Irregular wave model. Phase fraction and velocity field are built up from multiple first-order waves, sampled from a selectable wave spectrum. More...

Inheritance diagram for irregular:

[legend]

Collaboration diagram for irregular:

[legend]

Public Member Functions
	TypeName ("irregular")
	Runtime type information. More...

	irregular (const irregular &wave)
	Construct a copy. More...

	irregular (const dictionary &dict, const scalar g, const word &modelName=irregular::typeName)
	Construct from a dictionary and gravity. More...

virtual autoPtr< waveModel >	clone () const
	Construct a clone. More...

virtual	~irregular ()
	Destructor. More...

scalar	depth () const
	Get the depth. More...

virtual scalar	celerity () const
	The wave celerity [m/s]. More...

virtual tmp< scalarField >	elevation (const scalar t, const scalarField &x) const
	Get the wave elevation at a given time and local coordinates. Local. More...

virtual tmp< vector2DField >	velocity (const scalar t, const vector2DField &xz) const
	Get the wave velocity at a given time and local coordinates. Local. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from waveModel
	TypeName ("waveModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, waveModel, dictionary,(const dictionary &dict, const scalar g),(dict, g))

	waveModel (const waveModel &wave)
	Construct a copy. More...

	waveModel (const dictionary &dict, const scalar g)
	Construct from a dictionary and gravity. More...

virtual	~waveModel ()
	Destructor. More...

scalar	g () const
	Get the value of gravity. More...

Additional Inherited Members
Static Public Member Functions inherited from waveModel
static autoPtr< waveModel >	New (const dictionary &dict, const scalar g)
	Select. More...

static autoPtr< waveModel >	New (const word &type, const dictionary &dict, const scalar g)
	Select. More...

Detailed Description

Irregular wave model. Phase fraction and velocity field are built up from multiple first-order waves, sampled from a selectable wave spectrum.

Usage

Property	Description	Required?	Default
`depth`	The water depth [m]	no	great
`spectrum`	The wave spectrum	yes
`n`	The number of times to sample the spectrum	yes
`span`	The fractional range across which to sample the spectrum	no	(0.01 0.99)
`setFormat`	The format with which to plot the spectrum	no	none

Example specification in constant/waveProperties:

    waves
    (
        irregular
        {
            spectrum    PiersonMoskowitz;

            PiersonMoskowitzCoeffs
            {
                U19_5       15;
            }

            n           16;
            span        (0.01 0.99);
        }
    );

Source files

Definition at line 113 of file irregular.H.

Constructor & Destructor Documentation

◆ irregular() [1/2]

irregular ( const irregular & wave )

Construct a copy.

Definition at line 57 of file irregular.C.

Referenced by irregular::clone().

Here is the caller graph for this function:

◆ irregular() [2/2]

irregular	(	const dictionary &	dict,
		const scalar	g,
		const word &	modelName = `irregular::typeName`
	)

Construct from a dictionary and gravity.

Definition at line 71 of file irregular.C.

References AiryCoeffs::celerity(), Foam::cwd(), Foam::endl(), f(), Foam::fv::ff(), UList< T >::first(), Pair< Type >::first(), forAll, waveModel::g(), Foam::identityMap(), Foam::Info, Foam::j0(), Foam::j1(), UList< T >::last(), AiryCoeffs::length, UPstream::master(), Foam::max(), Foam::modelName(), writeFile::outputPrefix, rndGen(), Pair< Type >::second(), Foam::sqr(), Foam::sqrt(), Foam::constant::mathematical::twoPi(), and x.

Here is the call graph for this function:

◆ ~irregular()

~irregular ( )

virtual

Destructor.

Definition at line 231 of file irregular.C.

Member Function Documentation

◆ TypeName()

TypeName ( "irregular" )

Runtime type information.

◆ clone()

virtual autoPtr<waveModel> clone ( ) const

inlinevirtual

Construct a clone.

Implements waveModel.

Definition at line 170 of file irregular.H.

References irregular::irregular().

Here is the call graph for this function:

◆ depth()

scalar depth ( ) const

inline

Get the depth.

Definition at line 185 of file irregular.H.

◆ celerity()

Foam::scalar celerity ( ) const

virtual

The wave celerity [m/s].

Implements waveModel.

Definition at line 237 of file irregular.C.

◆ elevation()

Foam::tmp< Foam::scalarField > elevation	(	const scalar	t,
		const scalarField &	x
	)		const

virtual

Get the wave elevation at a given time and local coordinates. Local.

x is aligned with the direction of propagation.

Implements waveModel.

Definition at line 243 of file irregular.C.

References forAll, tmp< T >::ref(), and x.

Here is the call graph for this function:

◆ velocity()

Foam::tmp< Foam::vector2DField > velocity	(	const scalar	t,
		const vector2DField &	xz
	)		const

virtual

Get the wave velocity at a given time and local coordinates. Local.

x is aligned with the direction of propagation, and z with negative gravity.

Implements waveModel.

Definition at line 261 of file irregular.C.

References forAll, tmp< T >::ref(), List< T >::size(), and VectorSpace< Form, Cmpt, Ncmpts >::zero.

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Reimplemented from waveModel.

Definition at line 279 of file irregular.C.

References token::BEGIN_BLOCK, Foam::decrIndent(), token::END_BLOCK, Foam::incrIndent(), Foam::indent(), Foam::nl, Ostream::write(), waveModel::write(), Foam::writeEntry(), and Foam::writeEntryIfDifferent().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/waves/waveModels/irregular/irregular.H
src/waves/waveModels/irregular/irregular.C
