diagonalPreconditioner Class Reference

Diagonal preconditioner for both symmetric and asymmetric matrices. More...

Inheritance diagram for diagonalPreconditioner:

Collaboration diagram for diagonalPreconditioner:

Public Member Functions
	TypeName ("diagonal")
	Runtime type information. More...
	diagonalPreconditioner (const lduMatrix::solver &, const dictionary &solverControlsUnused)
	Construct from matrix components and preconditioner solver controls. More...
	diagonalPreconditioner (const diagonalPreconditioner &)=delete
	Disallow default bitwise copy construction. More...
virtual	~diagonalPreconditioner ()
	Destructor. More...
virtual void	precondition (scalarField &wA, const scalarField &rA, const direction cmpt=0) const
	Return wA the preconditioned form of residual rA. More...
virtual void	preconditionT (scalarField &wT, const scalarField &rT, const direction cmpt=0) const
	Return wT the transpose-matrix preconditioned form of residual rT. More...
void	operator= (const diagonalPreconditioner &)=delete
	Disallow default bitwise assignment. More...
Public Member Functions inherited from lduMatrix::preconditioner
virtual const word &	type () const =0
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, preconditioner, symMatrix,(const solver &sol, const dictionary &solverControls),(sol, solverControls))
	declareRunTimeSelectionTable (autoPtr, preconditioner, asymMatrix,(const solver &sol, const dictionary &solverControls),(sol, solverControls))
	preconditioner (const solver &sol)
virtual	~preconditioner ()
	Destructor. More...
virtual void	read (const dictionary &)
	Read and reset the preconditioner parameters. More...

Additional Inherited Members
Static Public Member Functions inherited from lduMatrix::preconditioner
static word	getName (const dictionary &)
	Find the preconditioner name (directly or from a sub-dictionary) More...
static autoPtr< preconditioner >	New (const solver &sol, const dictionary &solverControls)
	Return a new preconditioner. More...
Protected Attributes inherited from lduMatrix::preconditioner
const solver &	solver_
	Reference to the base-solver this preconditioner is used with. More...

Detailed Description

Diagonal preconditioner for both symmetric and asymmetric matrices.

The reciprocal of the diagonal is calculated and stored for reuse because on most systems '*' is faster than '/'.

Source files

• diagonalPreconditioner.H
• diagonalPreconditioner.C

Definition at line 51 of file diagonalPreconditioner.H.

Constructor & Destructor Documentation

diagonalPreconditioner() [1/2]

diagonalPreconditioner	(	const lduMatrix::solver &	sol,
		const dictionary &	solverControlsUnused
	)

Construct from matrix components and preconditioner solver controls.

Definition at line 46 of file diagonalPreconditioner.C.

References UList< T >::begin(), lduMatrix::diag(), lduMatrix::solver::matrix(), List< T >::size(), and lduMatrix::preconditioner::solver_.

Here is the call graph for this function:

diagonalPreconditioner() [2/2]

diagonalPreconditioner ( const diagonalPreconditioner &  )

delete

Disallow default bitwise copy construction.

~diagonalPreconditioner()

virtual ~diagonalPreconditioner ( )

inlinevirtual

Destructor.

Definition at line 81 of file diagonalPreconditioner.H.

Member Function Documentation

TypeName()

TypeName

(

"diagonal"

)

Runtime type information.

precondition()

void precondition ( scalarField &  wA, const scalarField &  rA, const direction  cmpt = 0  ) const

virtual

Return wA the preconditioned form of residual rA.

Implements lduMatrix::preconditioner.

Definition at line 70 of file diagonalPreconditioner.C.

References UList< T >::begin(), and List< T >::size().

Referenced by diagonalPreconditioner::preconditionT().

Here is the call graph for this function:

Here is the caller graph for this function:

preconditionT()

virtual void preconditionT ( scalarField &  wT, const scalarField &  rT, const direction  cmpt = 0  ) const

inlinevirtual

Return wT the transpose-matrix preconditioned form of residual rT.

Reimplemented from lduMatrix::preconditioner.

Definition at line 96 of file diagonalPreconditioner.H.

References diagonalPreconditioner::precondition().

Here is the call graph for this function:

operator=()

void operator= ( const diagonalPreconditioner &  )

delete

Disallow default bitwise assignment.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/preconditioners/diagonalPreconditioner/diagonalPreconditioner.H
• src/OpenFOAM/matrices/lduMatrix/preconditioners/diagonalPreconditioner/diagonalPreconditioner.C
