Public Member Functions | Friends | List of all members
pointEdgePoint Class Reference

Holds information regarding nearest wall point. Used in PointEdgeWave. (so not standard FaceCellWave) To be used in wall distance calculation. More...

Inheritance diagram for pointEdgePoint:
Inheritance graph
[legend]

Public Member Functions

 pointEdgePoint ()
 Construct null. More...

 pointEdgePoint (const point &, const scalar)
 Construct from origin, distance. More...

const point & origin () const

scalar distSqr () const

template<class TrackingData >
bool valid (TrackingData &td) const
 Check whether origin has been changed at all or. More...

template<class TrackingData >
void transform (const polyPatch &patch, const label patchFacei, const transformer &transform, TrackingData &td)
 Transform across an interface. More...

template<class TrackingData >
bool updatePoint (const polyMesh &mesh, const label pointi, const label edgeI, const pointEdgePoint &edgeInfo, const scalar tol, TrackingData &td)
 Influence of edge on point. More...

template<class TrackingData >
bool updatePoint (const polyMesh &mesh, const label pointi, const pointEdgePoint &newPointInfo, const scalar tol, TrackingData &td)
 Influence of different value on same point. More...

template<class TrackingData >
bool updateEdge (const polyMesh &mesh, const label edgeI, const label pointi, const pointEdgePoint &pointInfo, const scalar tol, TrackingData &td)
 Influence of point on edge. More...

template<class TrackingData >
bool equal (const pointEdgePoint &, TrackingData &td) const
 Same (like operator==) More...

bool operator== (const pointEdgePoint &) const

bool operator!= (const pointEdgePoint &) const


Friends

Ostream & operator<< (Ostream &, const pointEdgePoint &)

Istream & operator>> (Istream &, pointEdgePoint &)


Detailed Description

Holds information regarding nearest wall point. Used in PointEdgeWave. (so not standard FaceCellWave) To be used in wall distance calculation.

Source files

Definition at line 69 of file pointEdgePoint.H.

Constructor & Destructor Documentation

◆ pointEdgePoint() [1/2]

pointEdgePoint ( )
inline

Construct null.

Definition at line 77 of file pointEdgePointI.H.

◆ pointEdgePoint() [2/2]

pointEdgePoint ( const point &  origin,
const scalar  distSqr
)
inline

Construct from origin, distance.

Definition at line 84 of file pointEdgePointI.H.

Member Function Documentation

◆ origin()

const Foam::point & origin ( ) const
inline

Definition at line 97 of file pointEdgePointI.H.

Referenced by pointEdgePoint::operator==().

Here is the caller graph for this function:

◆ distSqr()

Foam::scalar distSqr ( ) const
inline

Definition at line 103 of file pointEdgePointI.H.

Referenced by pointEdgePoint::operator==().

Here is the caller graph for this function:

◆ valid()

bool valid ( TrackingData &  td) const
inline

Check whether origin has been changed at all or.

still contains original (invalid) value.

Definition at line 110 of file pointEdgePointI.H.

References VectorSpace< Form, Cmpt, Ncmpts >::max.

◆ transform()

void transform ( const polyPatch &  patch,
const label  patchFacei,
const transformer &  transform,
TrackingData &  td
)
inline

Transform across an interface.

Definition at line 117 of file pointEdgePointI.H.

References Foam::transform().

Referenced by pointData::transform().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ updatePoint() [1/2]

bool updatePoint ( const polyMesh &  mesh,
const label  pointi,
const label  edgeI,
const pointEdgePoint &  edgeInfo,
const scalar  tol,
TrackingData &  td
)
inline

Influence of edge on point.

Definition at line 132 of file pointEdgePointI.H.

References mesh, and polyMesh::points().

Referenced by pointData::updatePoint().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ updatePoint() [2/2]

bool updatePoint ( const polyMesh &  mesh,
const label  pointi,
const pointEdgePoint &  newPointInfo,
const scalar  tol,
TrackingData &  td
)
inline

Influence of different value on same point.

Merge new and old info.

Definition at line 148 of file pointEdgePointI.H.

References mesh, and polyMesh::points().

Here is the call graph for this function:

◆ updateEdge()

bool updateEdge ( const polyMesh &  mesh,
const label  edgeI,
const label  pointi,
const pointEdgePoint &  pointInfo,
const scalar  tol,
TrackingData &  td
)
inline

Influence of point on edge.

Definition at line 163 of file pointEdgePointI.H.

References Foam::e, primitiveMesh::edges(), mesh, and polyMesh::points().

Referenced by pointData::updateEdge().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ equal()

bool equal ( const pointEdgePoint &  rhs,
TrackingData &  td
) const
inline

Same (like operator==)

Definition at line 179 of file pointEdgePointI.H.

References Foam::operator==().

Here is the call graph for this function:

◆ operator==()

bool operator== ( const pointEdgePoint &  rhs) const
inline

Definition at line 191 of file pointEdgePointI.H.

References pointEdgePoint::distSqr(), and pointEdgePoint::origin().

Referenced by pointData::operator==().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ operator!=()

bool operator!= ( const pointEdgePoint &  rhs) const
inline

Definition at line 198 of file pointEdgePointI.H.

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<< ( Ostream &  ,
const pointEdgePoint &
)
friend

◆ operator>>

Istream& operator>> ( Istream &  ,
pointEdgePoint &
)
friend
The documentation for this class was generated from the following files:
