Non-conformal-processor-cyclic Lagrangian patch. More...

Inheritance diagram for nonConformalProcessorCyclicLagrangianPatch:

Collaboration diagram for nonConformalProcessorCyclicLagrangianPatch:

Public Member Functions
	TypeName (nonConformalProcessorCyclicPolyPatch::typeName_())
	Runtime type information. More...

	nonConformalProcessorCyclicLagrangianPatch (const polyPatch &, const LagrangianBoundaryMesh &)
	Construct from a patch and a boundary mesh. More...

virtual	~nonConformalProcessorCyclicLagrangianPatch ()
	Destructor. More...

const nonConformalProcessorCyclicPolyPatch &	nonConformalProcessorCyclicPatch () const
	Return the nonConformalProcessorCyclic patch. More...

const nonConformalCyclicLagrangianPatch &	referPatch () const
	Return a reference to the referred patch. More...

virtual void	initEvaluate (PstreamBuffers &, LagrangianMesh &, const LagrangianScalarInternalDynamicField &fraction) const
	Initialise evaluation of changes in elements that have tracked to. More...

virtual void	evaluate (PstreamBuffers &, LagrangianMesh &, const LagrangianScalarInternalDynamicField &fraction) const
	Evaluate changes in elements that have tracked to this patch. More...

Public Member Functions inherited from processorCyclicLagrangianPatch
	TypeName (processorCyclicPolyPatch::typeName_())
	Runtime type information. More...

	processorCyclicLagrangianPatch (const polyPatch &, const LagrangianBoundaryMesh &)
	Construct from a patch and a boundary mesh. More...

virtual	~processorCyclicLagrangianPatch ()
	Destructor. More...

const processorCyclicPolyPatch &	processorCyclicPatch () const
	Return the processorCyclic patch. More...

label	referPatchIndex () const
	Return the referred patch index. More...

const cyclicLagrangianPatch &	referPatch () const
	Return a reference to the referred patch. More...

const transformer &	transform () const
	Return a reference to the referred patch's transform. More...

Public Member Functions inherited from processorLagrangianPatch
	TypeName (processorPolyPatch::typeName_())
	Runtime type information. More...

	processorLagrangianPatch (const polyPatch &, const LagrangianBoundaryMesh &)
	Construct from a patch and a boundary mesh. More...

virtual	~processorLagrangianPatch ()
	Destructor. More...

const processorPolyPatch &	processorPatch () const
	Return the processor patch. More...

virtual const LagrangianSubMesh &	mesh () const
	Return the sub-mesh associated with this patch. More...

virtual void	partition () const
	Update following partitioning of the mesh. More...

Public Member Functions inherited from LagrangianPatch
	TypeName (polyPatch::typeName_())
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianPatch, polyPatch,(const polyPatch &patch, const LagrangianBoundaryMesh &boundaryMesh),(patch, boundaryMesh))
	Declare run-time constructor selection tables. More...

	LagrangianPatch (const polyPatch &, const LagrangianBoundaryMesh &)
	Construct from a patch and a boundary mesh. More...

	LagrangianPatch (const LagrangianPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~LagrangianPatch ()
	Destructor. More...

const polyPatch &	patch () const
	Return the patch. More...

virtual const word &	name () const
	Return name. More...

virtual bool	coupled () const
	Return whether or not this patch is coupled. More...

const LagrangianBoundaryMesh &	boundaryMesh () const
	Return the boundary mesh. More...

const objectRegistry &	db () const
	Return the local object registry. More...

template<class GeometricField , class Type >
const GeometricField::Patch &	lookupPatchField (const word &name)
	Lookup and return the patchField of the named field from the. More...

void	operator= (const LagrangianPatch &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from LagrangianPatch
static autoPtr< LagrangianPatch >	New (const word &type, const polyPatch &patch, const LagrangianBoundaryMesh &boundaryMesh)
	Return a pointer to a new LagrangianPatch of specified type. More...

static autoPtr< LagrangianPatch >	New (const polyPatch &patch, const LagrangianBoundaryMesh &boundaryMesh)
	Return a pointer to a new LagrangianPatch corresponding to the. More...

Protected Attributes inherited from processorLagrangianPatch
autoPtr< LagrangianSubMesh >	receiveMeshPtr_
	The sub-mesh used to append received data. More...

Detailed Description

Non-conformal-processor-cyclic Lagrangian patch.

Source files

Definition at line 51 of file nonConformalProcessorCyclicLagrangianPatch.H.

Constructor & Destructor Documentation

◆ nonConformalProcessorCyclicLagrangianPatch()

nonConformalProcessorCyclicLagrangianPatch	(	const polyPatch &	patch,
		const LagrangianBoundaryMesh &	boundaryMesh
	)

Construct from a patch and a boundary mesh.

Definition at line 50 of file nonConformalProcessorCyclicLagrangianPatch.C.

◆ ~nonConformalProcessorCyclicLagrangianPatch()

~nonConformalProcessorCyclicLagrangianPatch ( )

virtual

Destructor.

Definition at line 67 of file nonConformalProcessorCyclicLagrangianPatch.C.

Member Function Documentation

◆ TypeName()

TypeName ( nonConformalProcessorCyclicPolyPatch::typeName_() )

Runtime type information.

◆ nonConformalProcessorCyclicPatch()

const nonConformalProcessorCyclicPolyPatch& nonConformalProcessorCyclicPatch ( ) const

inline

Return the nonConformalProcessorCyclic patch.

Definition at line 88 of file nonConformalProcessorCyclicLagrangianPatch.H.

◆ referPatch()

const nonConformalCyclicLagrangianPatch& referPatch ( ) const

inline

Return a reference to the referred patch.

Definition at line 94 of file nonConformalProcessorCyclicLagrangianPatch.H.

References LagrangianPatch::boundaryMesh(), and processorCyclicLagrangianPatch::referPatchIndex().

Here is the call graph for this function:

◆ initEvaluate()

void initEvaluate	(	PstreamBuffers &	pBufs,
		LagrangianMesh &	mesh,
		const LagrangianScalarInternalDynamicField &	fraction
	)		const

virtual

Initialise evaluation of changes in elements that have tracked to.

this patch

Reimplemented from processorLagrangianPatch.

Definition at line 74 of file nonConformalProcessorCyclicLagrangianPatch.C.

References mesh, VectorSpace< Form, Cmpt, Ncmpts >::nan, DimensionedField< Type, GeoMesh, PrimitiveField >::primitiveField(), LagrangianSubMesh::sub(), and Foam::toBeRemoved.

Here is the call graph for this function:

◆ evaluate()

void evaluate	(	PstreamBuffers &	pBufs,
		LagrangianMesh &	mesh,
		const LagrangianScalarInternalDynamicField &	fraction
	)		const

virtual

Evaluate changes in elements that have tracked to this patch.

Reimplemented from processorLagrangianPatch.

Definition at line 107 of file nonConformalProcessorCyclicLagrangianPatch.C.

References polyPatch::faceAreas(), polyMesh::faceOwner(), forAll, Foam::inCell, Foam::tracking::locate(), Foam::magSqr(), fvMesh::mesh(), mesh, meshSearch::New(), Foam::tracking::position(), List< T >::size(), Foam::sqr(), and polyPatch::start().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/Lagrangian/Lagrangian/LagrangianMesh/LagrangianPatches/constraint/nonConformalProcessorCyclic/nonConformalProcessorCyclicLagrangianPatch.H
src/Lagrangian/Lagrangian/LagrangianMesh/LagrangianPatches/constraint/nonConformalProcessorCyclic/nonConformalProcessorCyclicLagrangianPatch.C
