phaseProperties Class Reference

Helper class to manage multi-specie phase properties. More...

Collaboration diagram for phaseProperties:
Collaboration graph
[legend]

Public Types

enum  phaseType { GAS , LIQUID , SOLID , UNKNOWN }
 Phase type enumeration. More...


Public Member Functions

 phaseProperties ()
 Null constructor. More...

 phaseProperties (Istream &)
 Construct from Istream. More...

 ~phaseProperties ()
 Destructor. More...

void reorder (const wordList &gasNames, const wordList &liquidNames, const wordList &solidNames)
 Reorder species to be consistent with the corresponding. More...

phaseType phase () const
 Return const access to the phase type. More...

const word & stateLabel () const
 Return const access to the phase state label. More...

word phaseTypeName () const
 Return word representation of the phase type. More...

const List< word > & names () const
 Return the list of specie names. More...

const word & name (const label speciei) const
 Return const access to a specie name. More...

const scalarField & Y () const
 Return const access to all specie mass fractions. More...

scalar & Y (const label speciei)
 Return non-const access to a specie mass fraction. More...

label carrierId (const label speciei) const
 Return the carrier id for a given specie. More...

label id (const word &specieName) const
 Return the id of a specie in the local list by name. More...


Static Public Attributes

static const NamedEnum< phaseType, 4 > phaseTypeNames
 Corresponding word representations for phase type enumerations. More...


Friends

Istream & operator>> (Istream &, phaseProperties &)

Ostream & operator<< (Ostream &, const phaseProperties &)


Detailed Description

Helper class to manage multi-specie phase properties.

Source files

Definition at line 60 of file phaseProperties.H.

Member Enumeration Documentation

◆ phaseType

enum phaseType

Phase type enumeration.

Enumerator
GAS
LIQUID
SOLID
UNKNOWN

Definition at line 67 of file phaseProperties.H.

Constructor & Destructor Documentation

◆ phaseProperties() [1/2]

phaseProperties ( )

Null constructor.

Definition at line 169 of file phaseProperties.C.

◆ phaseProperties() [2/2]

phaseProperties ( Istream &  is)

Construct from Istream.

Definition at line 31 of file phasePropertiesIO.C.

References IOstream::check(), forAllConstIter, entry::keyword(), dictionary::null, phaseProperties::phaseTypeNames, and List< T >::setSize().

Here is the call graph for this function:

◆ ~phaseProperties()

~phaseProperties ( )

Destructor.

Definition at line 181 of file phaseProperties.C.

Member Function Documentation

◆ reorder()

void reorder ( const wordList &  gasNames,
const wordList &  liquidNames,
const wordList &  solidNames
)

Reorder species to be consistent with the corresponding.

phase specie name list

Definition at line 187 of file phaseProperties.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::reorder().

Here is the call graph for this function:

◆ phase()

Foam::phaseProperties::phaseType phase ( ) const

Return const access to the phase type.

Definition at line 234 of file phaseProperties.C.

Referenced by CompositionModel< CloudType >::Cp(), CompositionModel< CloudType >::ha(), CompositionModel< CloudType >::hs(), CompositionModel< CloudType >::L(), and CompositionModel< CloudType >::X().

Here is the caller graph for this function:

◆ stateLabel()

const Foam::word & stateLabel ( ) const

Return const access to the phase state label.

Definition at line 240 of file phaseProperties.C.

◆ phaseTypeName()

Foam::word phaseTypeName ( ) const

Return word representation of the phase type.

Definition at line 246 of file phaseProperties.C.

◆ names()

const Foam::List< Foam::word > & names ( ) const

Return the list of specie names.

Definition at line 252 of file phaseProperties.C.

◆ name()

const Foam::word & name ( const label  speciei) const

Return const access to a specie name.

Definition at line 258 of file phaseProperties.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::nl.

Here is the call graph for this function:

◆ Y() [1/2]

const Foam::scalarField & Y ( ) const

Return const access to all specie mass fractions.

Definition at line 272 of file phaseProperties.C.

◆ Y() [2/2]

Foam::scalar & Y ( const label  speciei)

Return non-const access to a specie mass fraction.

Definition at line 278 of file phaseProperties.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::nl.

Here is the call graph for this function:

◆ carrierId()

Foam::label carrierId ( const label  speciei) const

Return the carrier id for a given specie.

Definition at line 292 of file phaseProperties.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::nl.

Referenced by CompositionModel< CloudType >::Cp(), CompositionModel< CloudType >::ha(), CompositionModel< CloudType >::hs(), and CompositionModel< CloudType >::X().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ id()

Foam::label id ( const word &  specieName) const

Return the id of a specie in the local list by name.

Returns -1 if not found

Definition at line 306 of file phaseProperties.C.

References forAll.

Friends And Related Function Documentation

◆ operator>>

Istream& operator>> ( Istream &  ,
phaseProperties &
)
friend

◆ operator<<

Ostream& operator<< ( Ostream &  ,
const phaseProperties &
)
friend

Member Data Documentation

◆ phaseTypeNames

const Foam::NamedEnum< Foam::phaseProperties::phaseType, 4 > phaseTypeNames
static
Initial value:
{
"gas",
"liquid",
"solid",
"unknown"
}

Corresponding word representations for phase type enumerations.

Definition at line 76 of file phaseProperties.H.

Referenced by Foam::operator<<(), Foam::operator>>(), and phaseProperties::phaseProperties().

The documentation for this class was generated from the following files:
