This source condition retains the internal value. More...

Inheritance diagram for internalLagrangianFieldSource< Type >:

Collaboration diagram for internalLagrangianFieldSource< Type >:

Public Member Functions
	TypeName ("internal")
	Runtime type information. More...

virtual autoPtr< LagrangianFieldSource< Type > >	clone (const regIOobject &iIo) const
	Construct and return a clone setting the internal field reference. More...

virtual	~internalLagrangianFieldSource ()
	Destructor. More...

virtual tmp< LagrangianSubField< Type > >	sourceValue (const LagrangianSource &, const LagrangianSubMesh &) const
	Return the source value. More...

virtual tmp< LagrangianSubScalarField >	internalCoeff (const LagrangianSource &, const LagrangianSubMesh &) const
	Return the internal coefficient. More...

Public Member Functions inherited from LagrangianFieldSource< Type >
	TypeName ("LagrangianFieldSource")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianFieldSource, null,(const regIOobject &iIo),(iIo))
	Select given internal field. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianFieldSource, dictionary,(const regIOobject &iIo, const dictionary &dict),(iIo, dict))
	Select given internal field and dictionary. More...

	LagrangianFieldSource (const regIOobject &)
	Construct from internal field. More...

	LagrangianFieldSource (const regIOobject &, const dictionary &)
	Construct from internal field and dictionary. More...

	LagrangianFieldSource (const LagrangianFieldSource< Type > &)=delete
	Disallow copy without setting the internal field reference. More...

autoPtr< LagrangianFieldSource< Type > >	clone () const
	Disallow clone without setting the internal field reference. More...

	LagrangianFieldSource (const LagrangianFieldSource< Type > &, const regIOobject &)
	Construct as copy setting the internal field reference. More...

virtual	~LagrangianFieldSource ()
	Destructor. More...

const objectRegistry &	db () const
	Return local objectRegistry. More...

const dimensionSet &	internalDimensions () const
	Return internal dimensions reference. More...

const LagrangianInternalDynamicField< Type > &	internalField () const
	Return internal field reference. More...

tmp< LagrangianSubField< Type > >	sourceCoeff (const LagrangianSource &, const LagrangianSubMesh &) const
	Return the source coefficient. More...

tmp< LagrangianSubField< Type > >	value (const LagrangianSource &, const LagrangianSubMesh &) const
	Return the value for a continuous source. More...

virtual tmp< LagrangianSubField< Type > >	value (const LagrangianInjection &, const LagrangianSubMesh &) const
	Return the value for an instantaneous injection. More...

tmp< LagrangianSubField< Type > >	value (const LagrangianModel &, const LagrangianSubMesh &) const
	Return the value for either a continuous source or an. More...

template<class OtherType >
const LagrangianFieldSource< OtherType > &	fieldSource (const word &name, const LagrangianModel &) const
	Lookup and return another field source. More...

template<class OtherType , class OtherFieldSourceType >
const OtherFieldSourceType &	fieldSourceCast (const word &name, const LagrangianModel &) const
	Lookup and return another field source and then cast to a. More...

template<class OtherModelType >
const OtherModelType &	modelCast (const LagrangianModel &) const
	Cast a model to the given type. Handle errors. More...

template<class OtherType >
tmp< LagrangianSubField< OtherType > >	value (const word &name, const LagrangianSource &, const LagrangianSubMesh &) const
	Lookup and return the value of another field source. More...

template<class OtherType >
tmp< LagrangianSubField< OtherType > >	value (const word &name, const LagrangianInjection &, const LagrangianSubMesh &) const
	Lookup and return the value of another field source. More...

virtual void	write (Ostream &) const
	Write. More...

template<class OtherType >
const Foam::LagrangianFieldSource< OtherType > &	fieldSource (const word &name, const LagrangianModel &model) const

template<class OtherType >
Foam::tmp< Foam::LagrangianSubField< OtherType > >	value (const word &name, const LagrangianSource &source, const LagrangianSubMesh &subMesh) const

template<class OtherType >
Foam::tmp< Foam::LagrangianSubField< OtherType > >	value (const word &name, const LagrangianInjection &injection, const LagrangianSubMesh &subMesh) const

Additional Inherited Members
Static Public Member Functions inherited from LagrangianFieldSource< Type >
static autoPtr< LagrangianFieldSource< Type > >	New (const word &fieldSourceType, const regIOobject &)
	Return a pointer to a new field source. More...

static autoPtr< LagrangianFieldSource< Type > >	New (const regIOobject &, const dictionary &)
	Return a pointer to a new field source created from a dictionary. More...

Static Public Attributes inherited from LagrangianFieldSource< Type >
static int	disallowGenericLagrangianFieldSource
	Debug switch to disallow the use of genericLagrangianFieldSource. More...

Detailed Description

template<class Type>
class Foam::internalLagrangianFieldSource< Type >

This source condition retains the internal value.

Usage

Example specification:

<LagrangianModelName>
{
    type            internal;
}

Source files

Definition at line 58 of file internalLagrangianFieldSource.H.

Constructor & Destructor Documentation

◆ ~internalLagrangianFieldSource()

~internalLagrangianFieldSource

virtual

Destructor.

Definition at line 31 of file internalLagrangianFieldSource.C.

Member Function Documentation

◆ TypeName()

TypeName ( "internal" )

Runtime type information.

◆ clone()

virtual autoPtr<LagrangianFieldSource<Type> > clone ( const regIOobject & iIo ) const

inlinevirtual

Construct and return a clone setting the internal field reference.

Implements LagrangianFieldSource< Type >.

Definition at line 74 of file internalLagrangianFieldSource.H.

◆ sourceValue()

Foam::tmp< Foam::LagrangianSubField< Type > > sourceValue	(	const LagrangianSource &	source,
		const LagrangianSubMesh &	subMesh
	)		const

virtual

Return the source value.

Reimplemented from LagrangianFieldSource< Type >.

Definition at line 39 of file internalLagrangianFieldSource.C.

References LagrangianModel::name(), Foam::name(), Foam::compressible::New(), and LagrangianSubMesh::sub().

Here is the call graph for this function:

◆ internalCoeff()

Foam::tmp< Foam::LagrangianSubScalarField > internalCoeff	(	const LagrangianSource &	source,
		const LagrangianSubMesh &	subMesh
	)		const

virtual

Return the internal coefficient.

Reimplemented from LagrangianFieldSource< Type >.

Definition at line 56 of file internalLagrangianFieldSource.C.

References Foam::dimless, LagrangianModel::name(), Foam::name(), and Foam::compressible::New().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/Lagrangian/Lagrangian/fields/LagrangianFieldSources/derived/internal/internalLagrangianFieldSource.H
src/Lagrangian/Lagrangian/fields/LagrangianFieldSources/derived/internal/internalLagrangianFieldSource.C
