel::correct(), delta, kinematicSingleLayer::delta(), drippingInjection::deltaStable_, drippingInjection::diameter_, filmSubModelBase::film(), forAll, kinematicSingleLayer::gNorm(), singleLayerRegion::magSf(), Foam::max(), Foam::min(), primitiveMesh::nCells(), drippingInjection::parcelDistribution_, drippingInjection::particlesPerParcel_, Foam::constant::mathematical::pi(), Foam::pow3(), regionModel::regionMesh(), rho, and kinematicSingleLayer::rho().

Here is the call graph for this function:

Member Data Documentation

◆ deltaStable_

scalar deltaStable_

protected

Stable film thickness - drips only formed if thickness.

execeeds this threhold value

Definition at line 80 of file drippingInjection.H.

Referenced by drippingInjection::correct().

◆ particlesPerParcel_

scalar particlesPerParcel_

protected

Number of particles per parcel.

Definition at line 83 of file drippingInjection.H.

Referenced by drippingInjection::correct().

◆ rndGen_

cachedRandom rndGen_

protected

Random number generator.

Definition at line 86 of file drippingInjection.H.

◆ parcelDistribution_

const autoPtr<distributionModel> parcelDistribution_

protected

Parcel size PDF model.

Definition at line 90 of file drippingInjection.H.

Referenced by drippingInjection::correct().

◆ diameter_

scalarList diameter_

protected

Diameters of particles to inject into the dripping.

Definition at line 93 of file drippingInjection.H.

Referenced by drippingInjection::correct().

The documentation for this class was generated from the following files:

src/regionModels/surfaceFilmModels/submodels/kinematic/injectionModel/drippingInjection/drippingInjection.H
src/regionModels/surfaceFilmModels/submodels/kinematic/injectionModel/drippingInjection/drippingInjection.C
