Calculates and writes the estimated flow heat transfer coefficient at wall patches as the volScalarField field 'wallHeatTransferCoeff' using Reynolds Analogy. More...

Inheritance diagram for ReynoldsAnalogy:

[legend]

Collaboration diagram for ReynoldsAnalogy:

[legend]

Public Member Functions
	TypeName ("ReynoldsAnalogy")
	Runtime type information. More...

	ReynoldsAnalogy (const word &name, const fvMesh &mesh, const dictionary &dict)
	Construct from name, mesh and dict. More...

	ReynoldsAnalogy (const ReynoldsAnalogy &)=delete
	Disallow default bitwise copy construction. More...

virtual	~ReynoldsAnalogy ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the ReynoldsAnalogy data. More...

virtual tmp< volScalarField >	htcByRhoCp (const momentumTransportModel &mmtm, const labelHashSet &patches) const
	Calculate the heat transfer coefficient. More...

void	operator= (const ReynoldsAnalogy &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from wallHeatTransferCoeffModel
	TypeName ("wallHeatTransferCoeffModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, wallHeatTransferCoeffModel, word,(const word &name, const fvMesh &mesh, const dictionary &dict),(name, mesh, dict))

	wallHeatTransferCoeffModel (const word &name, const fvMesh &mesh, const dictionary &)
	Construct from name, mesh and dict. More...

	wallHeatTransferCoeffModel (const wallHeatTransferCoeffModel &)=delete
	Disallow default bitwise copy construction. More...

autoPtr< wallHeatTransferCoeffModel >	clone () const
	Clone. More...

virtual	~wallHeatTransferCoeffModel ()
	Destructor. More...

tmp< surfaceVectorField >	tau (const momentumTransportModel &mmtm, const fvMesh &mesh) const
	Calculate wall shear stress. More...

void	operator= (const wallHeatTransferCoeffModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from wallHeatTransferCoeffModel
static autoPtr< wallHeatTransferCoeffModel >	New (const word &name, const fvMesh &mesh, const dictionary &)
	Return a reference to the selected subset. More...

Detailed Description

Calculates and writes the estimated flow heat transfer coefficient at wall patches as the volScalarField field 'wallHeatTransferCoeff' using Reynolds Analogy.

Reynolds Analogy model, given by:

$htc = 0.5 \rho C_p |U_{ref}| C_f$

where

	=	Density [kg/m^3]
	=	Specific heat capacity [m^2/K/s^2)]
	=	Far field velocity magnitude [m/s]
	=	Skin friction coefficient []

All wall patches are included by default; to restrict the calculation to certain patches, use the optional 'patches' entry.

Example of function object specification:

    ReynoldsAnalogy1
    {
        type       wallHeatTransferCoeff;
        libs       ("libfieldFunctionObjects.so");
        model      ReynoldsAnalogy;
        ...
        region     fluid;
        patches    (".*Wall");
        rho        1.225;
        Cp         1005;
        Uref       1.0;
    }

Usage

Property	Description	Required	Default value
`type`	type name: wallHeatTransferCoeff	yes
`model`	Type name: ReynoldsAnalogy	no	kappaEff
`patches`	List of patches to process	no	all wall patches
`region`	Region to be evaluated	no	default region
`rho`	Density	yes
`Cp`	Specific heat capacity	yes
`Uref`	Reference velocity magnitude	yes	no

Note: Cp and rho are required only for incompressible flow calculations.

Source files

Definition at line 157 of file ReynoldsAnalogy.H.

Constructor & Destructor Documentation

◆ ReynoldsAnalogy() [1/2]

ReynoldsAnalogy	(	const word &	name,
		const fvMesh &	mesh,
		const dictionary &	dict
	)

Construct from name, mesh and dict.

Definition at line 50 of file ReynoldsAnalogy.C.

References dict, and ReynoldsAnalogy::read().

Here is the call graph for this function:

◆ ReynoldsAnalogy() [2/2]

ReynoldsAnalogy ( const ReynoldsAnalogy & )

delete

Disallow default bitwise copy construction.

◆ ~ReynoldsAnalogy()

~ReynoldsAnalogy ( )

virtual

Destructor.

Definition at line 67 of file ReynoldsAnalogy.C.

Member Function Documentation

◆ TypeName()

TypeName ( "ReynoldsAnalogy" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the ReynoldsAnalogy data.

Implements wallHeatTransferCoeffModel.

Definition at line 73 of file ReynoldsAnalogy.C.

References dict.

Referenced by ReynoldsAnalogy::ReynoldsAnalogy().

Here is the caller graph for this function:

◆ htcByRhoCp()

Foam::tmp< Foam::volScalarField > htcByRhoCp	(	const momentumTransportModel &	mmtm,
		const labelHashSet &	patches
	)		const

virtual

Calculate the heat transfer coefficient.

Implements wallHeatTransferCoeffModel.

Definition at line 84 of file ReynoldsAnalogy.C.

References Foam::dimLength, Foam::dimTime, forAll, Foam::mag(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), patchi, tmp< T >::ref(), Foam::sqr(), tau, and Foam::type().

Here is the call graph for this function:

◆ operator=()

void operator= ( const ReynoldsAnalogy & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/functionObjects/field/wallHeatTransferCoeff/wallHeatTransferCoeffModels/ReynoldsAnalogy/ReynoldsAnalogy.H
src/functionObjects/field/wallHeatTransferCoeff/wallHeatTransferCoeffModels/ReynoldsAnalogy/ReynoldsAnalogy.C
