Laminar flame speed obtained from Ravi and Petersen's correlation. More...

Inheritance diagram for RaviPetersen:

Collaboration diagram for RaviPetersen:

Public Member Functions
	TypeName ("RaviPetersen")
	Runtime type information. More...

	RaviPetersen (const dictionary &dict, const dictionary &coeffDict, const psiuMulticomponentThermo &)
	Construct from dictionary and psiuMulticomponentThermo. More...

	RaviPetersen (const RaviPetersen &)=delete
	Disallow default bitwise copy construction. More...

virtual	~RaviPetersen ()
	Destructor. More...

tmp< volScalarField >	operator() () const
	Return the laminar flame speed [m/s]. More...

void	operator= (const RaviPetersen &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from laminarFlameSpeed
	TypeName ("laminarFlameSpeed")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, laminarFlameSpeed, dictionary,(const dictionary &dict, const dictionary &coeffDict, const psiuMulticomponentThermo &ct),(dict, coeffDict, ct))

	laminarFlameSpeed (const dictionary &, const psiuMulticomponentThermo &)
	Construct from dictionary and psiuMulticomponentThermo. More...

	laminarFlameSpeed (const laminarFlameSpeed &)=delete
	Disallow default bitwise copy construction. More...

virtual	~laminarFlameSpeed ()
	Destructor. More...

void	operator= (const laminarFlameSpeed &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from laminarFlameSpeed
static autoPtr< laminarFlameSpeed >	New (const dictionary &, const psiuMulticomponentThermo &)

Protected Attributes inherited from laminarFlameSpeed
const psiuMulticomponentThermo &	psiuMulticomponentThermo_

scalar	equivalenceRatio_
	Equivalence ratio of a homogeneous mixture. More...

Detailed Description

Laminar flame speed obtained from Ravi and Petersen's correlation.

The correlation for the laminar flame speed is of the following form:

$Su = \left( \sum \alpha_i \phi^i \right) \left( \frac{T}{T_{ref}} \right)^{\left( \sum \beta_j \phi^j \right)}$

Where $\phi$ is the equivalence ratio, and $\alpha$ and $\beta$ are polynomial coefficients given for a number of pressure and equivalence ratio points.

Source files

Definition at line 61 of file RaviPetersen.H.

Constructor & Destructor Documentation

◆ RaviPetersen() [1/2]

RaviPetersen	(	const dictionary &	dict,
		const dictionary &	coeffDict,
		const psiuMulticomponentThermo &	ct
	)

Construct from dictionary and psiuMulticomponentThermo.

Definition at line 49 of file RaviPetersen.C.

◆ RaviPetersen() [2/2]

RaviPetersen ( const RaviPetersen & )

delete

Disallow default bitwise copy construction.

◆ ~RaviPetersen()

~RaviPetersen ( )

virtual

Destructor.

Definition at line 72 of file RaviPetersen.C.

Member Function Documentation

◆ TypeName()

TypeName ( "RaviPetersen" )

Runtime type information.

◆ operator()()

Foam::tmp< Foam::volScalarField > operator() ( ) const

virtual

Return the laminar flame speed [m/s].

Implements laminarFlameSpeed.

Definition at line 295 of file RaviPetersen.C.

References Foam::dimless, Foam::dimVelocity, Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), IOobject::NO_READ, IOobject::NO_WRITE, p, tmp< T >::ref(), and Foam::type().

Here is the call graph for this function:

◆ operator=()

void operator= ( const RaviPetersen & )
