Public Member Functions | Static Public Member Functions | Protected Attributes | List of all members
surfaceWriter Class Referenceabstract

Base class for surface writers. More...

Inheritance diagram for surfaceWriter:
Inheritance graph
[legend]

Public Member Functions

 TypeName ("surfaceWriter")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, surfaceWriter, word,(const IOstream::streamFormat writeFormat, const IOstream::compressionType writeCompression),(writeFormat, writeCompression))

 declareRunTimeSelectionTable (autoPtr, surfaceWriter, dict,(const dictionary &dict),(dict))

 surfaceWriter (const IOstream::streamFormat writeFormat, const IOstream::compressionType writeCompression)
 Construct given write options. More...

 surfaceWriter (const dictionary &dict)
 Construct from dictionary. More...

virtual ~surfaceWriter ()
 Destructor. More...

virtual void write (const fileName &outputDir, const fileName &surfaceName, const pointField &points, const faceList &faces, const wordList &fieldNames, const bool writePointValues #define FieldTypeValuesConstArg(Type, nullArg)) const =0
 Write fields for a single surface to file. More...

virtual void write (const fileName &outputDir, const fileName &surfaceName, const pointField &points, const faceList &faces, const wordList &fieldNames, const bool writePointValues #define FieldTypeValuesConstArg(Type, nullArg)) const
 Write fields for a single surface to file. More...

void write (const fileName &outputDir, const fileName &surfaceName, const pointField &points, const faceList &faces) const
 Write the surface geometry only. More...

template<class ... Args>
void write (const fileName &outputDir, const fileName &surfaceName, const pointField &points, const faceList &faces, const bool writePointValues, const Args &... args) const
 Write fields for a single surface to file. For use in code where. More...


Static Public Member Functions

static autoPtr< surfaceWriter > New (const word &writeType, const IOstream::streamFormat writeFormat, const IOstream::compressionType writeCompression)
 Select given write options. More...

static autoPtr< surfaceWriter > New (const word &writeType, const dictionary &dict)
 Select given a dictionary. More...


Protected Attributes

IOstream::streamFormat writeFormat_
 Write format. More...

IOstream::compressionType writeCompression_
 Write compression. More...


Detailed Description

Base class for surface writers.

Source files

Definition at line 54 of file surfaceWriter.H.

Constructor & Destructor Documentation

◆ surfaceWriter() [1/2]

surfaceWriter ( const IOstream::streamFormat  writeFormat,
const IOstream::compressionType  writeCompression
)

Construct given write options.

Definition at line 43 of file surfaceWriter.C.

◆ surfaceWriter() [2/2]

surfaceWriter ( const dictionary &  dict)

Construct from dictionary.

Definition at line 54 of file surfaceWriter.C.

◆ ~surfaceWriter()

~surfaceWriter ( )
virtual

Destructor.

Definition at line 148 of file surfaceWriter.C.

Member Function Documentation

◆ TypeName()

TypeName ( "surfaceWriter"  )

Runtime type information.

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable ( autoPtr  ,
surfaceWriter  ,
word  ,
(const IOstream::streamFormat writeFormat, const IOstream::compressionType writeCompression)  ,
(writeFormat, writeCompression)
)

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable ( autoPtr  ,
surfaceWriter  ,
dict  ,
(const dictionary &dict)  ,
(dict)
)

◆ New() [1/2]

Foam::autoPtr< Foam::surfaceWriter > New ( const word &  writeType,
const IOstream::streamFormat  writeFormat,
const IOstream::compressionType  writeCompression
)
static

Select given write options.

Definition at line 74 of file surfaceWriter.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and MeshedSurfaceProxy< Face >::writeTypes().

Referenced by checkMesh::execute(), surfaceFieldValue::read(), and sampledSurfaces::read().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::surfaceWriter > New ( const word &  writeType,
const dictionary &  dict
)
static

Select given a dictionary.

Definition at line 110 of file surfaceWriter.C.

◆ write() [1/4]

virtual void write ( const fileName &  outputDir,
const fileName &  surfaceName,
const pointField &  points,
const faceList &  faces,
const wordList &  fieldNames,
const bool writePointValues #define   FieldTypeValuesConstArgType, nullArg
) const
pure virtual

Write fields for a single surface to file.

Implemented in vtkSurfaceWriter, rawSurfaceWriter, proxySurfaceWriter, noSurfaceWriter, foamSurfaceWriter, and ensightSurfaceWriter.

Referenced by Foam::meshCheck::mergeAndWrite(), and surfaceWriter::write().

Here is the caller graph for this function:

◆ write() [2/4]

virtual void write ( const fileName &  outputDir,
const fileName &  surfaceName,
const pointField &  points,
const faceList &  faces,
const wordList &  fieldNames,
const bool writePointValues #define   FieldTypeValuesConstArgType, nullArg
) const
inlinevirtual

Write fields for a single surface to file.

Reimplemented in vtkSurfaceWriter, rawSurfaceWriter, proxySurfaceWriter, noSurfaceWriter, foamSurfaceWriter, and ensightSurfaceWriter.

Definition at line 151 of file surfaceWriter.H.

References fieldNames, FieldTypeValuesParameter, Foam::FOR_ALL_FIELD_TYPES(), points, and surfaceWriter::write().

Here is the call graph for this function:

◆ write() [3/4]

void write ( const fileName &  outputDir,
const fileName &  surfaceName,
const pointField &  points,
const faceList &  faces
) const
inline

Write the surface geometry only.

Definition at line 182 of file surfaceWriter.H.

References FieldTypeValuesParameter, Foam::FOR_ALL_FIELD_TYPES(), points, and surfaceWriter::write().

Here is the call graph for this function:

◆ write() [4/4]

void write ( const fileName &  outputDir,
const fileName &  surfaceName,
const pointField &  points,
const faceList &  faces,
const bool  writePointValues,
const Args &...  args
) const
inline

Write fields for a single surface to file. For use in code where.

the fields that are to be written are known. Takes any number of name, values arguments at the end. E.g.:

write ( Output options "myDirectory", "mySurface",

Geometry pp.localPoints(), pp.localFaces(),

Fields "p", Field<scalar>(pp.size(), ...), "U", Field<vector>(pp.size(), ...) );

Definition at line 223 of file surfaceWriter.H.

References args, DeclareFieldTypeValues, fieldNames, FieldTypeValuesParameter, Foam::FOR_ALL_FIELD_TYPES(), points, setWriter::unpackTypeValueSets(), and surfaceWriter::write().

Here is the call graph for this function:

Member Data Documentation

◆ writeFormat_

IOstream::streamFormat writeFormat_
protected

Write format.

Definition at line 61 of file surfaceWriter.H.

◆ writeCompression_

IOstream::compressionType writeCompression_
protected

Write compression.

Definition at line 64 of file surfaceWriter.H.

The documentation for this class was generated from the following files:
