interfaceProperties Class Reference

Contains the interface properties. Surface tension, interface curvature, and functionality to correct alpha contact angle boundary conditions. More...

Public Member Functions
	interfaceProperties (const IOdictionary &dict, volScalarField &alpha1, volScalarField &alpha2, const volVectorField &U)
	Construct from dictionary, volume fraction fields and mixture. More...
	interfaceProperties (const interfaceProperties &)=delete
	Disallow default bitwise copy construction. More...
virtual	~interfaceProperties ()
	Destructor. More...
const volVectorField &	U () const
const dimensionedScalar &	deltaN () const
const surfaceScalarField &	nHatf () const
tmp< volVectorField >	n () const
tmp< volScalarField >	sigmaK () const
tmp< surfaceScalarField >	surfaceTensionForce () const
tmp< volScalarField >	nearInterface () const
	Indicator of the proximity of the interface. More...
void	correct ()
	Correct the curvature. More...
bool	read ()
	Read phaseProperties dictionary. More...
void	operator= (const interfaceProperties &)=delete
	Disallow default bitwise assignment. More...

Detailed Description

Contains the interface properties. Surface tension, interface curvature, and functionality to correct alpha contact angle boundary conditions.

Source files

• interfaceProperties.H
• interfaceProperties.C

Definition at line 52 of file interfaceProperties.H.

Constructor & Destructor Documentation

interfaceProperties() [1/2]

interfaceProperties	(	const IOdictionary &	dict,
		volScalarField &	alpha1,
		volScalarField &	alpha2,
		const volVectorField &	U
	)

Construct from dictionary, volume fraction fields and mixture.

velocity

Definition at line 147 of file interfaceProperties.C.

interfaceProperties() [2/2]

interfaceProperties ( const interfaceProperties &  )

delete

Disallow default bitwise copy construction.

~interfaceProperties()

virtual ~interfaceProperties ( )

inlinevirtual

Destructor.

Definition at line 115 of file interfaceProperties.H.

Member Function Documentation

U()

const volVectorField& U ( ) const

inline

Definition at line 121 of file interfaceProperties.H.

deltaN()

const dimensionedScalar& deltaN ( ) const

inline

Definition at line 126 of file interfaceProperties.H.

nHatf()

const surfaceScalarField& nHatf ( ) const

inline

Definition at line 131 of file interfaceProperties.H.

n()

Foam::tmp< Foam::volVectorField > n

(

)

const

Definition at line 199 of file interfaceProperties.C.

References Foam::fvc::grad(), Foam::mag(), and GeometricField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

sigmaK()

Foam::tmp< Foam::volScalarField > sigmaK

(

)

const

Definition at line 208 of file interfaceProperties.C.

surfaceTensionForce()

Foam::tmp< Foam::surfaceScalarField > surfaceTensionForce

(

)

const

Definition at line 215 of file interfaceProperties.C.

References Foam::fvc::interpolate(), and Foam::fvc::snGrad().

Here is the call graph for this function:

nearInterface()

Foam::tmp< Foam::volScalarField > nearInterface

(

)

const

Indicator of the proximity of the interface.

Field values are 1 near and 0 away from the interface.

Definition at line 222 of file interfaceProperties.C.

References Foam::pos0().

Here is the call graph for this function:

correct()

void correct

(

)

Correct the curvature.

Definition at line 228 of file interfaceProperties.C.

read()

bool read

(

)

Read phaseProperties dictionary.

Definition at line 234 of file interfaceProperties.C.

operator=()

void operator= ( const interfaceProperties &  )

delete

Disallow default bitwise assignment.

---

The documentation for this class was generated from the following files:

• src/twoPhaseModels/interfaceProperties/interfaceProperties.H
• src/twoPhaseModels/interfaceProperties/interfaceProperties.C
