Abstract class for laminar flame speed. More...

Inheritance diagram for laminarFlameSpeed:

[legend]

Collaboration diagram for laminarFlameSpeed:

Public Member Functions
	TypeName ("laminarFlameSpeed")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, laminarFlameSpeed, dictionary,(const dictionary &dict, const dictionary &coeffDict, const psiuMulticomponentThermo &ct),(dict, coeffDict, ct))

	laminarFlameSpeed (const dictionary &, const psiuMulticomponentThermo &)
	Construct from dictionary and psiuMulticomponentThermo. More...

	laminarFlameSpeed (const laminarFlameSpeed &)=delete
	Disallow default bitwise copy construction. More...

virtual	~laminarFlameSpeed ()
	Destructor. More...

virtual tmp< volScalarField >	operator() () const =0
	Return the laminar flame speed [m/s]. More...

void	operator= (const laminarFlameSpeed &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< laminarFlameSpeed >	New (const dictionary &, const psiuMulticomponentThermo &)

Protected Attributes
const psiuMulticomponentThermo &	psiuMulticomponentThermo_

scalar	equivalenceRatio_
	Equivalence ratio of a homogeneous mixture. More...

Detailed Description

Abstract class for laminar flame speed.

Source files

Definition at line 57 of file laminarFlameSpeed.H.

Constructor & Destructor Documentation

◆ laminarFlameSpeed() [1/2]

laminarFlameSpeed	(	const dictionary &	dict,
		const psiuMulticomponentThermo &	ct
	)

Construct from dictionary and psiuMulticomponentThermo.

Definition at line 40 of file laminarFlameSpeed.C.

References psiuMulticomponentThermo::containsSpecie(), dict, Foam::dimless, laminarFlameSpeed::equivalenceRatio_, laminarFlameSpeed::psiuMulticomponentThermo_, and dimensioned< Type >::value().

Here is the call graph for this function:

◆ laminarFlameSpeed() [2/2]

laminarFlameSpeed ( const laminarFlameSpeed & )

delete

Disallow default bitwise copy construction.

◆ ~laminarFlameSpeed()

~laminarFlameSpeed ( )

virtual

Destructor.

Definition at line 59 of file laminarFlameSpeed.C.

Member Function Documentation

◆ TypeName()

TypeName ( "laminarFlameSpeed" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		laminarFlameSpeed	,
		dictionary	,
		(const dictionary &dict, const dictionary &coeffDict, const psiuMulticomponentThermo &ct)	,
		(dict, coeffDict, ct)
	)

◆ New()

Foam::autoPtr< Foam::laminarFlameSpeed > New	(	const dictionary &	dict,
		const psiuMulticomponentThermo &	ct
	)

static

Definition at line 30 of file laminarFlameSpeedNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ operator()()

virtual tmp<volScalarField> operator() ( ) const

pure virtual

Return the laminar flame speed [m/s].

Implemented in RaviPetersen, Gulder, constant, and SCOPE.

◆ operator=()

void operator= ( const laminarFlameSpeed & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ psiuMulticomponentThermo_

const psiuMulticomponentThermo& psiuMulticomponentThermo_

protected

Definition at line 63 of file laminarFlameSpeed.H.

Referenced by laminarFlameSpeed::laminarFlameSpeed().

◆ equivalenceRatio_

scalar equivalenceRatio_
