Inheritance diagram for fvMeshToFvMesh:

Collaboration diagram for fvMeshToFvMesh:

Public Member Functions
	TypeName ("fvMeshToFvMesh")
	Run-time type information. More...

	fvMeshToFvMesh (const fvMesh &srcMesh, const fvMesh &tgtMesh, const word &engineType, const HashTable< word > &patchMap=NullObjectRef< HashTable< word >>())
	Construct from source and target meshes. If a patchMap is supplied,. More...

virtual	~fvMeshToFvMesh ()
	Destructor. More...

template<class Type >
tmp< VolField< Type > >	srcToTgt (const VolField< Type > &srcFld) const
	Interpolate a source vol field to the target with no left. More...

template<class Type >
tmp< VolField< Type > >	srcToTgt (const VolField< Type > &srcFld, const VolField< Type > &leftOverTgtFld, const UList< wordRe > &tgtCuttingPatches) const
	Interpolate a source vol field to the target with left over. More...

template<class Type >
tmp< VolInternalField< Type > >	srcToTgt (const VolInternalField< Type > &srcFld) const
	Interpolate a source vol internal field to the target with no. More...

template<class Type >
tmp< VolInternalField< Type > >	srcToTgt (const VolInternalField< Type > &srcFld, const VolInternalField< Type > &leftOverTgtFld) const
	Interpolate a source vol internal field to the target with left. More...

template<class Type >
tmp< SurfaceFieldBoundary< Type > >	srcToTgt (const SurfaceFieldBoundary< Type > &srcFld) const
	... More...

template<class Type >
Foam::tmp< Foam::VolField< Type > >	srcToTgt (const VolField< Type > &srcFld) const

template<class Type >
Foam::tmp< Foam::VolField< Type > >	srcToTgt (const VolField< Type > &srcFld, const VolField< Type > &leftOverTgtFld, const UList< wordRe > &tgtCuttingPatchNames) const

template<class Type >
Foam::tmp< Foam::VolInternalField< Type > >	srcToTgt (const VolInternalField< Type > &srcFld) const

template<class Type >
Foam::tmp< Foam::VolInternalField< Type > >	srcToTgt (const VolInternalField< Type > &srcFld, const VolInternalField< Type > &leftOverTgtFld) const

template<class Type >
Foam::tmp< Foam::fvMeshToFvMesh::SurfaceFieldBoundary< Type > >	srcToTgt (const SurfaceFieldBoundary< Type > &srcBfld) const

Public Member Functions inherited from meshToMesh
	TypeName ("meshToMesh")
	Run-time type information. More...

	meshToMesh (const polyMesh &srcMesh, const polyMesh &tgtMesh, const word &engineType, const HashTable< word > &patchMap=NullObjectRef< HashTable< word >>())
	Construct from source and target meshes. If a patchMap is supplied,. More...

	meshToMesh (const meshToMesh &)=delete
	Disallow default bitwise copy construction. More...

virtual	~meshToMesh ()
	Destructor. More...

const polyMesh &	srcMesh () const
	Return const access to the source mesh. More...

const polyMesh &	tgtMesh () const
	Return const access to the target mesh. More...

bool	consistent () const
	Is the interpolation between consistent meshes? I.e., are all. More...

remote	srcToTgtPoint (const label srcCelli, const point &p) const
	Find the target processor and cell associated with a point in a. More...

void	operator= (const meshToMesh &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Protected Member Functions inherited from meshToMesh
const cellsToCells &	cellsInterpolation () const
	Return the interpolation engine between source and target cells. More...

const cellsToCellsStabilisation &	srcCellsStabilisation () const
	Return the stabilisation engine for the source cells. More...

const cellsToCellsStabilisation &	tgtCellsStabilisation () const
	Return the stabilisation engine for the target cells. More...

const List< labelPair > &	patchIndices () const
	Return the list of corresponding source and target patch indices. More...

const patchToPatch &	patchInterpolation (const label i) const
	Return the interpolation engine between a source and a target. More...

const patchToPatchStabilisation &	srcPatchStabilisation (const label i) const
	Return the stabilisation engine for a source patch. More...

const patchToPatchStabilisation &	tgtPatchStabilisation (const label i) const
	Return the stabilisation engine for a target patch. More...

