Classes | Public Member Functions | List of all members
treeDataFace Class Reference

Encapsulation of data needed to search for faces. More...

Classes

class  findIntersectOp

class  findNearestOp


Public Member Functions

 ClassName ("treeDataFace")

 treeDataFace (const bool cacheBb, const primitiveMesh &, const labelUList &)
 Construct from mesh and subset of faces. More...

 treeDataFace (const bool cacheBb, const primitiveMesh &, labelList &&)
 Construct from mesh and subset of faces, transferring contents. More...

 treeDataFace (const bool cacheBb, const primitiveMesh &)
 Construct from mesh. Uses all faces in mesh. More...

 treeDataFace (const bool cacheBb, const polyPatch &)
 Construct from mesh. Uses all faces in patch. More...

const labelList & faceLabels () const

const primitiveMesh & mesh () const

label size () const

pointField shapePoints () const
 Get representative point cloud for all shapes inside. More...

volumeType getVolumeType (const indexedOctree< treeDataFace > &, const point &) const
 Get type (inside,outside,mixed,unknown) of point w.r.t. surface. More...

bool overlaps (const label index, const treeBoundBox &sampleBb) const
 Does (bb of) shape at index overlap bb. More...


Detailed Description

Encapsulation of data needed to search for faces.

Source files

Definition at line 58 of file treeDataFace.H.

Constructor & Destructor Documentation

◆ treeDataFace() [1/4]

treeDataFace ( const bool  cacheBb,
const primitiveMesh &  mesh,
const labelUList &  faceLabels
)

Construct from mesh and subset of faces.

Definition at line 82 of file treeDataFace.C.

◆ treeDataFace() [2/4]

treeDataFace ( const bool  cacheBb,
const primitiveMesh &  mesh,
labelList &&  faceLabels
)

Construct from mesh and subset of faces, transferring contents.

Definition at line 98 of file treeDataFace.C.

◆ treeDataFace() [3/4]

treeDataFace ( const bool  cacheBb,
const primitiveMesh &  mesh
)

Construct from mesh. Uses all faces in mesh.

Definition at line 114 of file treeDataFace.C.

◆ treeDataFace() [4/4]

treeDataFace ( const bool  cacheBb,
const polyPatch &  patch
)

Construct from mesh. Uses all faces in patch.

Definition at line 129 of file treeDataFace.C.

Member Function Documentation

◆ ClassName()

ClassName ( "treeDataFace"  )

◆ faceLabels()

const labelList& faceLabels ( ) const
inline

Definition at line 179 of file treeDataFace.H.

Referenced by treeDataFace::findNearestOp::operator()().

Here is the caller graph for this function:

◆ mesh()

const primitiveMesh& mesh ( ) const
inline

Definition at line 184 of file treeDataFace.H.

Referenced by treeDataFace::findNearestOp::operator()().

Here is the caller graph for this function:

◆ size()

label size ( ) const
inline

Definition at line 189 of file treeDataFace.H.

References List< T >::size().

Here is the call graph for this function:

◆ shapePoints()

Foam::pointField shapePoints ( ) const

Get representative point cloud for all shapes inside.

(one point per shape)

Definition at line 168 of file treeDataFace.C.

References primitiveMesh::faceCentres(), forAll, and List< T >::size().

Here is the call graph for this function:

◆ getVolumeType()

Foam::volumeType getVolumeType ( const indexedOctree< treeDataFace > &  oc,
const point &  sample
) const

Get type (inside,outside,mixed,unknown) of point w.r.t. surface.

Only makes sense for closed surfaces.

Definition at line 181 of file treeDataFace.C.

References Foam::abort(), Foam::e, primitiveMesh::edgeFaces(), primitiveMesh::edges(), Foam::endl(), f(), primitiveMesh::faceAreas(), primitiveMesh::faceCentres(), primitiveMesh::faceEdges(), primitiveMesh::faces(), Foam::FatalError, FatalErrorInFunction, forAll, PackedList< nBits >::get(), indexedOctree< Type >::getSide(), PointHit< Point >::hit(), PointIndexHit< Point >::index(), Foam::mag(), Foam::magSqr(), n, line< Point, PointRef >::nearestDist(), pFaces, primitiveMesh::pointFaces(), points, primitiveMesh::points(), Foam::Pout, PointHit< Point >::rawPoint(), Foam::sqr(), volumeType::unknown, and Foam::Zero.

Here is the call graph for this function:

◆ overlaps()

bool overlaps ( const label  index,
const treeBoundBox &  sampleBb
) const

Does (bb of) shape at index overlap bb.

Definition at line 436 of file treeDataFace.C.

References boundBox::containsAny(), f(), primitiveMesh::faceCentres(), primitiveMesh::faces(), forAll, triangleFuncs::intersectBb(), treeBoundBox::overlaps(), points, and primitiveMesh::points().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
