surfaceSets Class Reference

Various utilities to handle sets relating mesh to surface. Note: work in progress. Used in meshing tools. More...

Static Public Member Functions

static void getSurfaceSets (const polyMesh &mesh, const fileName &surfName, const triSurface &surf, const triSurfaceSearch &querySurf, const pointField &outsidePts, const label nCutLayers, labelHashSet &inside, labelHashSet &outside, labelHashSet &cut)
 Divide cells into cut,inside and outside. More...

static labelHashSet getHangingCells (const primitiveMesh &mesh, const labelHashSet &internalCells)
 Get cells using points on 'outside' only. More...


Detailed Description

Various utilities to handle sets relating mesh to surface. Note: work in progress. Used in meshing tools.

Source files

Definition at line 62 of file surfaceSets.H.

Member Function Documentation

◆ getSurfaceSets()

void getSurfaceSets ( const polyMesh &  mesh,
const fileName &  surfName,
const triSurface &  surf,
const triSurfaceSearch &  querySurf,
const pointField &  outsidePts,
const label  nCutLayers,
labelHashSet &  inside,
labelHashSet &  outside,
labelHashSet &  cut
)
static

Divide cells into cut,inside and outside.

nCutLayers>0 : remove cutCells (set to type inside) if further than nCutLayers away from outside type cell.

Definition at line 221 of file surfaceSets.C.

References cellClassification::CUT, forAll, HashSet< Key, Hash >::insert(), cellClassification::INSIDE, mesh, cellClassification::OUTSIDE, and cellClassification::trimCutCells().

Here is the call graph for this function:

◆ getHangingCells()

Foam::labelHashSet getHangingCells ( const primitiveMesh &  mesh,
const labelHashSet &  internalCells
)
static

Get cells using points on 'outside' only.

Definition at line 271 of file surfaceSets.C.

References cells, primitiveMesh::cells(), f(), polyMesh::faces(), forAll, forAllConstIter, HashTable< T, Key, Hash >::found(), HashSet< Key, Hash >::insert(), mesh, primitiveMesh::nCells(), primitiveMesh::nPoints(), and HashTable< T, Key, Hash >::size().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