Detailed Description

Source files

Definition at line 49 of file fvMeshToFvMesh.H.

Constructor & Destructor Documentation

◆ fvMeshToFvMesh()

fvMeshToFvMesh	(	const fvMesh &	srcMesh,
		const fvMesh &	tgtMesh,
		const word &	engineType,
		const HashTable< word > &	patchMap = `NullObjectRef<HashTable<word>>()`
	)

Construct from source and target meshes. If a patchMap is supplied,.

then interpolate between the specified patches. If not, then assume a consistent mesh with consistently named patches and interpolate 1-to-1 between patches with the same name.

Definition at line 38 of file fvMeshToFvMesh.C.

References Foam::dimless, Foam::endl(), Foam::Info, and DimensionedField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

◆ ~fvMeshToFvMesh()

~fvMeshToFvMesh ( )

virtual

Destructor.

Definition at line 79 of file fvMeshToFvMesh.C.

Member Function Documentation

◆ TypeName()

TypeName ( "fvMeshToFvMesh" )

Run-time type information.

◆ srcToTgt() [1/10]

tmp<VolField<Type> > srcToTgt ( const VolField< Type > & srcFld ) const

Interpolate a source vol field to the target with no left.

over values specified. If the interpolation weight sum is less than one for a face then they will be normalised. If the interpolation weight sum is zero for a face then that face's value will be NaN.

Referenced by Foam::MeshToMeshMapVolFields(), and Foam::MeshToMeshMapVolInternalFields().

Here is the caller graph for this function:

◆ srcToTgt() [2/10]

tmp<VolField<Type> > srcToTgt	(	const VolField< Type > &	srcFld,
		const VolField< Type > &	leftOverTgtFld,
		const UList< wordRe > &	tgtCuttingPatches
	)		const

Interpolate a source vol field to the target with left over.

values specified. If the interpolation weight sum is less than one for a face then the average will include the left over value multiplied by one minus the weight sum.

◆ srcToTgt() [3/10]

tmp<VolInternalField<Type> > srcToTgt ( const VolInternalField< Type > & srcFld ) const

Interpolate a source vol internal field to the target with no.

left over values specified. As the corresponding srcToTgt.

◆ srcToTgt() [4/10]

tmp<VolInternalField<Type> > srcToTgt	(	const VolInternalField< Type > &	srcFld,
		const VolInternalField< Type > &	leftOverTgtFld
	)		const

Interpolate a source vol internal field to the target with left.

over values specified. As the corresponding srcToTgt.

◆ srcToTgt() [5/10]

tmp<SurfaceFieldBoundary<Type> > srcToTgt ( const SurfaceFieldBoundary< Type > & srcFld ) const

...

◆ srcToTgt() [6/10]

Foam::tmp<Foam::VolField<Type> > srcToTgt ( const VolField< Type > & srcFld ) const

Definition at line 118 of file fvMeshToFvMeshTemplates.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), polyPatch::constraintType(), forAll, GeometricField< Type, GeoMesh, PrimitiveField >::internalField(), IOobject::name(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), patchi, fvPatchField< Type >::patchInternalField(), tmp< T >::ref(), PtrList< T >::set(), UPtrList< T >::size(), and Foam::typedName().

Here is the call graph for this function:

◆ srcToTgt() [7/10]

Foam::tmp<Foam::VolField<Type> > srcToTgt	(	const VolField< Type > &	srcFld,
		const VolField< Type > &	leftOverTgtFld,
		const UList< wordRe > &	tgtCuttingPatchNames
	)		const
