STARCD Class Reference

Writes polyMesh in pro-STAR (v4) bnd/cel/vrt format. More...

Inheritance diagram for STARCD:

Collaboration diagram for STARCD:

Public Member Functions
	STARCD (const polyMesh &, const scalar scaleFactor=1.0)
	Open a file for writing. More...
	STARCD (const STARCD &)=delete
	Disallow default bitwise copy construction. More...
virtual	~STARCD ()
	Destructor. More...
void	rmFiles (const fileName &baseName) const
	Remove STAR-CD files for the baseName. More...
virtual bool	write (const fileName &meshName=fileName::null) const
	Write volume mesh. More...
void	operator= (const STARCD &)=delete
	Disallow default bitwise assignment. More...
Public Member Functions inherited from meshWriter
	meshWriter (const polyMesh &, const scalar scaleFactor=1.0)
	Create a writer object. More...
	meshWriter (const meshWriter &)=delete
	Disallow default bitwise copy construction. More...
virtual	~meshWriter ()
	Destructor. More...
void	scaleFactor (const scalar scaling)
	Set points scaling. More...
void	noBoundary ()
	Suppress writing bnd file. More...
void	operator= (const meshWriter &)=delete
	Disallow default bitwise assignment. More...

Static Public Attributes
static const label	foamToStarFaceAddr [4][6]
	Face addressing from OpenFOAM faces -> pro-STAR faces. More...
Static Public Attributes inherited from meshWriter
static string	defaultMeshName = "meshExport"
	Specify a default mesh name. More...

Additional Inherited Members
Protected Attributes inherited from meshWriter
const polyMesh &	mesh_
	Mesh reference. More...
scalar	scaleFactor_
	Scaling factor for points (eg, [m] -> [mm]) More...
bool	writeBoundary_
	Write bnd file. More...
boundaryRegion	boundaryRegion_
	boundaryRegion persistent data saved as a dictionary More...
cellTable	cellTable_
	cellTable persistent data saved as a dictionary More...
labelList	cellTableId_
	cellTable IDs for each cell More...
Static Protected Attributes inherited from meshWriter
static const cellModel *	unknownModel
	Pointers to cell shape models. More...
static const cellModel *	tetModel
static const cellModel *	pyrModel
static const cellModel *	prismModel
static const cellModel *	hexModel

Detailed Description

Writes polyMesh in pro-STAR (v4) bnd/cel/vrt format.

The cellTableId and cellTable information are used (if available). Otherwise the cellZones are used (if available).

Source files

• STARCDMeshWriter.H
• STARCDMeshWriter.C

Definition at line 55 of file STARCDMeshWriter.H.

Constructor & Destructor Documentation

STARCD() [1/2]

STARCD	(	const polyMesh &	mesh,
		const scalar	scaleFactor = 1.0
	)

Open a file for writing.

Definition at line 466 of file STARCDMeshWriter.C.

References meshWriter::boundaryRegion_, meshWriter::cellTable_, meshWriter::mesh_, boundaryRegion::readDict(), and cellTable::readDict().

Here is the call graph for this function:

STARCD() [2/2]

STARCD ( const STARCD &  )

delete

Disallow default bitwise copy construction.

~STARCD()

~STARCD ( )

virtual

Destructor.

Definition at line 482 of file STARCDMeshWriter.C.

Member Function Documentation

rmFiles()

void rmFiles

(

const fileName &

baseName

)

const

Remove STAR-CD files for the baseName.

Definition at line 488 of file STARCDMeshWriter.C.

References Foam::rm().

Here is the call graph for this function:

write()

bool write ( const fileName &  meshName = fileName::null ) const

virtual

Write volume mesh.

Implements meshWriter.

Definition at line 497 of file STARCDMeshWriter.C.

References meshWriter::defaultMeshName, meshName, and fileName::name().

Here is the call graph for this function:

operator=()

void operator= ( const STARCD &  )

delete

Disallow default bitwise assignment.

Member Data Documentation

foamToStarFaceAddr

const Foam::label foamToStarFaceAddr

static

Initial value:

=
{
    { 4, 5, 2, 3, 0, 1 },
    { 0, 1, 4, 5, 2, -1 },
    { 5, 4, 2, 0, -1, -1 },
    { 0, 4, 3, 5, 2, -1 }
}

Face addressing from OpenFOAM faces -> pro-STAR faces.

Definition at line 88 of file STARCDMeshWriter.H.

---

The documentation for this class was generated from the following files:

• src/conversion/meshWriter/starcd/STARCDMeshWriter.H
• src/conversion/meshWriter/starcd/STARCDMeshWriter.C
