surfacePatch Class Reference

'Patch' on surface as subset of triSurface. More...

Inheritance diagram for surfacePatch:

Collaboration diagram for surfacePatch:

Public Member Functions
	ClassName ("surfacePatch")
	Runtime type information. More...
	surfacePatch ()
	Construct null. More...
	surfacePatch (const word &geometricType, const word &name, const label size, const label start, const label index)
	Construct from components. More...
	surfacePatch (Istream &is, const label index)
	Construct from Istream. More...
	surfacePatch (const word &name, const dictionary &dict, const label index)
	Construct from dictionary. More...
label	start () const
	Return start label of this patch in the polyMesh face list. More...
label &	start ()
	Return start label of this patch in the polyMesh face list. More...
label	size () const
	Return size of this patch in the polyMesh face list. More...
label &	size ()
	Return size of this patch in the polyMesh face list. More...
void	write (Ostream &) const
	Write. More...
void	writeDict (Ostream &) const
	Write dictionary. More...
bool	operator!= (const surfacePatch &) const
bool	operator== (const surfacePatch &) const
	compare. More...
Public Member Functions inherited from geometricSurfacePatch
	ClassName ("geometricSurfacePatch")
	Runtime type information. More...
	geometricSurfacePatch ()
	Construct null. More...
	geometricSurfacePatch (const word &geometricType, const word &name, const label index)
	Construct from components. More...
	geometricSurfacePatch (Istream &, const label index)
	Construct from Istream. More...
	geometricSurfacePatch (const word &name, const dictionary &dict, const label index)
	Construct from dictionary. More...
const word &	name () const
	Return name. More...
word &	name ()
	Return name. More...
const word &	geometricType () const
	Return the type of the patch. More...
word &	geometricType ()
	Return the type of the patch. More...
label	index () const
	Return the index of this patch in the boundaryMesh. More...
label &	index ()
	Return the index of this patch in the boundaryMesh. More...
void	write (Ostream &) const
	Write. More...
void	writeDict (Ostream &) const
	Write dictionary. More...
bool	operator!= (const geometricSurfacePatch &) const
bool	operator== (const geometricSurfacePatch &) const
	compare. More...

Friends
Ostream &	operator<< (Ostream &, const surfacePatch &)

Detailed Description

'Patch' on surface as subset of triSurface.

Source files

• surfacePatch.H
• surfacePatch.C

Definition at line 58 of file surfacePatch.H.

Constructor & Destructor Documentation

surfacePatch() [1/4]

surfacePatch

(

)

Construct null.

Definition at line 39 of file surfacePatch.C.

surfacePatch() [2/4]

surfacePatch	(	const word &	geometricType,
		const word &	name,
		const label	size,
		const label	start,
		const label	index
	)

Construct from components.

Definition at line 47 of file surfacePatch.C.

surfacePatch() [3/4]

surfacePatch	(	Istream &	is,
		const label	index
	)

Construct from Istream.

Definition at line 62 of file surfacePatch.C.

References Foam::readLabel().

Here is the call graph for this function:

surfacePatch() [4/4]

surfacePatch	(	const word &	name,
		const dictionary &	dict,
		const label	index
	)

Construct from dictionary.

Definition at line 73 of file surfacePatch.C.

Member Function Documentation

ClassName()

ClassName

(

"surfacePatch"

)

Runtime type information.

start() [1/2]

label start ( ) const

inline

Return start label of this patch in the polyMesh face list.

Definition at line 107 of file surfacePatch.H.

start() [2/2]

label& start ( )

inline

Return start label of this patch in the polyMesh face list.

Definition at line 113 of file surfacePatch.H.

size() [1/2]

label size ( ) const

inline

Return size of this patch in the polyMesh face list.

Definition at line 119 of file surfacePatch.H.

size() [2/2]

label& size ( )

inline

Return size of this patch in the polyMesh face list.

Definition at line 125 of file surfacePatch.H.

write()

void write

(

Ostream &

os

)

const

Write.

Definition at line 88 of file surfacePatch.C.

References Foam::endl(), Foam::nl, and Foam::tab.

Here is the call graph for this function:

writeDict()

void writeDict

(

Ostream &

os

)

const

Write dictionary.

Definition at line 95 of file surfacePatch.C.

References token::BEGIN_BLOCK, token::END_BLOCK, Foam::endl(), Foam::name(), Foam::nl, and geometricSurfacePatch::writeDict().

Here is the call graph for this function:

operator!=()

bool operator!=

(

const surfacePatch &

p

)

const

Definition at line 109 of file surfacePatch.C.

References p.

operator==()

bool operator==

(

const surfacePatch &

p

)

const

compare.

Definition at line 115 of file surfacePatch.C.

References p.

Friends And Related Function Documentation

operator<<

Ostream& operator<< ( Ostream &  , const surfacePatch &    )

friend

---

The documentation for this class was generated from the following files:

• src/triSurface/triSurface/surfacePatch/surfacePatch.H
• src/triSurface/triSurface/surfacePatch/surfacePatch.C
