solitary Class Reference

Solitary wave model. More...

Inheritance diagram for solitary:

Collaboration diagram for solitary:

Public Member Functions
	TypeName ("solitary")
	Runtime type information. More...
	solitary (const solitary &wave)
	Construct a copy. More...
	solitary (const dictionary &dict, const scalar g)
	Construct from a dictionary and gravity. More...
virtual autoPtr< waveModel >	clone () const
	Construct a clone. More...
virtual	~solitary ()
	Destructor. More...
scalar	depth () const
	Get the depth. More...
scalar	amplitude () const
	Get the amplitude. More...
scalar	offset () const
	Get the offset. More...
scalar	celerity () const
	The wave celerity [m/s]. More...
virtual tmp< scalarField >	elevation (const scalar t, const scalarField &x) const
	Get the wave elevation at a given time and local coordinates. Local. More...
virtual tmp< vector2DField >	velocity (const scalar t, const vector2DField &xz) const
	Get the wave velocity at a given time and local coordinates. Local. More...
virtual void	write (Ostream &os) const
	Write. More...
Public Member Functions inherited from waveModel
	TypeName ("waveModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, waveModel, dictionary,(const dictionary &dict, const scalar g),(dict, g))
	waveModel (const waveModel &wave)
	Construct a copy. More...
	waveModel (const dictionary &dict, const scalar g)
	Construct from a dictionary and gravity. More...
virtual	~waveModel ()
	Destructor. More...
scalar	g () const
	Get the value of gravity. More...

Additional Inherited Members
Static Public Member Functions inherited from waveModel
static autoPtr< waveModel >	New (const dictionary &dict, const scalar g)
	Select. More...
static autoPtr< waveModel >	New (const word &type, const dictionary &dict, const scalar g)
	Select. More...

Detailed Description

Solitary wave model.

Reference:

    Dean, R. G., & Dalrymple, R. A. (1991).
    Water wave mechanics for engineers and scientists (Vol. 2).
    World Scientific Publishing Company.

See pages 314-317.

Usage

Property	Description	Required?	Default
depth	The water depth [m]	no	great
amplitude	Peak amplitude [m]	yes
offset	The positional offset [m]	yes

Example specification in constant/waveProperties:

    waves
    (
        solitary
        {
            length      40;
            amplitude   0.5;
            offset      0;
        }
    );

Source files

• solitary.H
• solitary.C

Definition at line 100 of file solitary.H.

Constructor & Destructor Documentation

solitary() [1/2]

solitary

(

const solitary &

wave

)

Construct a copy.

Definition at line 86 of file solitary.C.

Referenced by solitary::clone().

Here is the caller graph for this function:

solitary() [2/2]

solitary	(	const dictionary &	dict,
		const scalar	g
	)

Construct from a dictionary and gravity.

Definition at line 95 of file solitary.C.

~solitary()

~solitary ( )

virtual

Destructor.

Definition at line 110 of file solitary.C.

Member Function Documentation

TypeName()

TypeName

(

"solitary"

)

Runtime type information.

clone()

virtual autoPtr<waveModel> clone ( ) const

inlinevirtual

Construct a clone.

Implements waveModel.

Definition at line 155 of file solitary.H.

References solitary::solitary().

Here is the call graph for this function:

depth()

scalar depth ( ) const

inline

Get the depth.

Definition at line 170 of file solitary.H.

amplitude()

scalar amplitude ( ) const

inline

Get the amplitude.

Definition at line 176 of file solitary.H.

offset()

scalar offset ( ) const

inline

Get the offset.

Definition at line 182 of file solitary.H.

celerity()

Foam::scalar celerity ( ) const

virtual

The wave celerity [m/s].

Implements waveModel.

Definition at line 56 of file solitary.C.

References alpha(), and Foam::sqrt().

Here is the call graph for this function:

elevation()

Foam::tmp< Foam::scalarField > elevation ( const scalar  t, const scalarField &  x  ) const

virtual

Get the wave elevation at a given time and local coordinates. Local.

x is aligned with the direction of propagation.

Implements waveModel.

Definition at line 116 of file solitary.C.

References x.

velocity()

Foam::tmp< Foam::vector2DField > velocity ( const scalar  t, const vector2DField &  xz  ) const

virtual

Get the wave velocity at a given time and local coordinates. Local.

x is aligned with the direction of propagation, and z with negative gravity.

Implements waveModel.

Definition at line 126 of file solitary.C.

References Foam::saturationModels::A, alpha(), Field< Type >::component(), k, Foam::max(), Foam::sqr(), Foam::tanh(), and Foam::zip().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Write.

Reimplemented from waveModel.

Definition at line 154 of file solitary.C.

References waveModel::write(), and Foam::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/waves/waveModels/solitary/solitary.H
• src/waves/waveModels/solitary/solitary.C
