patchInjection Class Reference

Patch injection model. This injects particles continuously at a patch with a given number rate. The number rate is a Function1 and can vary with time. More...

Detailed Description

Patch injection model. This injects particles continuously at a patch with a given number rate. The number rate is a Function1 and can vary with time.

Note that this model only controls the number and position of injected Lagrangian particles. All physical properties are specified by corresponding source conditions. So the velocity/direction/angle/etc..., is controlled by the velocity source condition, the size distribution by the diameter source condition, and the flow rate by the number source condition.

Usage
Property Description Required? Default
patch Name of the patch yes
numberRate The number of particles to inject per unit time yes

Example specification:

    <LagrangianModelName>
    {
        type        patchInjection;
        patch       top;
        numberRate  100000;
    }
See also
Foam::Function1s
Source files
The documentation for this class was generated from the following file:
