A zoneGenerator which constructs a faceZone from a set of patches. More...

Inheritance diagram for patch:

Collaboration diagram for patch:

Public Member Functions
	TypeName ("patch")
	Runtime type information. More...

	patch (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

virtual	~patch ()
	Destructor. More...

virtual zoneSet	generate () const
	Generate and return the zoneSet. More...

Public Member Functions inherited from zoneGenerator
	TypeName ("zoneGenerator")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, zoneGenerator, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	zoneGenerator (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from name, polyMesh and dictionary. More...

	zoneGenerator (const zoneGenerator &)=delete
	Disallow default bitwise copy construction. More...

virtual	~zoneGenerator ()
	Destructor. More...

const word &	name () const

const word &	zoneName () const

bool	moveUpdate () const
	Return true if the zoneGenerator updates any of the zones. More...

virtual zoneSet	movePoints () const
	Regenerate the zoneSet following mesh point motion. More...

void	operator= (const zoneGenerator &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from zoneGenerator
static autoPtr< zoneGenerator >	New (const word &name, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const word &name, const zoneTypes &zoneType, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, zoneType, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const polyMesh &mesh, const dictionary &dict)
	Select constructed from mesh and first valid dictionary. More...

static labelList	indices (const boolList &selected)
	Return the list of selected indices. More...

Protected Attributes inherited from zoneGenerator
const word	name_
	Name of zone generator. More...

const dictionary	dict_
	Dictionary cached for error context. More...

const word	zoneName_
	Name of the zone (defaults to the name of the generator) More...

const polyMesh &	mesh_
	Reference to the polyMesh. More...

bool	moveUpdate_
	Switch to update the zones if the mesh points are moved. More...

Detailed Description

A zoneGenerator which constructs a faceZone from a set of patches.

The returned faceZone is oriented and provides the corresponding flipMap.

Usage

Property	Description	Required	Default value
`type`	Type: face	yes
`name`	Name of the zone	no	zoneGenerator name
`patch`	Name of patch	no
`patches`	List of patch names	no	()
`moveUpdate`	Switch to update after mesh motion	no	false

To convert patch named freeSurface into a faceZone of the same name:

        freeSurface
        {
            type        patch;
            patch       freeSurface;
        }

Source files

Definition at line 101 of file patch_zoneGenerator.H.

Constructor & Destructor Documentation

Construct from dictionary.

Definition at line 49 of file patch_zoneGenerator.C.

~patch ( )

virtual

Destructor.

Definition at line 63 of file patch_zoneGenerator.C.

TypeName ( "patch" )

Runtime type information.

Foam::zoneSet generate ( ) const

virtual

Generate and return the zoneSet.

Definition at line 69 of file patch_zoneGenerator.C.

Here is the call graph for this function:

The documentation for this class was generated from the following files:
