Given cell centre values and point (vertex) values decompose into tetrahedra and linear interpolate within them. More...
Public Member Functions | |
| TypeName ("cellPoint") | |
| Runtime type information. More... | |
| interpolationCellPoint (const VolField< Type > &psi) | |
| Construct from components. More... | |
| interpolationCellPoint (const interpolationCellPoint< Type > &i) | |
| Copy construct. More... | |
| interpolationCellPoint (const VolField< Type > &psi, tmp< PointField< Type >> psip) | |
| Construct from components. More... | |
| virtual autoPtr< interpolation< Type > > | clone () const |
| Clone. More... | |
| Type | interpolate (const cellPointWeight &cpw) const |
| Interpolate field for the given cellPointWeight. More... | |
| Type | interpolate (const vector &position, const label celli, const label facei=-1) const |
| Interpolate field to the given point in the given cell. More... | |
| Type | interpolate (const barycentric &coordinates, const tetIndices &tetIs, const label facei=-1) const |
| Interpolate field to the given coordinates in the tetrahedron. More... | |
 Public Member Functions inherited from fieldInterpolation< Type, interpolationCellPoint< Type > > | |
| virtual tmp< Field< Type > > | interpolate (const vectorField &position, const labelList &celli, const labelList &facei=NullObjectRef< labelList >()) const |
| Interpolate field to the given points in the given cells. More... | |
| virtual tmp< Field< Type > > | interpolate (const Field< barycentric > &coordinates, const labelList &celli, const labelList &tetFacei, const labelList &tetPti, const labelList &facei=NullObjectRef< labelList >()) const |
| Interpolate field to the given coordinates in the given tetrahedra. More... | |
| Public Member Functions inherited from interpolation< Type > | |
| TypeName ("interpolation") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, interpolation, dictionary,(const VolField< Type > &psi),(psi)) | |
| interpolation (const VolField< Type > &psi) | |
| Construct from components. More... | |
| interpolation (const interpolation< Type > &i) | |
| Copy constructor. More... | |
| virtual | ~interpolation () |
| Destructor. More... | |
| const VolField< Type > & | psi () const |
| Return the field to be interpolated. More... | |
| Public Member Functions inherited from interpolationVolPointInterpolation< Type > | |
| TypeName ("interpolationVolPointInterpolation") | |
| Runtime type information. More... | |
| interpolationVolPointInterpolation (const VolField< Type > &psi) | |
| Construct from components. More... | |
| interpolationVolPointInterpolation (const interpolationVolPointInterpolation< Type > &i) | |
| Copy construct. More... | |
| interpolationVolPointInterpolation (const VolField< Type > &psi, tmp< PointField< Type >> psip) | |
| Construct from components. More... | |
| virtual | ~interpolationVolPointInterpolation () |
| const PointField< Type > & | psip () const |
| Access the point field. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from interpolation< Type > | |
| static autoPtr< interpolation< Type > > | New (const word &interpolationType, const VolField< Type > &psi) |
| Return a reference to the specified interpolation scheme. More... | |
| static autoPtr< interpolation< Type > > | New (const dictionary &interpolationSchemes, const VolField< Type > &psi) |
| Return a reference to the selected interpolation scheme. More... | |
| Protected Attributes inherited from interpolation< Type > | |
| const VolField< Type > & | psi_ |
| The vol field to interpolate. More... | |
| const polyMesh & | mesh_ |
| Reference to the mesh. More... | |
| Protected Attributes inherited from interpolationVolPointInterpolation< Type > | |
| const PointField< Type > | psip_ |
| Interpolated volfield. More... | |
Given cell centre values and point (vertex) values decompose into tetrahedra and linear interpolate within them.
Definition at line 48 of file interpolationCellPoint.H.
| interpolationCellPoint | ( | const VolField< Type > & | psi | ) |
Construct from components.
Definition at line 32 of file interpolationCellPoint.C.
References interpolation< Type >::psi().
| interpolationCellPoint | ( | const interpolationCellPoint< Type > & | i | ) |
Copy construct.
Definition at line 46 of file interpolationCellPoint.C.
References interpolation< Type >::psi().
| interpolationCellPoint | ( | const VolField< Type > & | psi, |
| tmp< PointField< Type >> | psip | ||
| ) |
Construct from components.
Definition at line 60 of file interpolationCellPoint.C.
| TypeName | ( | "cellPoint" | ) |
Runtime type information.
|
inlinevirtual |
Clone.
Implements interpolation< Type >.
Reimplemented in interpolationCellPointWallModified< Type >.
Definition at line 81 of file interpolationCellPoint.H.
|
inline |
Interpolate field for the given cellPointWeight.
Definition at line 29 of file interpolationCellPointI.H.
References cellPointWeight::cell(), cellPointWeight::faceVertices(), and cellPointWeight::weights().
Referenced by solidParticle::move(), and nearWallFields::sampleBoundaryField().
|
inlinevirtual |
Interpolate field to the given point in the given cell.
Implements interpolation< Type >.
Definition at line 47 of file interpolationCellPointI.H.
References Foam::fvc::interpolate(), and Foam::tracking::position().
|
inlinevirtual |
Interpolate field to the given coordinates in the tetrahedron.
defined by the given indices.
Reimplemented from interpolation< Type >.
Definition at line 59 of file interpolationCellPointI.H.
References tetIndices::cell(), Foam::tracking::coordinates(), Foam::exit(), tetIndices::face(), tetIndices::faceTriIs(), Foam::FatalError, and FatalErrorInFunction.
