This is a temperature boundary condition for a specie-transferring wall. More...

Inheritance diagram for specieTransferTemperatureFvPatchScalarField:

Collaboration diagram for specieTransferTemperatureFvPatchScalarField:

Public Member Functions
	TypeName ("specieTransferTemperature")
	Runtime type information. More...

	specieTransferTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &, const bool readValue=true)
	Construct from patch, internal field and dictionary. More...

	specieTransferTemperatureFvPatchScalarField (const specieTransferTemperatureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given fixedValueTypeFvPatchField. More...

	specieTransferTemperatureFvPatchScalarField (const specieTransferTemperatureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	specieTransferTemperatureFvPatchScalarField (const specieTransferTemperatureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

const tmp< scalarField >	phiHep () const
	Return the flux of energy. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

Public Member Functions inherited from mixedEnergyCalculatedTemperatureFvPatchScalarField
	TypeName ("mixedEnergyCalculatedTemperature")
	Run-time type information. More...

	mixedEnergyCalculatedTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	Construct from patch and internal field. More...

	mixedEnergyCalculatedTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	mixedEnergyCalculatedTemperatureFvPatchScalarField (const mixedEnergyCalculatedTemperatureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given. More...

	mixedEnergyCalculatedTemperatureFvPatchScalarField (const mixedEnergyCalculatedTemperatureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	mixedEnergyCalculatedTemperatureFvPatchScalarField (const mixedEnergyCalculatedTemperatureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual bool	fixesValue () const
	Return true if this patch field fixes a value. More...

scalarField &	heRefValue ()
	Access the energy value. More...

const scalarField &	heRefValue () const
	Access the energy value. More...

scalarField &	heRefGrad ()
	Access the energy gradient. More...

const scalarField &	heRefGrad () const
	Access the energy gradient. More...

scalarField &	heValueFraction ()
	Access the energy fraction. More...

const scalarField &	heValueFraction () const
	Access the energy fraction. More...

virtual void	map (const fvPatchScalarField &, const fieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...

virtual void	reset (const fvPatchScalarField &)
	Reset the fvPatchField to the given fvPatchField. More...

Detailed Description

This is a temperature boundary condition for a specie-transferring wall.

This condition must be used in conjunction with mass-fraction boundary conditions derived from specieTransferMassFractionFvPatchScalarField, and a specieTransferVelocity condition for the velocity.

This condition sums the species' energy fluxes generated by the mass-fraction conditions, and uses this total to set the flux of energy into or out of the domain.

Usage

Property	Description	Req'd?	Default
`phi`	Name of the flux field	no	phi
`U`	Name of the velocity field	no	U

Example of the boundary condition specification:

    <patchName>
    {
        type            specieTransferTemperature;
        value           $internalField;
    }

See also: Foam::specieTransferMassFractionFvPatchScalarField Foam::specieTransferVelocityFvPatchScalarField

Source files

Definition at line 91 of file specieTransferTemperatureFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ specieTransferTemperatureFvPatchScalarField() [1/4]

specieTransferTemperatureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict,
		const bool	readValue = `true`
	)

Construct from patch, internal field and dictionary.

Definition at line 38 of file specieTransferTemperatureFvPatchScalarField.C.

References dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), fvPatchField< Type >::operator, and p.

Here is the call graph for this function:

◆ specieTransferTemperatureFvPatchScalarField() [2/4]

specieTransferTemperatureFvPatchScalarField	(	const specieTransferTemperatureFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)
