processorLduInterfaceField Class Reference

Abstract base class for processor coupled interfaces. More...

Inheritance diagram for processorLduInterfaceField:

Public Member Functions
	TypeName ("processorLduInterfaceField")
	Runtime type information. More...
	processorLduInterfaceField ()
	Construct given coupled patch. More...
virtual	~processorLduInterfaceField ()
	Destructor. More...
virtual label	comm () const =0
	Return communicator used for comms. More...
virtual int	myProcNo () const =0
	Return processor number. More...
virtual int	neighbProcNo () const =0
	Return neighbour processor number. More...
virtual const transformer &	transform () const =0
	Return transformation between the coupled patches. More...
virtual int	rank () const =0
	Return rank of component for transform. More...
bool	transforms () const
	Is the transform required. More...
template<class Type >
void	transformCoupleField (Field< Type > &f) const
	Transform given patch field. More...
void	transformCoupleField (scalarField &f, const direction cmpt) const
	Transform given patch component field. More...

Detailed Description

Abstract base class for processor coupled interfaces.

Source files

• processorLduInterfaceField.H
• processorLduInterfaceField.C

Definition at line 50 of file processorLduInterfaceField.H.

Constructor & Destructor Documentation

processorLduInterfaceField()

processorLduInterfaceField ( )

inline

Construct given coupled patch.

Definition at line 62 of file processorLduInterfaceField.H.

~processorLduInterfaceField()

~processorLduInterfaceField ( )

virtual

Destructor.

Definition at line 39 of file processorLduInterfaceField.C.

Member Function Documentation

TypeName()

TypeName

(

"processorLduInterfaceField"

)

Runtime type information.

comm()

virtual label comm ( ) const

pure virtual

Return communicator used for comms.

Implemented in processorGAMGInterfaceField, and processorFvPatchField< Type >.

myProcNo()

virtual int myProcNo ( ) const

pure virtual

Return processor number.

Implemented in processorGAMGInterfaceField, and processorFvPatchField< Type >.

neighbProcNo()

virtual int neighbProcNo ( ) const

pure virtual

Return neighbour processor number.

Implemented in processorGAMGInterfaceField, and processorFvPatchField< Type >.

transform()

virtual const transformer& transform ( ) const

pure virtual

Return transformation between the coupled patches.

Implemented in processorGAMGInterfaceField, processorCyclicFvPatchField< Type >, processorFvPatchField< Type >, and nonConformalProcessorCyclicFvPatchField< Type >.

Referenced by processorLduInterfaceField::transformCoupleField(), and processorLduInterfaceField::transforms().

Here is the caller graph for this function:

rank()

virtual int rank ( ) const

pure virtual

Return rank of component for transform.

Implemented in processorGAMGInterfaceField, processorCyclicFvPatchField< Type >, processorFvPatchField< Type >, and nonConformalProcessorCyclicFvPatchField< Type >.

Referenced by processorLduInterfaceField::transforms().

Here is the caller graph for this function:

transforms()

bool transforms ( ) const

inline

Is the transform required.

Definition at line 90 of file processorLduInterfaceField.H.

References processorLduInterfaceField::rank(), processorLduInterfaceField::transform(), and transformer::transforms().

Referenced by processorLduInterfaceField::transformCoupleField().

Here is the call graph for this function:

Here is the caller graph for this function:

transformCoupleField() [1/2]

void transformCoupleField

(

Field< Type > &

f

)

const

Transform given patch field.

Definition at line 118 of file processorLduInterfaceField.H.

References f(), processorLduInterfaceField::transform(), transformer::transform(), and processorLduInterfaceField::transforms().

Here is the call graph for this function:

transformCoupleField() [2/2]

void transformCoupleField	(	scalarField &	f,
		const direction	cmpt
	)		const

Transform given patch component field.

Definition at line 45 of file processorLduInterfaceField.C.

References VectorSpace< Form, Cmpt, Ncmpts >::component(), Foam::diag(), Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, Foam::sqr(), Foam::T(), Foam::transform(), and transforms.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterfaceFields/processorLduInterfaceField/processorLduInterfaceField.H
• src/OpenFOAM/matrices/lduMatrix/lduAddressing/lduInterfaceFields/processorLduInterfaceField/processorLduInterfaceField.C
