Public Types | Public Member Functions | List of all members
lambdaThixotropic< BasicMomentumTransportModel > Class Template Reference

Thixotropic viscosity momentum transport model based on the evolution of the structural parameter $ \lambda $: More...

Inheritance diagram for lambdaThixotropic< BasicMomentumTransportModel >:
Inheritance graph
[legend]
Collaboration diagram for lambdaThixotropic< BasicMomentumTransportModel >:
Collaboration graph
[legend]

Public Types

typedef BasicMomentumTransportModel::alphaField alphaField

typedef BasicMomentumTransportModel::rhoField rhoField

- Public Types inherited from linearViscousStress< laminarModel< BasicMomentumTransportModel > >
typedef BasicMomentumTransportModel::alphaField alphaField

typedef BasicMomentumTransportModel::rhoField rhoField

- Public Types inherited from laminarModel< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField alphaField

typedef BasicMomentumTransportModel::rhoField rhoField


Public Member Functions

 TypeName ("lambdaThixotropic")
 Runtime type information. More...

 lambdaThixotropic (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
 Construct from components. More...

virtual ~lambdaThixotropic ()
 Destructor. More...

virtual bool read ()
 Read momentumTransport dictionary. More...

virtual tmp< volScalarField > nuEff () const
 Return the effective viscosity. More...

virtual tmp< scalarField > nuEff (const label patchi) const
 Return the effective viscosity on patch. More...

virtual void predict ()
 The lambdaThixotropic viscosity is not predicted. More...

virtual void correct ()
 Correct the lambdaThixotropic viscosity. More...

- Public Member Functions inherited from linearViscousStress< laminarModel< BasicMomentumTransportModel > >
Foam::tmp< Foam::fvVectorMatrix > DivDevTau (const RhoFieldType &rho, volVectorField &U) const

 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
 Construct from components. More...

virtual ~linearViscousStress ()
 Destructor. More...

virtual tmp< surfaceVectorField > devTau () const
 Return the effective surface stress. More...

virtual tmp< fvVectorMatrix > divDevTau (volVectorField &U) const
 Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix > divDevTau (const volScalarField &rho, volVectorField &U) const
 Return the source term for the momentum equation. More...

- Public Member Functions inherited from laminarModel< BasicMomentumTransportModel >
 TypeName ("laminar")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, laminarModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity),(alpha, rho, U, alphaRhoPhi, phi, viscosity))

 laminarModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
 Construct from components. More...

 laminarModel (const laminarModel &)=delete
 Disallow default bitwise copy construction. More...

virtual ~laminarModel ()
 Destructor. More...

virtual tmp< volScalarField > nut () const
 Return the turbulence viscosity, i.e. 0 for laminar flow. More...

virtual tmp< scalarField > nut (const label patchi) const
 Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorField > R () const
 Return the Reynolds stress tensor [m^2/s^2], i.e. 0 for laminar flow. More...

virtual tmp< volScalarField > k () const
 Return the turbulence kinetic energy, i.e. 0 for laminar flow. More...

virtual tmp< volScalarField > epsilon () const
 Return the turbulence kinetic energy dissipation rate,. More...

virtual tmp< volScalarField > omega () const
 Return the turbulence specific dissipation rate,. More...

void operator= (const laminarModel &)=delete
 Disallow default bitwise assignment. More...


Additional Inherited Members

- Static Public Member Functions inherited from laminarModel< BasicMomentumTransportModel >
static autoPtr< laminarModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
 Return a reference to the selected laminar model. More...

- Protected Member Functions inherited from linearViscousStress< laminarModel< BasicMomentumTransportModel > >
tmp< fvVectorMatrix > DivDevTau (const RhoFieldType &rho, volVectorField &U) const
 Return the source term for the momentum equation. More...

- Protected Member Functions inherited from laminarModel< BasicMomentumTransportModel >
const dictionary & laminarDict () const
 Const access to the laminar dictionary. More...

const dictionary & coeffDict () const
 Const access to the coefficients dictionary. More...


Detailed Description

template<class BasicMomentumTransportModel>
class Foam::laminarModels::lambdaThixotropic< BasicMomentumTransportModel >

Thixotropic viscosity momentum transport model based on the evolution of the structural parameter $ \lambda $:

\[ \frac{D\lambda}{Dt} = a(1 - \lambda)^b - c \lambda \dot{\gamma}^d \]

The viscosity is then calculated using the expression

\[ \nu = \frac{\nu_{\infty}}{{1 - K \lambda}^2} \]

Where the parameter K is given by:

\[ K = 1 - \sqrt{\frac{\nu_{\infty}}{\nu_{0}}} \]

Here:

$ \lambda $ = structural parameter
$ a $ = model coefficient
$ b $ = model coefficient
$ c $ = model coefficient
$ d $ = model coefficient
$ \dot{\gamma} $ = stress rate [1/s]
$ \nu_{0} $ = limiting viscosity when $ \lambda = 1 $
$ \nu_{\infty} $ = limiting viscosity when $ \lambda = 0 $

Reference:

        Barnes H A, 1997.  Thixotropy - a review.  J. Non-Newtonian Fluid
        Mech 70, pp 1-33
Source files

Definition at line 119 of file lambdaThixotropic.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 182 of file lambdaThixotropic.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 183 of file lambdaThixotropic.H.

Constructor & Destructor Documentation

◆ lambdaThixotropic()

lambdaThixotropic ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const viscosity &  viscosity
)

Construct from components.

Definition at line 43 of file lambdaThixotropic.C.

◆ ~lambdaThixotropic()

virtual ~lambdaThixotropic ( )
inlinevirtual

Destructor.

Definition at line 205 of file lambdaThixotropic.H.

Member Function Documentation

◆ TypeName()

TypeName ( "lambdaThixotropic< BasicMomentumTransportModel >"  )

Runtime type information.

◆ read()

bool read
virtual

Read momentumTransport dictionary.

Implements linearViscousStress< laminarModel< BasicMomentumTransportModel > >.

Definition at line 157 of file lambdaThixotropic.C.

References Foam::dimTime, Foam::pow(), and Foam::sqrt().

Here is the call graph for this function:

◆ nuEff() [1/2]

tmp< volScalarField > nuEff
virtual

Return the effective viscosity.

i.e. the lambdaThixotropic viscosity

Implements laminarModel< BasicMomentumTransportModel >.

Definition at line 188 of file lambdaThixotropic.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

◆ nuEff() [2/2]

tmp< scalarField > nuEff ( const label  patchi) const
virtual

Return the effective viscosity on patch.

Implements laminarModel< BasicMomentumTransportModel >.

Definition at line 200 of file lambdaThixotropic.C.

References patchi.

◆ predict()

virtual void predict ( )
inlinevirtual

The lambdaThixotropic viscosity is not predicted.

Reimplemented from laminarModel< BasicMomentumTransportModel >.

Definition at line 222 of file lambdaThixotropic.H.

◆ correct()

void correct
virtual

Correct the lambdaThixotropic viscosity.

Implements linearViscousStress< laminarModel< BasicMomentumTransportModel > >.

Definition at line 210 of file lambdaThixotropic.C.

References alpha(), fvConstraints::constrain(), laminarModel< BasicMomentumTransportModel >::correct(), Foam::fvm::ddt(), Foam::dimless, Foam::fvm::div(), fvConstraints(), fvModels(), Foam::max(), dictionary::New(), Foam::pow(), tmp< T >::ref(), rho, Foam::solve(), fvModels::source(), and Foam::fvm::Sp().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
