A zoneGenerator which converts the point, cell and face zones from a list of zoneGenerators into a pointZone. More...

Inheritance diagram for point:

Collaboration diagram for point:

Public Member Functions
	TypeName ("point")
	Runtime type information. More...

	point (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

virtual	~point ()
	Destructor. More...

virtual zoneSet	generate () const
	Generate and return the zoneSet. More...

Public Member Functions inherited from zoneGenerator
	TypeName ("zoneGenerator")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, zoneGenerator, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	zoneGenerator (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from name, polyMesh and dictionary. More...

	zoneGenerator (const zoneGenerator &)=delete
	Disallow default bitwise copy construction. More...

virtual	~zoneGenerator ()
	Destructor. More...

const word &	name () const

const word &	zoneName () const

bool	moveUpdate () const
	Return true if the zoneGenerator updates any of the zones. More...

virtual zoneSet	movePoints () const
	Regenerate the zoneSet following mesh point motion. More...

void	operator= (const zoneGenerator &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from zoneGenerator
static autoPtr< zoneGenerator >	New (const word &name, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const word &name, const zoneTypes &zoneType, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, zoneType, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const polyMesh &mesh, const dictionary &dict)
	Select constructed from mesh and first valid dictionary. More...

static labelList	indices (const boolList &selected)
	Return the list of selected indices. More...

Protected Attributes inherited from zoneGenerator
const word	name_
	Name of zone generator. More...

const dictionary	dict_
	Dictionary cached for error context. More...

const word	zoneName_
	Name of the zone (defaults to the name of the generator) More...

const polyMesh &	mesh_
	Reference to the polyMesh. More...

bool	moveUpdate_
	Switch to update the zones if the mesh points are moved. More...

Detailed Description

A zoneGenerator which converts the point, cell and face zones from a list of zoneGenerators into a pointZone.

If a pointZone with the same name as the pointZone to be generated is returned by a zoneGenerator in the list it is ignored.

Usage

Property	Description	Required	Default value
`type`	Type: point	yes
`name`	Name of the zone	no	zoneGenerator name
`moveUpdate`	Switch to update after mesh motion	no	false

To convert cellZone named cone1 generated by

        cone1
        {
            type        truncatedCone;
            zoneType    cell;

            point1      (-0.0075 0 -1);
            point2      (-0.003 0.0025 1);
            radius1     0.001;
            radius2     0.0005;
        }

into a pointZone also named cone1, the following zoneGenerator named cone1Points can be used

        cone1Points
        {
            type        point;
            name        cone1;

            cone1;
        }

If there is also a faceZone named cone1 which should not be included in the conversion to the pointZone the lookup of the cone1 can specify the cellZone type:

        cone1Points
        {
            type        point;
            name        cone1;

            cone1
            {
                zoneType    cell;
            }
        }

Source files

point_zoneGenerator.H point_
zoneGenerator.C

Definition at line 122 of file point_zoneGenerator.H.

Constructor & Destructor Documentation

◆ point()

point	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from dictionary.

Definition at line 49 of file point_zoneGenerator.C.

◆ ~point()

~point ( )

virtual

Destructor.

Definition at line 63 of file point_zoneGenerator.C.

Member Function Documentation

◆ TypeName()

TypeName ( "point" )

Runtime type information.

◆ generate()

Foam::zoneSet generate ( ) const

virtual

Generate and return the zoneSet.

Implements zoneGenerator.

Definition at line 69 of file point_zoneGenerator.C.

References zoneSet::cValid(), zoneSet::cZone(), f(), forAll, zoneSet::fValid(), zoneSet::fZone(), Zone< ZoneType, ZonesType >::name(), zoneSet::pValid(), and zoneSet::pZone().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/meshTools/zoneGenerators/point/point/point_zoneGenerator.H
src/meshTools/zoneGenerators/point/point/point_zoneGenerator.C
