A topoSetSource to select cells based on cell shape. More...
Public Member Functions | |
| TypeName ("shapeToCell") | |
| Runtime type information. More... | |
| shapeToCell (const polyMesh &mesh, const word &shape) | |
| Construct from components. More... | |
| shapeToCell (const polyMesh &mesh, const dictionary &dict) | |
| Construct from dictionary. More... | |
| virtual | ~shapeToCell () |
| Destructor. More... | |
| virtual sourceType | setType () const |
| virtual void | applyToSet (const topoSetSource::setAction action, topoSet &) const |
 Public Member Functions inherited from topoSetSource | |
| TypeName ("topoSetSource") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, topoSetSource, word,(const polyMesh &mesh, const dictionary &dict),(mesh, dict)) | |
| topoSetSource (const polyMesh &mesh) | |
| Construct from components. More... | |
| topoSetSource (const topoSetSource &)=delete | |
| Disallow default bitwise copy construction. More... | |
| autoPtr< topoSetSource > | clone () const |
| Clone. More... | |
| virtual | ~topoSetSource () |
| Destructor. More... | |
| const polyMesh & | mesh () const |
| void | operator= (const topoSetSource &)=delete |
| Disallow default bitwise assignment. More... | |
Static Public Attributes | |
| static scalar | featureCos = Foam::cos(degToRad(10.0)) |
| Cos of feature angle for polyHedral to be splitHex. More... | |
Additional Inherited Members | |
| Public Types inherited from topoSetSource | |
| enum | sourceType { CELLSETSOURCE , FACESETSOURCE , POINTSETSOURCE , CELLZONESOURCE , FACEZONESOURCE , POINTZONESOURCE } |
| Enumeration defining the types of sources. More... | |
| enum | setAction { CLEAR , NEW , INVERT , ADD , DELETE , SUBSET , LIST , REMOVE } |
| Enumeration defining the valid actions. More... | |
| Static Public Member Functions inherited from topoSetSource | |
| static setAction | toAction (const word &actionName) |
| Convert string to action. More... | |
| static autoPtr< topoSetSource > | New (const word &topoSetSourceType, const polyMesh &mesh, const dictionary &dict) |
| Return a reference to the selected topoSetSource. More... | |
| Protected Member Functions inherited from topoSetSource | |
| void | addOrDelete (topoSet &set, const label celli, const bool) const |
| Add (if bool) celli to set or delete celli from set. More... | |
| Protected Attributes inherited from topoSetSource | |
| const polyMesh & | mesh_ |
A topoSetSource to select cells based on cell shape.
Handles all ones from cellModeller and splitHex with 10 degrees feature angle.
Definition at line 51 of file shapeToCell.H.
| shapeToCell | ( | const polyMesh & | mesh, |
| const word & | shape | ||
| ) |
Construct from components.
Definition at line 79 of file shapeToCell.C.
References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and cellModeller::lookup().
| shapeToCell | ( | const polyMesh & | mesh, |
| const dictionary & | dict | ||
| ) |
Construct from dictionary.
Definition at line 96 of file shapeToCell.C.
References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and cellModeller::lookup().
|
virtual |
Destructor.
Definition at line 115 of file shapeToCell.C.
| TypeName | ( | "shapeToCell" | ) |
Runtime type information.
|
inlinevirtual |
Implements topoSetSource.
Definition at line 102 of file shapeToCell.H.
References topoSetSource::CELLSETSOURCE.
|
virtual |
Implements topoSetSource.
Definition at line 121 of file shapeToCell.C.
References topoSetSource::ADD, Foam::combine(), topoSetSource::DELETE, Foam::endl(), Foam::Info, and topoSetSource::NEW.
Cos of feature angle for polyHedral to be splitHex.
Definition at line 76 of file shapeToCell.H.
