Inheritance diagram for multiValveEngine::pistonObject:

Collaboration diagram for multiValveEngine::pistonObject:

Public Member Functions
	pistonObject (const word &name, const multiValveEngine &engine, const dictionary &dict)
	Construct from dictionary. More...

scalar	position (const scalar theta) const
	Return the piston position for the given CA theta. More...

scalar	position () const
	Return the current piston position. More...

scalar	displacement () const
	Return piston displacement for current time-step. More...

scalar	speed () const
	Return piston position for current time-step. More...

scalar	clearance () const
	Return clearance estimate. More...

void	updatePoints (pointField &)
	update points due to piston motion More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

Public Member Functions inherited from multiValveEngine::movingObject
	movingObject (const word &name, const multiValveEngine &engine, const dictionary &dict)
	Construct from dictionary. More...

virtual	~movingObject ()
	Destructor. More...

Static Public Attributes
static word	pistonBowlName
	Name of the piston bowl pointZone. More...

Additional Inherited Members
Public Attributes inherited from multiValveEngine::movingObject
const word	name
	Name of the object. More...

const vector	axis
	Axis. More...

const labelHashSet &	patchSet
	Object patchSet. More...

Protected Member Functions inherited from multiValveEngine::movingObject
void	calcScale (const pointMesh &pMesh, const scalarField &pDistMoving, const scalarField &pDistStatic, scalar dMoving, scalar dMax, scalar dStatic)
	Scale the mesh point deformation with distance functions. More...

void	transformPoints (pointField &newPoints, const vector &translationVector)

void	createStaticPatchSet ()
	Generate staticPatchSet_ based on patch entries. More...

void	initPatchSets ()
	Patch-set construction. More...

labelHashSet	movingPointZones () const

labelHashSet	staticPointZones () const

Protected Attributes inherited from multiValveEngine::movingObject
const multiValveEngine &	meshMover_
	Reference to engine mesh mover. More...

autoPtr< Function1< scalar > >	motion_
	Piston motion function. More...

wordReList	patchNames_
	Object patchNames. More...

labelHashSet	patchSet_
	Object patchSet. More...

labelHashSet	staticPatchSet_
	Patches which must not deform during mesh motion. More...

scalar	maxMotionDistance_
	Distance from object beyond which the mesh does not deform. More...

scalar	movingFrozenLayerThickness_
	Distance from object within mesh nodes move. More...

scalar	staticFrozenLayerThickness_
	Distance from static wall patch at domain perimeter. More...

wordReList	movingPointZones_

wordReList	frozenPointZones_

labelList	pointIDs_
	Points to move when cell zone is supplied. More...

pointScalarField	scale_
	Interpolation scale (1 at moving patches, 0 at far-field) More...

const scalar	cosineScale_
	Cosine scale for the boundary point motion, between 0 and 1. More...

const scalar	travelInterval_
	Update the scale_ field when the travel exceeds travelInterval. More...

label	executionCount_
	Count of the scale_ field updates. More...

scalar	position0_
	Position at last scale update. More...
