Model for the wall lubrication force between two phases. More...

Inheritance diagram for wallLubricationModel:

[legend]

Collaboration diagram for wallLubricationModel:

Public Member Functions
	TypeName ("wallLubricationModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, wallLubricationModel, dictionary,(const dictionary &dict, const phaseInterface &interface),(dict, interface))

	wallLubricationModel (const dictionary &dict, const phaseInterface &interface)
	Construct from a dictionary and an interface. More...

virtual	~wallLubricationModel ()
	Destructor. More...

virtual tmp< volVectorField >	F () const =0
	Return wall lubrication force. More...

virtual tmp< surfaceScalarField >	Ff () const =0
	Return face wall lubrication force. More...

Public Member Functions inherited from wallDependentModel
	wallDependentModel (const fvMesh &mesh)
	Construct from a mesh. More...

	wallDependentModel (const wallDependentModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~wallDependentModel ()
	Destructor. More...

const volScalarField &	yWall () const
	Return the wall distance, creating and storing it if necessary. More...

const volVectorField &	nWall () const
	Return the wall normal, creating and storing it if necessary. More...

void	operator= (const wallDependentModel &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< wallLubricationModel >	New (const dictionary &dict, const phaseInterface &interface, const bool outer=true)

Static Public Attributes
static const dimensionSet	dimF
	Coefficient dimensions. More...

Protected Member Functions
tmp< volVectorField >	zeroGradWalls (tmp< volVectorField >) const
	Zero-gradient wall-lubrication force at walls. More...

Detailed Description

Model for the wall lubrication force between two phases.

Source files

Definition at line 53 of file wallLubricationModel.H.

Constructor & Destructor Documentation

◆ wallLubricationModel()

wallLubricationModel	(	const dictionary &	dict,
		const phaseInterface &	interface
	)

Construct from a dictionary and an interface.

Definition at line 69 of file wallLubricationModel.C.

◆ ~wallLubricationModel()

~wallLubricationModel ( )

virtual

Destructor.

Definition at line 81 of file wallLubricationModel.C.

Member Function Documentation

◆ zeroGradWalls()

Foam::tmp< Foam::volVectorField > zeroGradWalls ( tmp< volVectorField > tFi ) const

protected

Zero-gradient wall-lubrication force at walls.

Definition at line 44 of file wallLubricationModel.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryFieldRef(), forAll, DimensionedField< Type, GeoMesh, PrimitiveField >::mesh(), patches, patchi, fvPatchField< Type >::patchInternalField(), and tmp< T >::ref().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "wallLubricationModel" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		wallLubricationModel	,
		dictionary	,
		(const dictionary &dict, const phaseInterface &interface)	,
		(dict, interface)
	)

◆ New()

Foam::autoPtr< Foam::wallLubricationModel > New	(	const dictionary &	dict,
		const phaseInterface &	interface,
		const bool	outer = `true`
	)

static

Definition at line 31 of file wallLubricationModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, dictionary::lookup(), phaseInterface::name(), and Foam::outer().

Here is the call graph for this function:

◆ F()

virtual tmp<volVectorField> F ( ) const

pure virtual

Return wall lubrication force.

Implemented in noWallLubrication, and dispersedWallLubricationModel.

Referenced by blendedWallLubricationModel::F().

Here is the caller graph for this function:

◆ Ff()

virtual tmp<surfaceScalarField> Ff ( ) const

pure virtual

Return face wall lubrication force.

Implemented in noWallLubrication, and dispersedWallLubricationModel.

Referenced by blendedWallLubricationModel::Ff().

Here is the caller graph for this function:

Member Data Documentation

◆ dimF

const Foam::dimensionSet dimF

static

Coefficient dimensions.

Definition at line 89 of file wallLubricationModel.H.

Referenced by blendedWallLubricationModel::F(), and blendedWallLubricationModel::Ff().

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/phaseSystem/interfacialModels/wallLubricationModels/wallLubricationModel/wallLubricationModel.H
applications/modules/multiphaseEuler/phaseSystem/interfacialModels/wallLubricationModels/wallLubricationModel/wallLubricationModel.C
applications/modules/multiphaseEuler/phaseSystem/interfacialModels/wallLubricationModels/wallLubricationModel/wallLubricationModelNew.C
