Public Member Functions | Static Public Member Functions | Protected Attributes | List of all members
lduMatrix::preconditioner Class Referenceabstract

Abstract base-class for lduMatrix preconditioners. More...

Inheritance diagram for lduMatrix::preconditioner:
Inheritance graph
[legend]
Collaboration diagram for lduMatrix::preconditioner:
Collaboration graph
[legend]

Public Member Functions

virtual const word & type () const =0
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, preconditioner, symMatrix,(const solver &sol, const dictionary &solverControls),(sol, solverControls))

 declareRunTimeSelectionTable (autoPtr, preconditioner, asymMatrix,(const solver &sol, const dictionary &solverControls),(sol, solverControls))

 preconditioner (const solver &sol)

virtual ~preconditioner ()
 Destructor. More...

virtual void read (const dictionary &)
 Read and reset the preconditioner parameters. More...

virtual void precondition (scalarField &wA, const scalarField &rA, const direction cmpt=0) const =0
 Return wA the preconditioned form of residual rA. More...

virtual void preconditionT (scalarField &wT, const scalarField &rT, const direction cmpt=0) const
 Return wT the transpose-matrix preconditioned form of. More...


Static Public Member Functions

static word getName (const dictionary &)
 Find the preconditioner name (directly or from a sub-dictionary) More...

static autoPtr< preconditioner > New (const solver &sol, const dictionary &solverControls)
 Return a new preconditioner. More...


Protected Attributes

const solver & solver_
 Reference to the base-solver this preconditioner is used with. More...


Detailed Description

Abstract base-class for lduMatrix preconditioners.

Definition at line 410 of file lduMatrix.H.

Constructor & Destructor Documentation

◆ preconditioner()

preconditioner ( const solver &  sol)
inline

Definition at line 458 of file lduMatrix.H.

◆ ~preconditioner()

virtual ~preconditioner ( )
inlinevirtual

Destructor.

Definition at line 478 of file lduMatrix.H.

Member Function Documentation

◆ getName()

Foam::word getName ( const dictionary &  solverControls)
static

Find the preconditioner name (directly or from a sub-dictionary)

Definition at line 39 of file lduMatrixPreconditioner.C.

References Foam::e, dictionary::lookupEntry(), and Foam::name().

Referenced by PBiCG::solve(), PBiCGStab::solve(), and PCG::solve().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ type()

virtual const word& type ( ) const
pure virtual

Runtime type information.

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable ( autoPtr  ,
preconditioner  ,
symMatrix  ,
(const solver &sol, const dictionary &solverControls)  ,
(sol, solverControls)
)

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable ( autoPtr  ,
preconditioner  ,
asymMatrix  ,
(const solver &sol, const dictionary &solverControls)  ,
(sol, solverControls)
)

◆ New()

Foam::autoPtr< Foam::lduMatrix::preconditioner > New ( const solver &  sol,
const dictionary &  solverControls
)
static

Return a new preconditioner.

Definition at line 62 of file lduMatrixPreconditioner.C.

References lduMatrix::asymmetric(), Foam::e, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, dictionary::lookupEntry(), lduMatrix::solver::matrix(), Foam::name(), Foam::nl, dictionary::null, and lduMatrix::symmetric().

Referenced by PBiCG::solve(), PBiCGStab::solve(), and PCG::solve().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ read()

virtual void read ( const dictionary &  )
inlinevirtual

Read and reset the preconditioner parameters.

from the given stream

Definition at line 486 of file lduMatrix.H.

◆ precondition()

virtual void precondition ( scalarField &  wA,
const scalarField &  rA,
const direction  cmpt = 0
) const
pure virtual

Return wA the preconditioned form of residual rA.

Implemented in noPreconditioner, GAMGPreconditioner, FDICPreconditioner, DILUPreconditioner, DICPreconditioner, and diagonalPreconditioner.

References NotImplemented.

◆ preconditionT()

virtual void preconditionT ( scalarField &  wT,
const scalarField &  rT,
const direction  cmpt = 0
) const
inlinevirtual

Return wT the transpose-matrix preconditioned form of.

residual rT. This is only required for preconditioning asymmetric matrices.

Reimplemented in noPreconditioner, DILUPreconditioner, and diagonalPreconditioner.

Definition at line 500 of file lduMatrix.H.

Member Data Documentation

◆ solver_

const solver& solver_
protected

Reference to the base-solver this preconditioner is used with.

Definition at line 417 of file lduMatrix.H.

Referenced by diagonalPreconditioner::diagonalPreconditioner(), and FDICPreconditioner::FDICPreconditioner().

The documentation for this class was generated from the following files:
