This source condition provides the surface area of introduced particles. It converts between the corresponding diameter/etc..., conditions to automatically produce a value for the surface area. It is selected automatically by the functions that need it, so the user should never need to specify this condition explicitly. More...

Inheritance diagram for surfaceAreaLagrangianScalarFieldSource:

[legend]

Collaboration diagram for surfaceAreaLagrangianScalarFieldSource:

[legend]

Public Member Functions
	TypeName ("surfaceArea")
	Runtime type information. More...

	surfaceAreaLagrangianScalarFieldSource (const regIOobject &)
	Construct from internal field. More...

	surfaceAreaLagrangianScalarFieldSource (const regIOobject &, const dictionary &)
	Construct from internal field and dictionary. More...

	surfaceAreaLagrangianScalarFieldSource (const surfaceAreaLagrangianScalarFieldSource &, const regIOobject &)
	Copy constructor setting the internal field reference. More...

virtual autoPtr< LagrangianScalarFieldSource >	clone (const regIOobject &iIo) const
	Construct and return a clone setting the internal field reference. More...

virtual	~surfaceAreaLagrangianScalarFieldSource ()
	Destructor. More...

virtual tmp< LagrangianSubScalarField >	value (const LagrangianInjection &, const LagrangianSubMesh &) const
	Return the value for an instantaneous injection. More...

Detailed Description

This source condition provides the surface area of introduced particles. It converts between the corresponding diameter/etc..., conditions to automatically produce a value for the surface area. It is selected automatically by the functions that need it, so the user should never need to specify this condition explicitly.

Source files

Definition at line 53 of file surfaceAreaLagrangianScalarFieldSource.H.

Constructor & Destructor Documentation

◆ surfaceAreaLagrangianScalarFieldSource() [1/3]

surfaceAreaLagrangianScalarFieldSource ( const regIOobject & iIo )

Construct from internal field.

Definition at line 32 of file surfaceAreaLagrangianScalarFieldSource.C.

Referenced by surfaceAreaLagrangianScalarFieldSource::clone().

Here is the caller graph for this function:

◆ surfaceAreaLagrangianScalarFieldSource() [2/3]

surfaceAreaLagrangianScalarFieldSource	(	const regIOobject &	iIo,
		const dictionary &	dict
	)

Construct from internal field and dictionary.

Definition at line 43 of file surfaceAreaLagrangianScalarFieldSource.C.

◆ surfaceAreaLagrangianScalarFieldSource() [3/3]

surfaceAreaLagrangianScalarFieldSource	(	const surfaceAreaLagrangianScalarFieldSource &	field,
		const regIOobject &	iIo
	)

Copy constructor setting the internal field reference.

Definition at line 55 of file surfaceAreaLagrangianScalarFieldSource.C.

◆ ~surfaceAreaLagrangianScalarFieldSource()

~surfaceAreaLagrangianScalarFieldSource ( )

virtual

Destructor.

Definition at line 69 of file surfaceAreaLagrangianScalarFieldSource.C.

Member Function Documentation

◆ TypeName()

TypeName ( "surfaceArea" )

Runtime type information.

◆ clone()

virtual autoPtr<LagrangianScalarFieldSource> clone ( const regIOobject & iIo ) const

inlinevirtual

Construct and return a clone setting the internal field reference.

Definition at line 84 of file surfaceAreaLagrangianScalarFieldSource.H.

References surfaceAreaLagrangianScalarFieldSource::surfaceAreaLagrangianScalarFieldSource().

Here is the call graph for this function:

◆ value()

Foam::tmp< Foam::LagrangianSubScalarField > value	(	const LagrangianInjection &	injection,
		const LagrangianSubMesh &	subMesh
	)		const
