Class to be used with PointEdgeWave which enumerates layers of points. More...

Inheritance diagram for pointEdgeLayerInfo:

Public Member Functions
	pointEdgeLayerInfo ()
	Construct null. More...

	pointEdgeLayerInfo (const label pointLayer)
	Construct given the point layer index. More...

label	pointLayer () const
	Return the point layer index. More...

label	edgeLayer () const
	Return the edge layer index. More...

template<class TrackingData >
bool	valid (TrackingData &td) const
	Check whether info has been changed at all or. More...

template<class TrackingData >
bool	sameGeometry (const pointEdgeLayerInfo &, const scalar tol, TrackingData &td) const
	Check for identical geometrical data. Used for cyclics checking. More...

template<class TrackingData >
void	transform (const polyPatch &patch, const label patchPointi, const transformer &transform, TrackingData &td)
	Transform across an interface. More...

template<class TrackingData >
bool	updatePoint (const polyMesh &mesh, const label pointi, const label edgei, const pointEdgeLayerInfo &edgeInfo, const scalar tol, TrackingData &td)
	Influence of edge on point. More...

template<class TrackingData >
bool	updatePoint (const polyMesh &mesh, const label pointi, const pointEdgeLayerInfo &newPointInfo, const scalar tol, TrackingData &td)
	Influence of different value on same point. More...

template<class TrackingData >
bool	updatePoint (const pointEdgeLayerInfo &newPointInfo, const scalar tol, TrackingData &td)
	Influence of different value on same point. More...

template<class TrackingData >
bool	updateEdge (const polyMesh &mesh, const label edgei, const label pointi, const pointEdgeLayerInfo &pointInfo, const scalar tol, TrackingData &td)
	Influence of point on edge. More...

template<class TrackingData >
bool	equal (const pointEdgeLayerInfo &, TrackingData &td) const
	Same (like operator==) More...

bool	operator== (const pointEdgeLayerInfo &) const

bool	operator!= (const pointEdgeLayerInfo &) const

Friends
Ostream &	operator<< (Ostream &, const pointEdgeLayerInfo &)

Istream &	operator>> (Istream &, pointEdgeLayerInfo &)

Detailed Description

Class to be used with PointEdgeWave which enumerates layers of points.

Source files

Definition at line 60 of file pointEdgeLayerInfo.H.

Constructor & Destructor Documentation

◆ pointEdgeLayerInfo() [1/2]

pointEdgeLayerInfo ( )

inline

Construct null.

Definition at line 31 of file pointEdgeLayerInfoI.H.

◆ pointEdgeLayerInfo() [2/2]

pointEdgeLayerInfo ( const label pointLayer )

inline

Construct given the point layer index.

Definition at line 37 of file pointEdgeLayerInfoI.H.

Member Function Documentation

◆ pointLayer()

Foam::label pointLayer ( ) const

inline

Return the point layer index.

Definition at line 45 of file pointEdgeLayerInfoI.H.

References Foam::exit(), and Foam::FatalError.

Here is the call graph for this function:

◆ edgeLayer()

Foam::label edgeLayer ( ) const

inline

Return the edge layer index.

Definition at line 58 of file pointEdgeLayerInfoI.H.

References Foam::exit(), and Foam::FatalError.

Here is the call graph for this function:

◆ valid()

bool valid ( TrackingData & td ) const

inline

Check whether info has been changed at all or.

still contains original (invalid) value

Definition at line 72 of file pointEdgeLayerInfoI.H.

References Foam::labelMax.

Referenced by mappedExtrudedPatchBase::patchLocalPoints(), and pointEdgeLayerInfo::updatePoint().

Here is the caller graph for this function:

◆ sameGeometry()

bool sameGeometry	(	const pointEdgeLayerInfo &	l,
		const scalar	tol,
		TrackingData &	td
	)		const

inline

Check for identical geometrical data. Used for cyclics checking.

Definition at line 79 of file pointEdgeLayerInfoI.H.

◆ transform()

void transform	(	const polyPatch &	patch,
		const label	patchPointi,
		const transformer &	transform,
		TrackingData &	td
	)

inline

Transform across an interface.

Definition at line 91 of file pointEdgeLayerInfoI.H.

◆ updatePoint() [1/3]

bool updatePoint	(	const polyMesh &	mesh,
		const label	pointi,
		const label	edgei,
		const pointEdgeLayerInfo &	edgeInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of edge on point.

Definition at line 102 of file pointEdgeLayerInfoI.H.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::blendedInterfacialModel::valid(), and pointEdgeLayerInfo::valid().

Referenced by PointEdgeLayerInfoData< Type >::updatePoint().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ updatePoint() [2/3]

bool updatePoint	(	const polyMesh &	mesh,
		const label	pointi,
		const pointEdgeLayerInfo &	newPointInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of different value on same point.

Merge new and old info.

Definition at line 132 of file pointEdgeLayerInfoI.H.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::blendedInterfacialModel::valid().

Here is the call graph for this function:

◆ updatePoint() [3/3]

bool updatePoint	(	const pointEdgeLayerInfo &	newPointInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of different value on same point.

No old information.

Definition at line 156 of file pointEdgeLayerInfoI.H.

◆ updateEdge()

bool updateEdge	(	const polyMesh &	mesh,
		const label	edgei,
		const label	pointi,
		const pointEdgeLayerInfo &	pointInfo,
		const scalar	tol,
		TrackingData &	td
	)

inline

Influence of point on edge.

Definition at line 169 of file pointEdgeLayerInfoI.H.

References Foam::labelMax, and Foam::blendedInterfacialModel::valid().

Referenced by PointEdgeLayerInfoData< Type >::updateEdge().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ equal()

bool equal	(	const pointEdgeLayerInfo &	rhs,
		TrackingData &	td
	)		const

inline

Same (like operator==)

Definition at line 191 of file pointEdgeLayerInfoI.H.

References Foam::operator==().

Here is the call graph for this function:

◆ operator==()

bool operator== ( const pointEdgeLayerInfo & rhs ) const

inline

Definition at line 203 of file pointEdgeLayerInfoI.H.

Referenced by PointEdgeLayerInfoData< Type >::operator==().

Here is the caller graph for this function:

◆ operator!=()

bool operator!= ( const pointEdgeLayerInfo & rhs ) const

inline

Definition at line 212 of file pointEdgeLayerInfoI.H.

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const pointEdgeLayerInfo &
	)

friend

◆ operator>>

Istream& operator>>	(	Istream &	,
		pointEdgeLayerInfo &
	)

friend

The documentation for this class was generated from the following files:

src/meshTools/layerInfo/pointEdgeLayerInfo.H
src/meshTools/layerInfo/pointEdgeLayerInfoI.H
